- Page 1 ELKO - SmartMove Multiwire Dimmer Push Device user guide Information about features and functionality of the devices 11/2022 www.elko.no...
- Page 2 Legal Information The ELKO brand and any trademarks of ELKO AS and its subsidiaries referred to in this guide are the property of ELKO AS or its subsidiaries. All other brands may be trademarks of their respective owners. This guide and its content are protected under applicable copyright laws and furnished for informational use only.
-
Page 3: Table Of Contents
Table of Contents Safety information ..................4 ELKO - SmartMove Multiwire Dimmer Push ...........5 For your safety ...................5 About the device..................6 Installing the device ..................6 Pairing the device ..................6 Pairing device manually.................6 Pairing device with auto scan..............8 Checking the type of wiring mode ..............9 Configuring the device ................9... -
Page 4: Safety Information
Safety information Safety information Important information Read these instructions carefully and look at the equipment to become familiar with the device before trying to install, operate, service, or maintain it. The following special messages may appear throughout this manual or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure. -
Page 5: Elko - Smartmove Multiwire Dimmer Push
ELKO - SmartMove Multiwire Dimmer Push ELKO - SmartMove Multiwire Dimmer Push EKO0725X EKO07253, EKO30199 For your safety DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Safe electrical installation must be carried out only by skilled professionals. Skilled professionals must prove profound knowledge in the following areas: - Connecting to installation networks. -
Page 6: About The Device
Control options Home control: To control the motion sensor through the ELKO app you will need the ELKO SmartHUB. Direct operation: The motion sensor can always be controlled directly on-site. - Page 7 ELKO - SmartMove Multiwire Dimmer Push 4. To pair the device with an install code, tap Add Device with Install Code to display the slide-up menu. Select any one of the options (B): – Scan Install Code - you can scan the device for the install code.
-
Page 8: Pairing Device With Auto Scan
2. Tap Auto scan and tap Confirm. 3. If you have multiple hubs, do Step 4 or proceed to Step 5. 4. Tap Select hub and select the ELKO SmartHub from the slide-up menu. 5. Short press the push button 3 times (< 0,5 s). -
Page 9: Checking The Type Of Wiring Mode
ELKO - SmartMove Multiwire Dimmer Push Checking the type of wiring mode Using the ELKO Smart app, you can check whether the dimmer is connected with or without neutral wire. To check the type of wiring mode: 1. On the Home page, tap All devices > Motion Sensor Dimmer. -
Page 10: Renaming The Device
Name Save Changing the device location You can change the device location using the ELKO Smart app. 1. On the Home page, select the device for which you wish to change the location. 2. At the top-right corner of the screen, tap... - Page 11 ELKO - SmartMove Multiwire Dimmer Push 3. Tap edit next to the device name. 4. Tap Location. 5. Select the desired location from the list (A) and then tap Save. Device location Save Living Room Master Bedroom Dining Room Study Room...
-
Page 12: Managing Motion Sensor Dimmer Settings
ELKO - SmartMove Multiwire Dimmer Push Managing motion sensor dimmer settings Using The ELKO app, you can manage the settings. To access the motion sensor dimmer settings: 1. On the Home page, tap All devices > Motion Sensor Dimmer. 2. On the device control panel page, tap Settings. - Page 13 ELKO - SmartMove Multiwire Dimmer Push NOTE: The Dimming range is limited if the min. and max. levels are too close to each other. Toggle mode setting Using this setting, the device will remember the last state of the device.
- Page 14 ELKO - SmartMove Multiwire Dimmer Push Sensor setting Sensitivity Setting Using the ELKO app, you can set the sensitivity of the sensor (such as High, Medium, Low). Tap Sensitivity Setting and select one of the following levels (A): • High •...
