2.2 Dimensions

Hot water outlet
Magnesium anode
Circulation
water inlet
Cold
water inlet
APHPDHW300S
[mm]
1905
A
1467
B
1208
C
1088
D
576
E
128
F
G
640
Φ
H
150
Φ
I
226
J
531
K
1026
G
APHPDHW200
[mm]
1600
1162
Hot water outlet:
903
783
-
Cold water inlet: G3/4"; Drainage: G3/4"
128
640
Φ
150
Φ
-
-
-
H
Safety valve
Solar water
inlet
Temp.Sensor
Solar water
outlet
Drainage
CONNECTIONS ["]
-
-
G3/4"; Safety valve: G3/4"
Magnesium anode: G3/4"
Circulation water inlet
-
-
Solar water outlet: G3/4"
Temp.Sensor: G3/4"
Solar water inlet: G3/4"
