- Page 1 DALPHT18-1 Lithium pole hedge trimmer USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. GENERAL POWER TOOL SAFETY WARNINGS ..................3 2. SAFETY WARNINGS FOR OPERATIONS....................5 3. TECHNICAL SPECIFICATIONS ......................13 4. EXPLODED VIEW AND SPARE PART LIST ................... 14 WARRANTY ............................... 17... -
Page 3: General Power Tool Safety Warnings
1. GENERAL POWER TOOL SAFETY WARNINGS Read the operating instructions carefully, especially the safety instructions, before using the device. Failure to follow these operating instructions can result in serious injury or damage to the device. The operating instructions are based on the standards and rules applicable in the European Union. When abroad, also observe country-speci c guidelines and laws. - Page 4 Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the in uence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
-
Page 5: Safety Warnings For Operations
Service a) Have your power tool serviced by a quali ed repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 2. SAFETY WARNINGS FOR OPERATIONS Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, re and/or serious injury WARNING: Risk of injury! •... - Page 6 The ambient temperature must not be less than 0ºC nor exceed 40ºC when charging. Do not use or store drill or batteries in temperatures in excess of 49ºC. d) Battery Packs which are defective or damaged, or can no longer be re-charged, must be dispo- sed of as hazardous waste.
- Page 7 Residual risks Despite the intended use, residual risks that are not obvious cannot be completely ruled out. Due to the type of device, the following hazards can occur: Damage to health resulting from vibration emissions if the device is used over a long period of time or is not properly operated and maintai- ned.
- Page 8 Service Use a shoulder strap When using the device, always wear the carrying strap 5 in order to be able to work without getting tired. In order to be able to open the carrying strap 5 quickly in the event of an accident, the carr- ying strap is equipped with an accelerator 13.
- Page 9 Adjust the angle of inclination In order to ensure an optimal working position, the hedge trimmer head 10 can be inclined in 15º steps up to an angle of 135º. 1. Press the inclination angle lock 15 on both sides and set the desired inclination angle. 2.
- Page 10 Remove the battery 1. Press and hold the battery release button. 2. Pull the battery out of the battery holder. If the battery cannot be removed easily, the battery release button was not pressed enough. Press the battery release button more rmly. Insert the battery 1.
- Page 11 • Achieve the best cutting performance You, if the device is guided in such a way that the knife teeth are directed at an angle of approx. 15º to the hedge. • The side surfaces of a hedge are cut with arcuate movements from bottom to top. •...
- Page 12 Remove blockages Risk of injury! Unintentional switching on can lead to injuries. • Make sure that the device is switched off. • Disconnect the battery from the device. 1. Stop the device. 2. Remove the battery. 3. Remove the jammed material from the sword. Test Risk of injury from sharp knives •...
-
Page 13: Technical Specifications
3. TECHNICAL SPECIFICATIONS Power: 18 V Cutting length: 415 mm Cutting thickness: 15 mm Max. running time: 35 min (at ambient temperature 20°C) Adjustable height of telescopic handle: 2.17-2.92 m Knife length: 480 mm Tooth spacing: 16 mm Weight (without battery): 3.7 kg Battery and charger are not included. -
Page 14: Exploded View And Spare Part List
4. EXPLODED VIEW AND SPARE PART LIST... - Page 16 1. Battery bracket (x1) 50. The left casing (x1) 2. Unlock the push button (x1) 51. Wire holder (x1) 3. Micro Switch (x1) 52. Illustration (x2) 4. Spring 1 (x1) 53. Cross tapping screw (x16) 5. Switch the trigger (x1) 54.
-
Page 17: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 18 Manufactured under license of Daewoo International Corporation, Korea...