-
Page 15: Removing The Device
ELKO - SmartMove Multiwire Dimmer Push Lux Customization Using the ELKO app, you can define the threshold value for lux ranges (such as very dark, dark, bright, very bright) of the environment. This will help to prevent the false alarm caused by changes in the light intensity. -
Page 16: Resetting The Device
ELKO - SmartMove Multiwire Dimmer Push Resetting the device You can reset the device to factory default manually. To reset the device: Short press push button 3 times (< 0.5 s) and then long press the push button once (>10 s), LED starts blinking red then release the push button. -
Page 17: Switching/Dimming The Device Manually
Dimmer. > 0,5 s Switching/Dimming the device using app Using the ELKO app, you can turn on/off and increase/decrease the brightness of the device. To turn the device on/off: 1. On the Home page, tap the power button (A) to turn on/off the Motion Sensor Dimmer. -
Page 18: Creating A Schedule
ELKO - SmartMove Multiwire Dimmer Push 2. On the Home page, tap the ˅ next to the device name and drag the sliding bar (B) to adjust the brightness of the dimmer. 3. Alternatively, you can navigate to the control panel, page 16... -
Page 19: Creating A Moment
8. Tap Save. Creating a moment Moment allows you to group multiple actions that are usually done together. Using the ELKO Smart app, you can create moments based on your needs. To create a moment: 1. On the Home page, tap 2. - Page 20 ELKO - SmartMove Multiwire Dimmer Push 5. In the Add task menu, you can do either or all of the following actions (C): – Run the device - Select the devices that you want in a moment. – Select Automation - Select the automation that you want to enable or disable.
-
Page 21: Creating An Automation
Creating an automation Automation allows you to group multiple actions that are usually done together, triggered automatically or at scheduled times. Using the ELKO Smart app, you can create automations based on your needs. To create an automation: 1. On the Home page, tap the 2. - Page 22 ELKO - SmartMove Multiwire Dimmer Push 4. Tap Any condition is met to select any one of the condition type (B): – All conditions are met - The automation is triggered when all the conditions are met. – Any condition is met - The automation is triggered when at least one condition is met.
- Page 23 ELKO - SmartMove Multiwire Dimmer Push 7. Tap When device status changes > Motion Sensor Dimmer and select either functions: – Motion Dimmer - Turn the Dimmer On/Off (D). – Motion State - Select the Occupied or Unoccupied state (E).
- Page 24 ELKO - SmartMove Multiwire Dimmer Push 10. Tap on Effective period to set the time range for the automation. You can select any one of the following (I): – All-day - 24 hours – Daytime - From sunrise to sunset –...
- Page 25 ELKO - SmartMove Multiwire Dimmer Push 5. Tap Add task > Send Notification and select Notifications (B). Multiple items selectable 6. Tap Next. 7. In the Automation Settings page, tap Save. Once the automation is saved, it is visible on the Automation tab. You can tap the toggle switch on the automation to enable it.
-
Page 26: Led Indication
ELKO - SmartMove Multiwire Dimmer Push 1. On the Automation tab, locate the automation that you want to delete and then tap 2. Tap Delete and tap Ok. NOTE: After deleting an automation, the device action can no longer be triggered. -
Page 27: Technical Data
ELKO - SmartMove Multiwire Dimmer Push Technical Data Nominal power Load value Load type Load name 2 wire (without neutral) 3 wire (with neutral) 7–130 W (max. 0,8 A) 0–130 W (max. 0,8 A) 7–80 W (max. 0,5 A) 0–80 W (max. 0,5 A) Incandescent lamp 14–200 W... - Page 28 Trademarks This guide makes reference to system and brand names that are trademarks of their relevant owners. • Zigbee ® is a registered trademark of the Connectivity Standards Alliance. • Apple ® and App Store ® are brand names or registered trademarks of Apple Inc. •...
- Page 30 ELKO AS Sandstuveien 68, 0680 Oslo Pb 6598 Etterstad, 0607 Oslo Norway +47 67 79 39 00 support@elko.no www.elko.no As standards, specifications, and design change from time to time, please ask for confirmation of the information given in this publication.
