Xiamen Cashino Technology Co., Ltd.
CSN-A5 user manual
CSN-A5 Micro Panel Printer
Product Specifications
Protocol: Lin Xiaopeng 2017.04.06
Audit
: Hu Riyu 2017.04.08
Standardize：Liu Zhonghua 2017.04.09
Authorize: Wang Huanyong 2017.04.11
Company: Xiamen Cashino Technology Co., Ltd.
Tel: 0592-5517253 Fax: 0592-5231815
Address: 4/F,No.318,Tongji South Road, Jimei District,Xiamen,China.361021
The manual is subject to change without further notice. Please contact Xiamen Cashino Technology
Co., Ltd. directly for the latest version.
www.cashinotech.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSN-A5 and is the answer not in the manual?

Questions and answers

Related Manuals for Cashino CSN-A5

Summary of Contents for Cashino CSN-A5

  • Page 1 Authorize: Wang Huanyong 2017.04.11 Company: Xiamen Cashino Technology Co., Ltd. Tel: 0592-5517253 Fax: 0592-5231815 Address: 4/F,No.318,Tongji South Road, Jimei District,Xiamen,China.361021 The manual is subject to change without further notice. Please contact Xiamen Cashino Technology Co., Ltd. directly for the latest version. www.cashinotech.com...
  • Page 2 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual CSN-A5 micro panel printer product specifications revision record Edited Item Date Description Desing Review page 20180419 The first draft Hu Riyu Chunyan 20180523 Modify installation port size Hu Riyu Chunyan 20180726 Add two-dimensional code printing...

  • Page 3: Table Of Contents

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Content 1. Product description............................5 2. Product feature..............................5 3. External................................6 4. Product specification............................6 5. Paper installation............................... 7 6. Interface and define............................8 Parallel..................................9 7. LED reminder..............................9 8. Command Instruction............................9 8.1 Command List............................
  • Page 4 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual ④Tab Commands..........................32 Horizontal tab............................32 Horizontal tab position setting......................32 ⑤One-dimension bar code command..................... 33 1D bar code readable character(HRI) print position setting............33 1D bar code height setting......................... 33 1D bar code width setting........................34 1D bar code printing..........................

  • Page 5: Product Description

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 1. Product description Name: Micro panel thermal printer Model: CSN-A5 Installation port size: 82.3(W)*82.3(L)mm Embedded depth: 54mm Application: Medical apparatus and instruments Measuring equipment Security equipment Analytical instruments and meters 2. Product feature...

  • Page 6: External

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 3. External 4. Product specification Printing Method Thermal Line Print Printing Speed Max:90mm/s Resolution 203dpi(8dots/mm) Effective Printing Width 48mm Character Set ASCII, GB2312-80(Chinese), BIG5, etc. Character Print Font ANK:9×17,12×24, GBK:24×24 Paper Type Thermal Paper Paper spec.

  • Page 7: Paper Installation

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Paper Roll Diameter Max:50mm Reliability 50km(12.5% print ratio) Interface Parallel/Serial/Cashbox Power Supply (Adapter) DC5-9V ≥2A DC12V ≥2A Outline Dimension (WxLxH) 88×87×57mm Physical Installation Port Size(WxL) 82.3x82.3mm Insert Depth 54mm Color Black/Beige Operating Temp 0°C ~ 50°C...

  • Page 8: Interface And Define

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 6. Interface and define POWER Introduction 5-9V OR 12V Ground Serial Introduction Transmit Data Receive Data Ground Data Terminal Ready USB_D- USB_D+ Cashbox Introduction Power supply Cashbox www.cashinotech.com...

  • Page 9: Parallel

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual control Parallel Introduction strobe pulse D1~D8 output data acknowledgment character BUSY 18~26 Ground 7. LED reminder Power on ,and indicator light will flash two times ,one second apart. It shows power on.

  • Page 10: Commands Details

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Set and delete underline ESC - n ESC V n Set and delete 90°rotate printing ESC a Setting position alignment mode FS & Set Chinese character mode Delete Chinese character mode FS .

  • Page 11: Enter

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Range None Default None Notes None Example None Enter Name Enter ASCII ：CR Code DEC ：13 HEX ：0D Function Adjust print position to initial position of the same line. Range None Default...

  • Page 12: Set Line Space As N Dots

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Set line space as n dots Set line space as n dots Name ASCII ：ESC 3 n Code ：27 51 n ：1B 33 n Function Set line space as n dots Range 0 ≤...

  • Page 13: Set The Left Margin

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual HEX ：1B 24 nL nH Function Set left side blank area as（nL + nH × 256）dots 0 ≤ nL ≤ 255 Range 0 ≤ nH ≤ 255 Default None Set left side blank area as[(nL+nH*256)]*0.125mm] This command is only effective with the initial position of the line.

