ASSEMBLY INSTRUCTION
Patio Folding Adirondack Chair
Prior to assembly, make sure you lay out and identify all the parts listed
below in the parts list.
Assembly Manual
Tighten all nuts and bolts securely. All bolts should be hand tightened
before use. Never use power tools or excessive force during assembly
and tightening of bolts.
Should you experience any difficulty during assembly or if any part is
missing or damaged:
Contact our customer service by email: info@kozyard.com or call toll
free: 1-866-355-0018.
Copyright 2016 - 2022 Kozyard LLC. | All Rights Reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kozyard Patio Folding Adirondack Chair
Summary of Contents for Kozyard Patio Folding Adirondack Chair
- Page 1 Should you experience any difficulty during assembly or if any part is missing or damaged: Contact our customer service by email: info@kozyard.com or call toll free: 1-866-355-0018. Copyright 2016 - 2022 Kozyard LLC. | All Rights Reserved.
- Page 2 Part list Part Description Part Description Seat Holder Back Armrest Armrest Front Connecting Bar Fasten Bar Knobs Back Connecting Bar...
- Page 3 Connect legs (part E and part F) with seat (part A) by Connect armrests (part C and part D) with legs using bolt ③ as shown in diagram. (part E and part F) by using bolt ④ as shown in diagram.
- Page 4 First connect back (part B) with armrests (part E and First connect back bar (part J) with seat (part A) by part F) by using bolt ⑤ as shown in diagram. using bolt ① as shown in diagram. Then connect fasten bar (part H) with seat (part A) by Then connect front bar (part G) with seat (part A) using bolt ①...
- Page 5 Assemble holder (part K) by using bolt ① as shown Storage or Folding for carrying out. in diagram. Pull out knobs (Part L) from both legs and seat to Complete the assembly. fold the chair as shown in diagram. Fasten all screws before use. Put knobs (Part L) back into the position on both sides and lock them before using as shown in diagram.
- Page 6 Toll free: 866-355-0018 www.kozyard.com email: support@ kozyard.com Follow us on Instagram www.instagram.com/kozyard Upload a pictu re of your Kozyard product in your home with the hashtag #kozyard share with your friends. Kozyard LLC 10808 6th St,Unit 100, Rancho Cucamonga,CA 91730...
