Howard Miller HEKMAN 79167P Manual

A B
ALLEN BOLT ALLEN BOLT
5 5 1
" X 2" (4 PCS.) " X 1 "(3 PCS.)
16 16 2
G H
FLAT WASHER M6 SPRING W. M6
(1 PC.) (1 PC.)
TOP ASSEMBLIES (2 Pcs)
THE DESK CANNOT BE MOVED AFTER IT IS ASSEMBLED SO IT MUST BE ASSEMBLED IN THE AREA
IT WLL BE USED.
THE PEDESTAL WITH THE DOOR IS ON THE LEFT AS YOU ARE SITTING AT THE DESK
THE PEDESTAL WITH THE DRAWER IS ON THE RIGHT AS YOU ARE SITTING AT THE DESK.
STEP 2.
ASSEMBLE THE RIGHT PEDESTAL (2)
AND THE RIGHT MODESTY PANEL (3)
SAME AS STEP 1.
A HOWARD MILLER COMPANY
79167P PEDESTALS & MODESTY PANELS
79167T TOP PANEL
HARDWARE LIST
C D
FLAT WASHER M8 SPRING W. M8
(9 PCS.) (9 PCS.)
I
ALLEN KEY L4 (For M6)
ALLEN KEY L5 (For
(1 PC.)
1

Assembly Instruction

E
ALLEN BOLT
5
" X 6" (2 PCS.)
16
J K
5
") "L" BRACKET
16
(1 PC.) (4 PCS.)
PART INSIDE
2
PEDESTALS (2 Pcs)
STEP 1.
ASSEMBLE THE LEFT PEDESTAL (2) AND THE LEFT
MODESTY PANEL (3) WITH ALLEN BOLTS (A),
SPRING WASHER (D), FLAT WASHER (C) USE
ALLEN KEY (J) BUT DO NOT TIGHTEN THE BOLTS
COMPLETELY AT THIS TIME.
Page 1 of 3
F
ALLEN BOLT
M6 X 35 (1 PC.)
L
5
SCREW Ø6 x "
8
(8 PCS.)
3
MODESTY PANEL (2 Pcs)
J
A
D
C