  • Page 14: Set Character Size

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 0 Font Normal Small character 1 Undefined 2 Undefined 3Bold Cancel Setting 4 Double height Cancel Setting 5 Double width Cancel Setting 6 Undefined 7 Underline Cancel Setting Range None Default n = 0 The command is effective with Chinese and foreign languages.

  • Page 15: Set、Remove White Printing

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Range None Default n = 0 This command is effective with Chinese and other foreign languages, Notes except for HRI character. The command setting is disable when ESC@, printer reset or power off.

  • Page 16: Set、Remove 90°Revolving Printing

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 0, 48 underline mode Remove 1, 49 Set underline mode(1dotcoarse) 2, 50 Set underline mode(2dotcoarse) Range 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 Default n = 0 Printer can print underline for all characters(including the space to the right of the character), except for the space set by HT.

  • Page 17: Set Printing Alignment

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual invalid. 1b 40 1b 56 01 Example 30 31 32 0d 0a 30 31 32 0d 0a Set printing alignment Name Set print alignment（Left, middle, right） ASCII ：ESC a n Code ：27 97 n ：1B 61 n...

  • Page 18: Select、Cancel User Customized Characters

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual ASCII：FS . DEC ：28 46 Code HEX：1C 2E Function Exit Chinese character mode，cancel Chinese character mode Range None Default None Notes None Example None Select、cancel user customized characters Select 、cancel user customized characters Name ASCII ：ESC % n...
  • Page 19 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual When it need one character only, make c1=c2. d is character’s dot data, dot mode starts from left side in the horizontal direction. It is blank for the rest dots in the right side.

  • Page 20: Cancel User Customized Characters

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual d1= <0F>H d4 = <30>H d7 = <40>H ..d2 = <03>H d5 = <80>H d8 = <40>H ..d3 = <00>H d6 =<00>H d9 = <20>H ..

  • Page 21: Selecting International Character Set

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual In the font selected with ESC !, the command removes the style defined for the specified encoding. If a user customized character is not defined, the printer ignores the command. Example None...
  • Page 22 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Selects n from character code Code Page CP437[U.S.A., Standard Europe] KataKana CP850 [Multilingual] CP860 [Portuguese] CP863 [Canadian-French] CP865 [Nordic] WCP1251 [Cyrillic] CP866 Cyrilliec #2 MIK [Cyrillic /Bulgarian] CP755 [East Europe，Latvian 2] Iran...

  • Page 23: ③Graphic Printing Command

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual ISO-8859-6[Arabic] ISO-8859-7[Greek] ISO-8859-8[Hebrew] ISO-8859-9[Turkish] ISO-8859-15 [Latin 9] Thai2 CP856 Cp874 CP932 SHIFT_JIS UNICODE UCS-2 BIG5 Range 0 ≤ n ≤ 255 Default Notes None 1B 40 1C 2E 1B 74 00 80 81 82 83 84 85 86 87 88 89 8A 8B 8C 8D 8E 8F 90 91 92 93 94 95 96...
  • Page 24 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 1≤Hl+Hh×256≤384 0≤d≤255 k=Hl+Hh×256（when m=0、1） k=(Hl +Hh×256) ×3（when m=32、33） XX80： m=0、1、32、33 1≤Hl+Hh×256≤576 0≤d≤255 k=Hl+Hh×256（when m=0、1） k=(Hl +Hh×256) ×3（when m=32、33） Default None [d]k corresponding bit is 1,which means that this bit can print. While it is 0,it means that this bit cannot print.

  • Page 25: Print Graphics Horizontal Module Data

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Print Graphics horizontal module data Name Print Graphics horizontal module data ASCII ：GS v 0 Code ：29 118 48 m xL xH yL yH [d]k ：1D 76 30 m xL xH yL yH [d]k Print horizontal module graphic data, the parameters are as below: m as bitmap method：...

  • Page 26: Define Downloaded Bitmap

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual This command has the printing function, data will be transferred while printing, no need to use the printing command again 1B 40 1d 76 30 00 03 00 09 00 Example FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF...

  • Page 27: Print Downloaded Bitmap

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 1B 40 1D 2A 03 03 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF Example FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF...

  • Page 28: Define Nv Bitmap

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Default None this command will be ignored if the bitmap data has not been defined. In standard mode, this command is effective only when there is no data in the buffer area.
  • Page 29 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual printing buffers and resets the printer to the mode that workable when power on. (hardware reset interface is not supported ) This command cancels all NV bitmaps that have already been defined by this command.
  • Page 30 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual data whose total capacity [bitmap data header] exceeds 192K bytes. The printer does not transmit ASB status or perform status detection during processing of this command even when ASB is specified. Once an NV bitmap is defined, it is not erased by performing ESC @, reset, and power off.

