HOMCOM HOME GYM Assembly Instruction Manual page 5

NO. Description
1 Front Base Tube
2 Middle Base Tube
3 Back Base Tube
4 Guide Tube(down)
5 Guide Tube(up)
6 Bilateral Tube
7 Ridge Tube
8 Connecting Part
9 Butterfly Arm (right)
10 Butterfly Arm (left)
11 Handle Bar
12 Seat Beam
13 Leg Beam
14 Foam Tube
15 Main Frame(down)
16 Main Frame(up)
17 Connect Tube
18 Pulley Bracket
19 U Push Frame(left)
20 Selector Bar
21 Top Lat Bar
22 Floating Pulley Bracket
23 Reverse Pulley Bracket
24 Weight Stack Pin
25 Weight Stack
26 Black Fixing Bushing
27 Fixing Pin
28 Top Plate
29 Big Washer
30 Lat Bar
31 U Push Frame(right)
□1.77" End Plug
32
□1.77" Foot Cap
33
□1.5" End Plug
34
Qty NO. Description
1 35
Round Plugφ1"
1 36 L Cover
1 37 Handle Grip
2 38 Middle empty Plug
2 39 Rubber Ring
2 40 Rubber Cushion
1 41 Pulley
1 42 Pulley Bushing
1 43 Quick Pin
1 44 Snap Hook
2 45 Chain
1 46 Butterfly Arm Foam
1 47 Leg Foam
2 48 Leg Cable
1 49 Arm Cable
1 50 Top Lat Cable
1 51 Oil Bushing(Small)
2 52 Oil Bushing(Big)
1 53 Backrest
1 54 Seat
1 55 M1/2x7.08" Bolt
1 56 Hex Bolt M3/8x2.55"
1 57 Hex Bolt M3/8x2.75"
1 58 Hex Bolt M3/8x2.36"
8 59 Hex Bolt M3/8x1.57"
1 60 Hex Bolt M3/8x0.75"
1 61 Hex Bolt M1/4x2.55"
1 62 Hex Bolt M1/4x0.75"
1 63 M1/4" Washer
1 64 M3/8" Washer
1 65 M1/2" Washer
9 66 M3/8" Nylon Nut
4 67 M1/2" Nylon Nut
6
4
Qty
4
2
6
2
2
1
14
6
2
5
2
2
4
1
1
1
6
4
1
1
1
19
1
2
11
9
2
5
7
77
4
35
4
