- Page 1 OHP 7500 User Manual On-Hold Plus 7500 Digital MP3 CD Autoload System With Analog Line Capability Before using this unit, please read these operating instructions carefully. Afterwards, keep them handy for future reference.
-
Page 2: Supplied Accessories
OHP 7500 User Manual OHP 7500 User Manual Supplied Accessories 4" handset cords Cordless phone Cordless phone Telephone Extension 6' Phone Line Cords adapter cable (male) adapter cable (female) Hold Music Activators (TEHMA) "T" Adapters USB Cable AC Adapter HoldTracks MP3 CD MessageStudio™... - Page 3 OHP 7500 User Manual OHP 7500 User Manual Set-up Connection to analog phone lines Combined Line Connection step Lines 1 & 2 are combined in one wall jack and lines 3 & 4 are combined in another wall jack Plug the supplied "T adapter" into any modular phone jack which services line 1 and 2.
-
Page 4: Usb Connection To Pc
OHP 7500 User Manual OHP 7500 User Manual Set-up USB Connection to PC USB cable Connect AC adapter to wall power outlet and connect power plug to the jack marked 12VDC. Plug USB cable (square socket) into the USB jack on the back panel of the player. - Page 5 OHP 7500 User Manual OHP 7500 User Manual Corded Phone Set-up Telephone Extension Hold Music Activators (TEHMA) For true "hold button activation" of on-hold audio, each phone extension requires a "hold music activator". Two activators have been included in your package.
-
Page 6: Cordless Telephone Connection
OHP 7500 User Manual OHP 7500 User Manual Cordless Phone Set-up Telephone Extension Hold Music Activators (TEHMA) For true "hold button activation" of on-hold audio, each cordless phone requires the use of a telephone headset (not included) in conjunction with a "hold music activator". Two hold music activators and headset adapter cables have been included in your package. -
Page 7: Controls And Functions
OHP 7500 User Manual OHP 7500 User Manual Controls & Functions LCD Display REPEAT MODE PLAY MODE SD CARD displays continuous playback indicates playback status, either indicates that an SD card is mode selected (repeat all, "play" (arrow) or "stop" (square) present in the memory slot repeat shuffle, repeat one) VOLUME LEVEL... -
Page 8: Operation
OHP 7500 User Manual OHP 7500 User Manual Operation Adding New Audio Using the CD Drive The OHP 7500 will read ordinary Audio CDs and MP3 encoded CDs. Each time you record a new CD, the audio content stored on the on-board memory will be erased and replaced with the new audio from the CD. - Page 9 OHP 7500 User Manual OHP 7500 User Manual Operation (cont'd) Adding New Tracks to the Player via USB (Win) Once connected via USB, the player will show up as two removable drives (i.e. Drive E & Drive F) in the MY COMPUTER window. The first drive will represent the on-board memory (128 MB).
-
Page 10: Playback Operation
OHP 7500 User Manual OHP 7500 User Manual Playback Operation Playback Playing Audio Stored in On-Board Memory or on SD Card By default, the unit is always in "playback" mode. When unit is playing, the LCD will display a running time and the icon will be shown on the LCD. - Page 11 Simply click on your choices, add a sentence or two of your own, and you’re done...it’s that easy. Your finished script can either be read by you or submitted to On-Hold Plus for professional voiceover of your custom messages by one of our certified production partners.
-
Page 12: Player Software
(using a mic hooked up to your PC sound card) or have messages professionally produced by On-Hold Plus or any other professional voice talent (see MessageStudio Writer on the previous page). When your production is finished, click the "EXPORT AS MP3"... -
Page 13: Specifications
OHP 7500 User Manual OHP 7500 User Manual Specifications General On-board memory - 128MB Maximum memory supported (SD) – 1GB Supported bit rates – 32–320kbps External memory slot – Secure Digital (SD) Memory Card Interface – USB 1.1 Playback modes – repeat one, repeat all, repeat all-shuffle Int 128MB Audio output mode –... -
Page 14: Limited Warranty
OHP 7500 User Manual OHP 7500 User Manual Warranty Limited Warranty IntelliTouch warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 3 years from date of original purchase in the United States. Should service be necessary under this warranty for any reason due to manufacturing defect during this 3-year period from date of original purchase, IntelliTouch will either repair the unit or replace it with a reconditioned unit at no charge. -
Page 15: Fcc Information
- direct sunlight. NO ADDITIONAL ROYALTIES ARE DUE TO ON-HOLD PLUS OR ANY OTHER THIRD-PARTY MUSIC LICENSING - excessive dust. AGENCY. - Page 16 800-839-7277 www.onholdplus.com On-Hold Plus and MessageStudio are registered trademarks of IntelliTouch Communications. © IntelliTouch Communications. All rights reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of IntelliTouch Communications.
