- Page 1 User Manual PCE-AQD 20 Particle Counter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 22 January 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Setting the alarm ......................8 6.10 Setting TWA for PM2.5 ..................... 8 6.11 Setting the sea level (for CO2 measurement) ..............8 RS232 interface ..................9 Battery ....................10 System Reset ..................10 10 Warranty ....................10 11 Disposal ....................10 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Technical Specifications
250-mA with lighting Operating conditions 0 ... 50°C / 32 ... 122°F, max. 80% rh Weight About 387 g / < 1 lb Dimensions 164 x 93 x 72 mm / 6.5 x 3.7 x 2.8 in © PCE Instruments... -
Page 5: Device Description
In measuring mode, press and hold this key for approx. 2 seconds to activate the logger function. Down/ALARM In the settings menu, the values can be changed with this key. Quicker changes are possible by pressing and holding this key. © PCE Instruments... -
Page 6: Display Description
The air pressure is displayed in hpa (hectopascal), mmHg (millimetres of mercury) or in inHG (inches of mercury). Time During the measurement, the display will show the time. Press the TIME/SET key for a short time to view the date followed by the sampling time for about 2 seconds. © PCE Instruments... -
Page 7: Functions
ENTER/LOG key for a short time. You can also save a “position“ along with the value. The position is displayed as “P x“ and can be changed to a value between 1 and 99 with the arrow keys. This enables you, for example, to assign the measurements to different places. © PCE Instruments... -
Page 8: Sd Card / Memory Structure
Press the ENTER/LOG key to save the value. 5.8.3 Temperature calibration Press the ENTER/LOG key to calibrate the temperature value. You can change the value with the arrow keys. Press the ENTER/LOG key to save the value. © PCE Instruments... -
Page 9: Settings
Press the Up and Down keys to select “YES“ or “NO“. If you have selected “YES“, press the ENTER/LOG key to save the setting. You can go to the next setting with the SET key. Note: When the meter is powered by the mains adaptor, Auto Power Off will be deactivated. © PCE Instruments... -
Page 10: Key Sound
Down keys to select the level of your current environment. Save this value by pressing the ENTER/LOG key. To go to “SET ESC“ (leave settings), press the SET key. Press the same key again to leave the settings and return to measurement mode. © PCE Instruments... -
Page 11: Rs232 Interface
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP D8 … D1 Display reading, D1 = LSD, D8 = MSD For example: If the display reading is 1234, then D8 … D1 is: 00001234 End word © PCE Instruments... -
Page 12: Battery
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 13 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
