Controls & Functions

LCD Display

Player Controls

PLAY MODE
indicates playback status, either
"play" (arrow) or "stop" (square)
VOLUME LEVEL
bar graph displays relative
volume level
ID3 TAG
displays name of track and other
identifying information
MENU
Used to enter MENU mode
Also used to select track
for "REPEAT 1" playback
Up/Down Scroll
Navigates up and down
through tracks in memory while
in MENU Mode
REPEAT MODE
displays continuous playback
mode selected (repeat all,
repeat shuffle, repeat one)
1
Int 128MB
VOL
Ext
Acoustic Elegance
HoldTracks
IntelliTouch
02:36/07:45
Track: 002/008
TRACK LENGTH
displays running time and
total length of selected track
TRACK PLAYING
displays current track
selected/playing
VOLUME
Increases and decreases
volume level
Forward/Backward Scroll
Navigates forward and backward
through tracks in memory while
in Playback Mode
3

SD CARD
indicates that an SD card is
present in the memory slot
MEMORY
displays amount of internal and
external memory in memory card slot
1GB
TOTAL TRACKS
displays total number
of tracks in memory
REPEAT MODE
Used to select repeat mode
(Repeat 1, Repeat all, Repeat all shuffle)
Also used to exit from MENU mode
PLAY/STOP
Used to begin and stop playback
Also used to store track, volume
and mode settings
