- Page 1 BELT DRIVE INDOOR CYCLING BIKE SF-B1002 USER MANUAL IMPORTANT: Read all instructions carefully before using this product. Retain owner’s manual future reference. customer service, please contact: support@sunnyhealthfitness.com...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly. -
Page 3: Exploded Drawing
EXPLODED DRAWING HARDWARE PACKAGE #9 (M10*25*S6) 4PCS #19 (M10*25*S6) 2PCS #20 (d10*Φ20*1.5) 2PCS #10 (d10*Φ20*2.0) 4PCS #78 (S14-15-17) #79 (S13-15) #77 (S6) #80 (S8-14-22) -
Page 4: Parts List
PARTS LIST Description Spec. Description Spec. Main Frame Bearing 6004-RZ NBK Saddle Post Jump Ring Handlebar Wave Washer d20*Φ26*0.3 Handlebar Post M10*1.25*H7.5*S14 Cover For Middle Φ50*Φ32*33 Adjustable Bolt Axle Front Stabilizer Tension Knob M10*Φ49*46 Rear Stabilizer M10*H7*S17 Φ10*240*M10*15*M Seat Slider Brake Rod 6*7 *M10*95 Screw... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP 1: #77 S6 Unscrew the Screws (No. 74) with Allen Wrench (No. 77) and remove the Washers (No. 10), Shipping Rear Tube (No. 75) and Shipping Front Tube (No. 76). You may discard these parts or save them in case you’d like to repackage the item in the future. - Page 6 STEP 4: #79 S13-15 Loosen and remove the [saddle post] Adjustment Knob (No. 16). Insert Saddle Post (No. 2) into the sleeve located on the back of the Main Frame (No. 1). Adjust the Saddle Post (No. 2) to the desired position and reinsert and tighten Adjustment Knob (No.
- Page 7 ADJUSTMENTS & USAGE GUIDE ADJUSTING THE BALANCE In order to achieve a smooth and comfortable ride, you must ensure that the stability of the bike is secured. If you notice that the bike is unbalanced during use, you should adjust the foot levelers located beneath the front and rear stabilizers.
-
Page 8: Maintenance And Care
MAINTENANCE & CARE This is general information for daily, weekly and monthly maintenance to be performed on your bike. DAILY MAINTENANCE MONTHLY MAINTENANCE After each exercise session, wipe down all 1. Check all hardware is secure, such as: water bottle holder, flywheel nuts, belt/chain guard the equipment: seat, frame, handlebars.
