1. DESCRIPTION

Motor housing
1. Saftey switch
2. Handle
3. Switch
4. Cable
5. Front handle
6. Telescopic tube
7. Motor protect housing
8. Housing
9. Head adjust button
10. Protection guard
11. Guide wheel
12. Spool
Fig 1

2. TECHNICAL SPECIFICATION

Voltage/Frequency: 220 V~ 50Hz
Power: 450 W
No load speed: 10000 rpm
Line diameter: 1.4 mm
Cutting width: 30 cm
Guaranteed sound power level: 96 dB(A)

3. SAFETY INSTRUCTION

WARNING! Read all instructions failure to follow all instructions listed below may result in elec-
tric shock, fire and /or serious injury. The term "power tool" in all of the warnings listed below
refers to your mains operated (corded) power tools.
SAVE THESE INSTRUCTIONS
1) WORK AREA
a) Keep the work area clean and well lit. Cluttered and dark areas invite accidents
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks, which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
