DE: MONTAGEANLEITUNG
EN: ASSEMBLY INSTRUCTION
DE: ,,WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN
AUFBEWAHREN."
EN: IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
INamb010_DE
A91-233V00
150KG
Max 150kg

Advertisement

loading
Need help?

Need help?

Do you have a question about the A91-233V00 and is the answer not in the manual?

Questions and answers

Summary of Contents for HOMCOM A91-233V00

  • Page 1 INamb010_DE A91-233V00 DE: MONTAGEANLEITUNG 150KG EN: ASSEMBLY INSTRUCTION Max 150kg DE: ,,WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN." EN: IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
  • Page 6 Satz 1 stk Hauptrahmen 1 stk Verstrebungsstange 2 stk. Verbindungshebel 2 stk. Unteres Rohr 2 stk. M10 x 60 Schraube/Mutter/Unterlegscheiben 4 STK / 8 STK / 4 STK M8 x 110 Schraube/Mutter/Unterlegscheiben 2 STK / 4 STK / 2 STK M8 x 70 Schraube/Unterlegscheiben 3 STK / 3 STK M10 x 16 Schraube/Mutter/Unterlegscheiben...
  • Page 7 Montageanweisungen 1.Verbinden Sie das untere Rohr (5) mit der Verstre- bungsstange (3) mit Schrauben M10 x 60, Mut- tern und Unterlegscheiben (6). 2.Verbindungshebel (4) mit Schrauben M8 x 110, Mut- tern und Unterlegscheiben (7) an der Verstre- bungsstange (3) befesti- gen.
  • Page 8 3. Den Hauptrahmen (2) mit den M10 x 16 Schrau- ben und den Unterlegschei- ben (9) an der Verstre- bungsstange (3) befesti- gen. 4. Verbinden Sie das Set (1) mit dem Hauptrahmen (2) mit Schrauben M8 x 70, Muttern und Unterlegschei- ben (8).
  • Page 9 IMPORTANT MESSAGE WARNING - PLEASE READ ADULT ASSEMBLY REQUIRED CHOKING HAZARD Small Parts. NOT for children under 3 years of age. WARNING: While every attempt is made to ensure the highest degree of protection in all equipment, we cannot guarantee freedom from injury. The user assumes all risks of injury due to use.
  • Page 10 -10-...
  • Page 11 -11-...
  • Page 12 -12-...
  • Page 13 Main frame Bracing bar 2pcs Union lever 2pcs Bottom tube 2pcs M10*60 screw /nut/ washers 4PCS/8PCS/4PCS M8*110 screw /nut/ washers 2PCS/4PCS/2PC M8*70 screw/washers 3PCS/3PCS M10*16 screw/nut/ washers 4pcs/8pcs/4pcs -13-...
  • Page 14 Assembly instructions 1.Connect bottom tube (5) to the bracing bar (3) using M10*60 screws, nuts and washers (6). 2.Connect the union lever (4) to the bracing bar (3) using M8*110 screws, nuts and washers (7). -14-...
  • Page 15 3. Connect main frame (2) to the bracing bar (3) using M10*16 screws and wash- ers (9). 4. Connect the set (1) to the main frame (2) using M8*70 screws, nuts and washers (8). -15-...

This manual is also suitable for:

A91-233v00bk
