5.1 Example of ReportDataCmd

FPort：0x06
Bytes 1
Version
Version– 1 byte –0x01——the Version of NetvoxLoRaWAN Application Command Version
DeviceType– 1 byte – Device Type of Device
The devicetype is listed in Netvox LoRaWAN Application Devicetype doc
ReportType – 1 byte –the presentation of the NetvoxPayLoadData，according the devicetype
NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)
Tips
1. Battery Voltage:
The voltage value is bit 0 ~ bit 6, bit 7=0 is normal voltage, and bit 7=1 is low voltage.
Battery=0xA0, binary=1010 0000, if bit 7= 1, it means low voltage.
The actual voltage is 0010 0000 = 0x20 = 32, 32*0.1v =3.2v
2. Version Packet:
When Report Type=0x00 is the version packet, such as 013D000A0B202005200000, the firmware version is 2020.05.20
3. Data Packet:
When Report Type=0x01 is data packet.
Device Report
Device
Type Type
0x00
R718DB2 0x3D
0x01
Example 1 of Uplink: 013D012401000000000000
st
1 byte (01): Version
nd byte (3D): DeviceType 0x3D － R718DB2
2
rd
3 byte (01): ReportType
th byte (24): Battery － 3.6V, 24(Hex) = 36(Dec), 36x0.1v=3.6v
4
th byte (01): Status － on
5
th byte (00): Status － off
6
th th
7 -11 byte (0000000000): Reserved
1 1
DeviceType ReportType
SoftwareVersion
(1Byte)Eg.0x0A—V1.0
Battery
(1Byte, unit:0.1V)
NetvoxPayLoadData
NetvoxPayLoadData
HardwareVersion
(1Byte) (4Bytes,eg 0x20170503)
Status 1
(1Byte 0:off 1:on) (1Byte 0:off 1:on)
6
Var (Fix=8 Bytes)
DateCode
(2Bytes,fixed 0x00)
Status 2
(5Bytes,fixed 0x00)
Reserved
Reserved