  • Page 31: Print Nv Bitmap

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 1B 40 1C 71 01 03 00 03 00 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF...

  • Page 32: ④Tab Commands

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual normal and double-width modes, and (for the height n 2 of the NV bitmap) in double height and quadruple modes, regardless of the line space specified by ESC 2 or ESC 3.

  • Page 33: ⑤One-Dimension Bar Code Command

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Maximum support for the setting of 16 tab position Using this command, the setting of previous tab position will be canceled k is for indication purpose, no transmission When transport [d]k, and come across NULL, should be considered over...

  • Page 34: Bar Code Width Setting

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual ASCII ：GS h n ：29 104 n Code DEX ：1D 68 n Parameter n specifies the height of a bar code in dots： Function Parameter 1 ≤ n ≤ 255 range Defaults...
  • Page 35 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Hex ：1D 6B m n [d]k 1D bar code printing, the parameters meaning as below： m is encoding n is code data length, only for (command B),the difference between (A) and (B)is that the data (A) end with NULL, but (B) indicates the data...
  • Page 36 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Bar code length（SP show space） Coding system Character set Data（d） leng fixe UPC-A n = 11，12 48≤d≤57 48≤d≤57 fixe 6≤n≤8， [when n = UPC-E n = 11，12 7,8,11,12， d1 = 48 ]...
  • Page 37 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual range (B) 65 ≤ m ≤ 74 Defaults None If the bar code width exceed the printable area, the printer does not perform barcode printing Paper feed as needed when the command is carried out, that not affected...
  • Page 38 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual When d6 is 1~9,be sure d7,d8,d9,d10 are 0,and d11 is 5~9 Initial character, terminator automatically inserted When print EAN13(m = 2 or 67),Please pay attention as following: Whatever the input data length is 12 or 13,check bit is automatically...
  • Page 39 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual When barcode readable character(HRI) is set to print, the control character will be replaced with space When print CODE128(m = 73),please pay attention as following: The encoding system intelligently identifies data and implements...

  • Page 40: ⑥Status Querying Commands

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual 1d 6b 43 0c 30 32 33 34 35 36 30 30 30 30 38 39 1d 6b 44 08 30 32 33 34 35 36 30 30 1d 6b 45 08 30 32 33 34 35 36 30 30...

  • Page 41: Real-Time Transmission Status

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Undefined. Paper end sensor: paper adequate. (0C) (12) Paper end sensor: paper near end. unused. fixed to be Off. Undefined. unused. fixed to be Off. Paper sensor status (n = 1, 49): Bits 2 and 3: When the paper end sensor detects the paper end, the printer goes offline and does not execute this command.
  • Page 42 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual •Printer return to the relative status immediately after receiving the command • this command try not to put in command list between 2 or more bite . Though printer being forbid by ESC=,this command still effective.
  • Page 43 Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Open upper cover Not press feed key press feed key Fixed to be 1 Paper adequate Paper shortage No error Error Fixed to be 0 n=3：transmit error status bite 0 Hexadecim decimalis...

  • Page 44: ⑦Two-Dimensional Bar Code Commands

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual recovered. n=4：paper sensor status bite Hexadecim decimalis Function Fixed to be 0 Fixed to be 1 2， 3 0 Paper Paper near-end Fixed to be 1 5， 6 0 Paper Paper end...

  • Page 45: Setting Error Correction Level Of Qr Code

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Default Notes Setting mode type of QR code to [n dot × n dot]. Example None Setting error correction level of QR code Name Setting error correction level of QR code ASCII ：GS (...

  • Page 46: Printing Qr Code

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Store two-dimensional code data (d1...dk) to data buffer. Notes ((pL + pH×256) - 3) bytes is processed as a graphic data after the m (d1... dk). Example None Printing QR code Name...

  • Page 47: Printing Two Dimensional Code

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual Setting QR code graph information The detailed graph information is as follows: Transmit data Hexadecim Decimal Data type Header 1byte Flag 1byte Width 30H-39H 48-57 1-5byte Separator 1byte Height 30H-39H 48-57 1-5byte...

  • Page 48: Printing Double Qr Code

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual nL nH: describes data length d1…dk: describes two dimensional code to be printed 0 ≤ v ≤ 17 Parameter 1 ≤ r ≤ 4 range k = nL + 256 * nH...

  • Page 49: ⑧Other Commands

    Xiamen Cashino Technology Co., Ltd. CSN-A5 user manual ⑧Other commands Printer reset Name Printer reset ASCII ：ESC @ Code Decimal ：27 64 Hex ：1B 40 The ESC @ command initializes the printer as following： This command prints the data contained in the print buffer, and Function initializes various set up items.
