- Page 1 User Manual PC Software PCE-FM 200 / PCE-FM 50N / PCE-FM 500N User manuals in various languages (deutsch, français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com last change: 29 January 2019...
-
Page 2: Table Of Contents
Disconnect from the PCE-FM 200 ..................5 Numerical display ......................6 Statistical data ........................6 Graphical representation ....................7 Performing the measurement ................... 8 Export of series of measurements ..................8 Loading and saving series of measurements ..............8 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general warranty terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. System requirements Operating system Windows XP SP3 or higher •... -
Page 4: Operation
The lower bar shows the statistical settings of the program that can be defined in the settings screen. The upper status bar shows the dynamic settings or data of the PCE-FM 200 which are directly taken from the connected device. These include the selected unit. © PCE Instruments... -
Page 5: Meaning Of The Individual Icons On The Toolbar
Save a series of measurements in a file Group "Graphics" Enlarge the graphics area ("Zooming") or move the enlarged graphics Restore the orginal graphics Change the background and representation of the graphics Print the currently visible graphics © PCE Instruments... - Page 6 Group "Settings" Open settings dialog Select one of the languages supported by the program Group "Program" Display an information dialog Exit the program © PCE Instruments...
-
Page 7: Operation
If, however, no connection has been established, the term "Disconnected" is displayed in red. Disconnect from the PCE-FM 200 By clicking on the icon, an active connection to the PCE-FM 200 can be terminated. If you exit the software while the connection is active, the connection will also be terminated. © PCE Instruments... -
Page 8: Numerical Display
These data come directly from the PCE- FM 200; the time can thus deviate from the PC time. Statistical data The statistics include the number of measured points, the smallest and largest measured force levels and the average value. Also, they include the date, start time, end time and duration of measurement. © PCE Instruments... -
Page 9: Graphical Representation
Shift mode is represented by the icon. If the mouse is now placed over the graphics area and then the left mouse button is pressed, the depicted section can be moved by holding the mouse button down. © PCE Instruments... -
Page 10: Performing The Measurement
Measurement series can also be exported. The entire content of one series of measurements can be exported in CSV format by using the icon of the toolbar. Loading and saving series of measurements A series of measurements can be loaded and saved via the and the icon in the toolbar. © PCE Instruments... - Page 11 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
- Page 12 User manuals in various languages (deutsch, français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Specifications are subject to change without notice. © PCE Instruments...
