PERFORMANCE INTERACTIVE SERIES
RECUMBENT BIKE
SF-RB420032
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PERFORMANCE INTERACTIVE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sunny Health & Fitness PERFORMANCE INTERACTIVE Series

Summary of Contents for Sunny Health & Fitness PERFORMANCE INTERACTIVE Series

  • Page 1 PERFORMANCE INTERACTIVE SERIES RECUMBENT BIKE SF-RB420032 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly.

  • Page 3: Pre-Assembly Check List

    PRE-ASSEMBLY CHECK LIST .Before you start to assemble, please make sure all parts are included.
  • Page 4 Description Spec. Qty. Description Spec. Qty. Main Frame 45L/R Pedal 1PR. Front Stabilizer Support Pad Rear Stabilizer Seat Handlebar Post Backrest 5L/R Swing Bar 1PR. Nut Cap 6L/R Connecting Arm 1PR. Meter 7L/R Handlebar 1PR. Manual Rear Handlebar Thank You Card Adjustable Handle Hardware Package Seat Rail...

  • Page 5: Hardware Package

    HARDWARE PACKAGE Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ✓ The model number (found on cover of manual) ✓ The product name (found on cover of manual) ✓...
  • Page 6 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 1 Remove the 2 Paper Tubes (No. E), 4 Carriage Bolts (No. 27), 4 Arc Washers (No. 26) and 4 Cap Nuts (No.
  • Page 7 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 2 Remove 4 Screws (No. 22), 4 Spring Washers (No. 41) and 4 Arc Washers (No. 26) from the Main Frame (No.
  • Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 3 Remove 2 Hex Screws (No. 30), 2 Spring Washers (No. 41), 2 Flat Washers (No. 38) and 2 Wave Washers (No.
  • Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 4 Remove the 2 Nylon Nuts (No. 23L/R) and 2 Spring Washers (No. 78) from the Pedals (No. 45L/R) by Spanner (No.
  • Page 10 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 5 Attach 2 Handlebars (No. 7L/R) to 2 Swing Bars (No. 5L/R) with 4 Carriage Bolts (No. 29), 4 Arc Washers (No.
  • Page 11 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 7 Remove 1 Screw (No. 22), 1 Spring Washer (No. 41) and 1 Flat Washer (No.

  • Page 12: Adjustment Guide

    ADJUSTMENT GUIDE ADJUSTING THE BALANCE In order to achieve a smooth and comfortable ride, you must ensure that the bike is stabled and secured. If you notice that the bike is unbalanced during use, you should adjust the Adjustable Pads (No.

  • Page 13: Battery Installation And Replacement

    BATTERY INSTALLATION & REPLACEMENT Battery Battery Cover BATTERY INSTALLATION 1. Take out 2 AAA batteries from meter box. 2. Press the buckle of battery cover on the Meter (No. 65), then remove battery cover. 3. Install 2 AAA batteries into the battery case on the back of the Meter (No. 65). Pay attention to the battery + and –...

  • Page 14: Function Buttons

    EXERCISE METER FUNCTION BUTTONS: MODE: Press the button to select TIME, DISTANCE, and CALORIES to preset. Press the button for selection function display value on LCD or enter after setting. Press the button and hold for 3 seconds to reset all values except odometer to zero.

  • Page 15: App Connection

    Automatically counts down from targeting value during exercise. NOTE: This data is a rough guide which cannot be used in medical treatment. 8. ODOMETER: Displays the total accumulated distance from 0.0 to 9999 M (miles). User can also press MODE button to display the odometer value.

  • Page 16: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 17: Parts List

    PARTS LIST Description Spec. Qty. Description Spec. Qty. Φ25×1.5 Main Frame Round Plug Front Stabilizer Square Plug 38×38×1.5 Rear Stabilizer Sleeve Handlebar Post Transportation Wheel 5L/R Swing Bar 1PR. Seat 6L/R Connecting Arm 1PR. Backrest 7L/R Handlebar 1PR. Nut Cap Seat Support Meter Meter Sensor...
  • Page 18 Description Spec. Qty. Description Spec. Qty. Flywheel Axle Spanner S13,S14,S15 Bearing Bracket Allen Wrench Magnet Allen Wrench Spring Washer Spanner S13,S14 Φ1.6×Φ15×L47.2 Spring Spanner S17,S19 Φ3×Φ18×L58.5 Spring Magnetic Board Bearing 6001RS Version 1.0...

This manual is also suitable for:

Sf-rb420032

Table of Contents
