USE AND CARE GUIDE
PLAISTOW 3 PERSON WICKER SWING WITH CANOPY
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this swing. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY GCS00225B
Summary of Contents for HAMPTON BAY GCS00225B
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Package Contents ..............4 Assembly ................5 Warranty ................ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Part Description... -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Top bar Side bar Seat Back Left arm Right arm Curved bar Support bar Short swing pipe Long swing pipe Canopy Seat cushion... -
Page 5: Assembly
Assembly ASSEMBLING THE SWING FRAME Attach two sets of the legs (B) to the top bar (A) using M8x100 combination bolts, washers and nuts (AA). Attach the support bars (KK) to the legs (B) and the top bar (A) using M8x45 combination bolts, washers and nuts (CC) and M8x50 combination bolts, washers and nuts (BB). - Page 6 Assembly (continued) ATTACHING THE ARMS AND THE SEAT TO THE BACK Attach the left and the right arm (F&G) to the back (E) using M6x40 combination bolts (FF). Attach the seat (D) to the arms (F&G) using M6x20 combination bolts (HH). Connect the seat (D) to the back (E) using M6x45 combination bolts (EE).
- Page 7 Assembly (continued) ATTACHING THE SWING PIPES TO THE ARMS Attach the short and the long swing pipes (J&K) to the left and the right arms (F&G) using M8x20 combination bolts (DD). Connect the top of the two swing pipes (J&K) together using the hooks (II). Once all of the bolts are in place, fully tighten the bolts.
- Page 8 Assembly (continued) ATTACHING THE SEAT TO THE SWING FRAME Attach the assembled seat to the swing frame using the hooks (II).
- Page 9 Assembly (continued) ASSEMBLING THE TOP FRAME Attach the two curved bars (H) to the support bars (I) using M6x30 bolts (GG). Fully tighten all of the bolts on the top frame using the hex wrench (LL) before placing the canopy (L). Place the canopy (L) on the assembled top frame and tie the canopy (L) to the curved bars (H) by affixing the Velcro.
- Page 10 Assembly (continued) ATTACHING THE TOP FRAME TO THE TOP BAR Attach the assembled top frame to the top bar (A) using the knobs (JJ) on both sides. Adjust the angle of the top frame and fully tighten the knobs (JJ) in the clockwise direction. Place the seat cushions (M) on the seat (D).
-
Page 11: Care And Cleaning
Assembly (continued) TIGHTENING THE BOLTS Make sure that the swing is tightly assembled and stable before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 12 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
