79187P PEDESTALS & MODESTY PANELS
A
ALLEN BOLT
5
" X 2" (13 PCS.)
16
D
FLAT WASHER M8
(17 PCS.)
TOP ASSEMBLIES (2 Pcs)
THE DESK CANNOT BE MOVED AFTER IT IS ASSEMBLED SO IT MUST BE ASSEMBLED IN THE AREA
IT WLL BE USED.
THE PEDESTAL WITH THE DOOR IS ON THE LEFT AS YOU ARE SITTING AT THE DESK
THE PEDESTAL WITH THE DRAWER IS ON THE RIGHT AS YOU ARE SITTING AT THE DESK.
STEP 2.
ASSEMBLE THE RIGHT PEDESTAL (2)
AND THE RIGHT MODESTY PANEL (3)
SAME AS STEP 1.
A HOWARD MILLER COMPANY
79187T TOP PANELS
HARDWARE LIST
B
ALLEN BOLT
5
" X 6" (2 PCS.)
16
E
F
ALLEN KEY L5
SPRING WASHER M8
5
(17 PCS.)
For
" & M8 (1 PC.)
16
PART INSIDE
1
Assembly Instruction
Page 1 of 3
C
ALLEN BOLT
M8 X 40 (2 PCS.)
G
COVER C A P S
(6 PCS.)
2
PEDESTALS (2 Pcs)
STEP 1.
ASSEMBLE THE LEFT PEDESTAL (2) AND THE LEFT
MODESTY PANEL (3) WITH ALLEN BOLTS (A),
SPRING WASHER (E), FLAT WASHER (D) USE
ALLEN KEY (F) BUT DO NOT TIGHTEN THE BOLTS
COMPLETELY AT THIS TIME.
3
MODESTY PANELS (2 Pcs)
F
E
D
"A" TYPE
G
A
