Summary of Contents for boso TM-2450
- Page 1 BOSCH boso a er +SOHN � � s TA R EN ISO 81060-2...
- Page 2 24h Blood Pressure Monitor boso TM-2450...
- Page 3 24h Blood Pressure Monitor boso TM-2450 New packaging concept Sustainable and clearly arranged...
- Page 4 24h Blood Pressure Monitor boso TM-2450 Cuffs New sizes. New design. Cuffs Can be washed off and is latex-free. Size M CA91 20 - 31 cm 259-4-400 S | M | M-right | L | XL Size M-right CA91R 20 - 31 cm...
- Page 5 24h Blood Pressure Monitor boso TM-2450 Varta Premium Batteries Varta Premium Charger 2100 mmAh / 600 measures Safety switch-off 4 charging slots The VARTA Recharge Recycled Batteries are made from 11% recycled material and combine the benefits of low self-discharge with environ-...
-
Page 6: Scope Of Delivery
24h Blood Pressure Monitor boso TM-2450 Scope of delivery 24-hr blood pressure monitor boso TM-2450 Transport case Battery charger 2 x battery packs with two batteries (one set already inserted into the device) Cuffs for adults (can be washed off, latex-free) - Size M (13 x 62 | 20 –... - Page 7 - Great wearing comfort thanks to the small and lightweight design with only 2 batteries 22,5% lighter - Extremely low noise level quieter - Ergonomic hip-bag including transport strap and belt compared to the previous model boso TM-2430 PC 2...
- Page 8 24h Blood Pressure Monitor boso TM-2450 Overview Device TM-2430 PC 2 TM-2450 Dimensions 72x27x100 mm 66x25x95 mm Weight 155 g 135 g Adapter socket Jack micro-USB Measurement storage Connection cable Jack to USB Micro-USB to USB Battery 3 pieces 2 pieces...
-
Page 9: Device Overview
24h Blood Pressure Monitor boso TM-2450 Device overview Cuff connection socket START/STOP button AUTO button (day/night button) Battery compartment Batterie compartment lid 2LR6 (AA) batteries Micro USB connection... - Page 10 24h Blood Pressure Monitor boso TM-2450 Function symbols on the measuring device START/STOP button START/STOP AUTO/ STOP AUTO/ AUTO button (day/night button) AUTO/ START/STOP AUTO/ Automatic mode active Sleep mode active Battery status display: 1. Battery charged 2. Battery partially charged 3.
- Page 11 24h Blood Pressure Monitor boso TM-2450 Tape Attaching the cuffs Air connection plug Place the cuff on the unclothed upper arm so that white marking the white marking lies on the arteria brachialis. 2–3 cm Cuff The cuff should lie roughly 2-3 cm above the elbow connection bend and should not be too tight.
- Page 12 24h Blood Pressure Monitor boso TM-2450 Start of the interval automation To start the automatic interval function, press and hold the black AUTO button with the display activated until “ ” appears in the blood pressure monitor display and is confirmed with a short signal tone (after approx. 5 seconds).
-
Page 13: Performing A Measurement
Automatic adjustment of the pumping level (only in automatic interval mode) The boso TM-2450 automatically pumps up to the required pressure level. If this pumping level is not sufficient, the device automatically pumps approx. 60 mmHG above the original pumping level. - Page 14 24h Blood Pressure Monitor boso TM-2450 Cancellation of the measurement To cancel the measurement, the white START/STOP button must be pressed on the boso TM-2450. If the measurement is to be taken at a later time a manual measurement can be taken using the...
- Page 15 (approx. 5 seconds). If the display is off, activate it by pressing any button. After that, connect the TM-2450 to a computer with a PC-connection cable. Transfer the data according to the boso profil-manager XD instruction manual.
-
Page 16: Replacing The Batteries
Step 2 To prevent any data loss, the data stored on the boso TM-2450 are buffered Remove empty using an internal battery. These batteries are automatically charged via the batteries battery pack. -
Page 17: Charging The Batteries
24h Blood Pressure Monitor boso TM-2450 Charging the batteries Longer storage of the device Insert the rechargeable batteries into the charger and plug it If the device is not used for a longer period of time (4 weeks or more), remove into the power socket. -
Page 18: Important Note
If the internal battery’s power supply is interrupted, In addition to the two rechargeable batteries required for the power the settings of the boso TM-2450 will be lost after approx. 10 days. supply, the boso TM-2450 also contains an internal battery to save the measurement data and the program settings in the device. -
Page 19: Error Codes
24h Blood Pressure Monitor boso TM-2450 Error codes Error code Cause Remedy 0:00 Time sets to 0:00 when battery is replaced Device must be reprogrammed. E03 / E90 Zero point adjustment not possible Deflate cuff completely. Empty battery Charge or replace batteries. -
Page 20: Cleaning And Disinfection
24h Blood Pressure Monitor boso TM-2450 Cleaning and disinfection To clean the boso TM-2450 and the cuff, please use a soft cloth that may be moistened with soapy water. For the protective covers: machine wash at max. 60 °C. Never use solvents, benzine, spirits or abrasive cleaners for cleaning! For disinfection by wiping (exposure time at least 5 minutes) the device, we recommend the disinfectant Antifect Liquid (Schülke &... - Page 21 ABPM Guidelines The boso TM-2450 and the boso profil-manager XD software meet the practical ABPM guidelines of the European Society of Hypertension in the following points: boso TM-2450 (measuring device) Clinically validated according to DIN EN ISO 81060-2 – precise blood pressure measurement on the upper arm...
- Page 22 ABPM Guidelines The boso TM-2450 and the boso profil-manager XD software meet the practical ABPM guidelines of the European Society of Hypertension in the following points: PROFIL-MANAGER boso profil-manager XD (ABPM-Software) V 6.0 • boso TM-2450 • boso TM-2430 • boso ABI-system 100 •...
-
Page 23: Start Screen
profil-manager XD Start screen New design New logo... - Page 24 XD – boso TM-2450 application Patient overview...
-
Page 25: Measured Data
XD – boso TM-2450 application Measured data Device can be initialised using the unique patient number (simple workflow for devices operated in parallel, e.g. in a hospital) - Page 26 XD – boso TM-2450 application Profile Sys/Dia Overlay of two curves (SYS, DIA, PULS, MAP, PP) possible (easy identification of successful treatment), still compatible with boso TM-2430 PC2...
- Page 27 XD – boso TM-2450 application Statistics Statistical evaluation incl. calculation of the morning blood pressure rise (MBPS)
- Page 28 XD – boso TM-2450 application Easy mixed operation of boso TM-2430 PC2 and boso TM-2450 possible. The interface settings were adapted accordingly for this:...
- Page 29 XD – boso TM-2450 application Definable maximum pressure (specifically for sensitive patients)
- Page 30 XD – ABI application Measured data...
-
Page 31: Good To Know
Blood Pressure Variability with GOOD TO KNOW Atmospheric pressure / Temperature Atmospheric pressure Recent studies demonstrate an influence of meteorological factors, such as atmospheric pressure, on blood pressure behaviour. Source: Stergiou GS, Myrsilidi A, Kollias A, Destounis A, Roussias L, Kalogeropoulos P. Seasonal variation in meteorological parameters and office, ambulatory and home blood pressure: predicting fac- tors and clinical implications. Hypertens Res. 2015;... - Page 32 BOSCH + SOHN GmbH u. Co. KG Bahnhofstraße 64 | 72417 Jungingen, Germany | T +49 (0) 7477 9275-0 | F +49 (0) 7477 1021 E zentrale@boso.de | boso.de Subject to technical changes | No liability for printing errors | 02/2021...
