Summary of Contents for Daewoo DAHT5540Li
- Page 1 DAHT5540Li Lithium hedge trimmer USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SYMBOLS MARKED ON THE PRODUCT ..................... 2 2. GENERAL SAFETY RULES ........................2 3. GENERAL IDENTIFICATION ........................5 4. TECHNICAL DATA ........................... 6 5. ASSEMBLY .............................. 6 6. OPERATING THE HEDGE TRIMMER ..................... 7 7. MAINTENANCE AND CARE ........................9 8. -
Page 3: Symbols Marked On The Product
1. SYMBOLS MARKED ON THE PRODUCT SYMBOLS NAME EXPLANATION The product meets demands and regulations set by the CE Marking European Community (now European Union). CAUTION! Unusable power tools do not belong with domestic waste. They must be taken to a communal WEEE marking collecting point for environmentally friendly disposal in accordance with local regulations... - Page 4 2.2 Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adap- ter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b）...
- Page 5 f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.
-
Page 6: General Identification
8. Use the battery only in conjunction with your power tool. This measure alone protects the battery against dangerous overload. 2.6.3 Safety Warnings for battery chargers 1. Keep the battery charger away from rain or moisture. Penetration of water in the battery charger increases the risk of an electric shock. -
Page 7: Technical Data
4. TECHNICAL DATA Model DAHT5540Li Power: 40 V No Load Speed: 1400 rpm Cutting length: 520 mm Cutting width: 20 mm Net weight: 4.35 kg Sound Pressure level at the operator’s position: 80.3dB(A) K=3 dB(A) Measured Sound Power level: 93.1dB(A) K=2.0dB(A) Guaranteed Sound Power level: 95dB(A) Vibration: 3.05m/s²... -
Page 8: Operating The Hedge Trimmer
5.2 Remove the battery 1. Press and hold the battery latch button at the bottom of the battery pack. (Fig.2A). 2. Remove battery pack from the product. (Fig.2B). Fig. 2A Fig. 2B 6. OPERATING THE HEDGE TRIMMER WARNING: Before working on the device-cleaning, inspection， maintenance or other work-always turn off the device and remove the battery from the device. - Page 9 Fig. 4 6.3 Stopping the device：if you release one of the safety elements， the cutting blades will stop. (Fig.5) Fig. 5 6.4 Gather up the cutting guard For you safety and storage, please gather up cutting guard after each operation. (Fig.6A/ Fig.B/ Fig.6C)
-
Page 10: Maintenance And Care
Fig. 6A Fig. 6B Fig. 6C 7. MAINTENANCE AND CARE WARNING: Switch off and remove battery from machine before adjusting or cleaning. For safe and proper working, always keep the garden product clean. Note: To ensure long and reliable service, carry out the following maintenance regularly. 1. -
Page 11: Troubleshooting
8. TROUBLESHOOTING The following chart lists problem symptoms, possible causes and corrective action, if your garden product does not operate properly. If these do not identify and correct the problem, contact your service agent. WARNING: Switch off and remove the battery prior to any troubleshooting. Fault Remedial action Hedge trimmer does not operate. -
Page 12: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
