ASSEMBLY INSTRUCTION FOR 26120 DINING TABLE
HARDWARE LIST
NO.
DESCRIPTIN
ITEM
Bolt M8X35 MM
1
2
Flat washer M8X22 MM
3
Wrench
TO ASSEMBLY :
STEP 1 : Unpack dining table and turn the top assembly (A) upside down on a soft clean surface.
STEP 2 : Align holes in legs (B) with holes on bottom of top (A) and slide it into position.
STEP 3 : Assemble the Top(A) with Legs (B) using matching marks (A1-A1) & (B1-B1) .
STEP 4 : Thread all the flat washer(2) , bolt (1) to leg (B) .Do not tighten bolts fully until all bolts are started.
STEP 5 : Tighten all bolts fully with wrench (3) & (4) then carefully turn the dining table upright.
A HOWARD MILLER COMPANY
QTY.
8
8
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Howard Miller HEKMAN 26120
Summary of Contents for Howard Miller HEKMAN 26120
- Page 1 A HOWARD MILLER COMPANY ASSEMBLY INSTRUCTION FOR 26120 DINING TABLE HARDWARE LIST DESCRIPTIN QTY. ITEM Bolt M8X35 MM Flat washer M8X22 MM Wrench TO ASSEMBLY : STEP 1 : Unpack dining table and turn the top assembly (A) upside down on a soft clean surface.
- Page 2 A HOWARD MILLER COMPANY ASSEMBLY INSTRUCTION FOR 26120 DINING TABLE TO ASSEMBLY : STEP 5 :Unlock table slides. STEP 6 : Pull left & right side sliding top of the table away from the center. STEP 7 :Place the extension top (C) in the center of the table.
