- Page 1 PSI-010-FT2G-P8G Industrial Gigabit PoE+ Booster Switch...
-
Page 2: Table Of Contents
4.1. Wiring the Power Inputs ............14 4.2. Wiring Protective Earth ............14 4.3. Wiring the Ethernet Ports ............14 4.4. Connecting Powered Device (PD) ........... 15 4.5. Mounting ................15 5. Specifications ................16 5.1. Interface Specifications ............16 PSI-010-FT2G-P8G... -
Page 3: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
No personal injury Minor damage to the order to avoid misuse of product the product, confusion or misunderstanding NOTICE Used for highlighting general, No personal injury Minor damage to the but important information product NOTE Table 1. Warning levels PSI-010-FT2G-P8G... -
Page 5: Safety Information
PROTECTIVE FUSE The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. PSI-010-FT2G-P8G... -
Page 6: Care Recommendations
If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. PSI-010-FT2G-P8G... -
Page 7: Product Disposal
Table 2. Agency approvals and standards compliance 2.5.2. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. -
Page 8: Product Description
(SFPs). This offers flexibility for installations to reach both short and long distances by using any of the many SFPs in the Westermo portfolio. In addition, it also offers a cost-effective connection with the copper port. A fibre optic connection can be made outside the premises, as there is no electrical connection, allowing for diverse ground potentials. -
Page 9: Hardware Overview
3.3. Hardware Overview Description Description 2 x RJ-45/SFP combo ports LED indicators 8 x Ethernet TX ports (PoE+) Figure 3. Location of interface ports and LED indicators PSI-010-FT2G-P8G... -
Page 10: Connector Information
Supply voltage PWR2- Input Common Table 4. Power input 3.4.2. Wiring the Relay Output The product provides relay output. The relay contacts are energized (open) for normal operation and will close under faulty condition such as Ethernet port link break. PSI-010-FT2G-P8G... -
Page 11: Ethernet Connection Tx
Each SFP slot can hold one SFP transceiver. See "Transceiver User Guide 6100-0000" for transceiver handling instructions, which also can be downloaded from the product support pages at www.westermo.com/support/product-support. In the event of contamination, the optical connectors in the SFP transceivers should only be cleaned by the use of forced nitrogen and some kind of cleaning stick. -
Page 12: Led Indicators
Link with speed 10/100 Mbps LNK/ACT GREEN Fibre port is attached with partner BLINKING Fibre port is transmitting or receiving packets Fibre port link is inactive 1000M YELLOW ON Gigabit speed YELLOW OFF 100 Mbps speed Table 6. LED indicators PSI-010-FT2G-P8G... -
Page 13: Dimensions
3.7. Dimensions Dimensions are stated in mm. Figure 5. Dimensional drawing PSI-010-FT2G-P8G... -
Page 14: Installation
The green LNK LED will light up when the cable is correctly connected. Refer to the LED Indicators information for descriptions of each LED indicator. Always make sure that the cables between the switches and attached devices (e.g. switch, hub, or workstation) are less than 100 metres (328 feet). PSI-010-FT2G-P8G... -
Page 15: Connecting Powered Device (Pd)
1. Insert the upper end of the DIN-rail clip into the back of the DIN-rail track from its upper side. 2. Lightly, push the bottom of the DIN-rail clip into the track. 3. Check if the DIN-rail clip is tightly attached to the track. Figure 7. Mounting of product PSI-010-FT2G-P8G... -
Page 16: Specifications
PD device. Once the latest PD device claimed power over the system surplus power budget, the highest port of PoE will not be active due to port order mechanism. System Power Budget: 240 W at 24 VDC/120 W at 12 VDC PSI-010-FT2G-P8G... - Page 17 -40 to +85 °C, 0 to 90% humidity Hi pot 2.25 KVDC for power to chassis ground, Ethernet port to chassis ground Regulatory approvals Variation/Shock IEC 6137 Free fall IEC 60068 2 32 with package Note 1 Warranty 5 years PSI-010-FT2G-P8G...
- Page 18 Westermo • Metallverksgatan 6, SE-721 30 Västerås, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6626-2200 REV. A 2023 02 @ Westermo Network Technologies AB, Sweden...
