Installation of the water inlet or outlet
pipes:
The specification of the water inlet and outlet
thread is G3/4" (internal
be heat-resistant and durable.
Installation of the pipe
valve:
The spec of the valve
G3/4" (internal thread).
must be confirmed that the drainpipe outlet is
exposed to the air. When the flexible
is joined to the pressure
valve, you must ensure
drainpipe is pointing downwards and exposed in
the air. At least pull every 6 months the handle of the
safety valve in order to remove the sediment of
Calcium Carbonate.

4.3 Wire connection

The wire should be placed orderly, reasonable and
in accordance with national
Appliances should be installed in accordance with
national wiring rules. The unit is equipped with
the power plug line for connected to the power
unit.

4.4 Storage and transportation

Generally, it's better to use a container to transport hot
water heat pumps and store them in a suitable and dry
place. For short distance carrying, please be careful
and the maximum inclination is no more than 60°.
During transportation and
temperature should be from 0℃ ~ 40℃.The storage of
equipment should be
manufacturer's instructions.
Transport by forklift
When using forklift to carry the unit which must have
a pallet, the operator should try best to keep the
height of forklift at a low level. Because the top
part is heavier, the operator needs to take measures
to prevent overturning. To avoid any damages, the
unit must stand on a flat place.
Transport for installation
When transporting for installation, the bottom of unit
needs to be added with pallet and use a rope or belt
to fix it well. In manual
transportation, the inclination is no more than 60° as
the following picture shows.

4.5 Disposal

Demolition and disposal of the unit is under the
exclusive liability and responsibility of the owner who
must do so in accordance with the laws in force in the
country of installation pertaining to safety, respect
and protection of the environment.
At the end of its service life, the product must not be
disposed of as household waste.
thread). Pipes must
for the safety
connecting thread is
After installation, it
drainpipe
relief orifice of this
that the flexible
wiring rules.
storage, the ambient
in accordance with the
carrying or forklift
Please ensure the device
The drainage outlet
high, please pay attention
good insulation to drainage pipe to prevent pipe
freezing in winter, which
conditions. The discharge
may be higher than expected and please take care to
avoid burns.
When the unit is connected to the circuit, there must
be circuit breaker or protector for the unit circuit.
If the power wire has been damaged, the new wire must
have the same certification as the old one, the spare
one should be ordered to the manufacturer.
If the inclination unavoidably exceeds 60°, the unit must
be kept at vertical status for at least 1 hour before
performing any action. In order to avoid scratch or
deformation of the unit surface, apply guard boards
to the contacting surface. This unit is heavy, it need to
be carried by two or more persons, otherwise it might
cause injury and damage.
It can be taken to designated separate waste collection
centres run by local administrations or to dealers who
offer this service.
Disposing of the product as sorted waste avoids any
negative consequences on the environment and health
deriving from unsuitable disposal and it recovers the
materials that the stove is composed of in order to save
considerable energy and resources.
is with no jam.
water temperature is
to it. Please make
may lead to unsafe
water temperature
