Argo AGHP081PH User Manual

Air/water heat pump monobloc
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
MODELS:
AGHP081PH
AGHP121PH
AGHP161PH
AGHP123PH
AGHP163PH
Thank you for choosing an Argoclima heat pump. Please read this manual carefully before using the unit and retain
it for future reference.
Air/water Heat pump
Monobloc
V 09/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGHP081PH and is the answer not in the manual?

Questions and answers

Related Manuals for Argo AGHP081PH

Summary of Contents for Argo AGHP081PH

  • Page 1 Air/water Heat pump Monobloc User Manual MODELS: AGHP081PH AGHP121PH AGHP161PH AGHP123PH AGHP163PH Thank you for choosing an Argoclima heat pump. Please read this manual carefully before using the unit and retain it for future reference. V 09/21...
  • Page 2 Notices Thank you for selecting Argo product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve expected operating effect, we hereby instruct as below: (1) This instruction manual is a universal manual, some functions are only applicable to particular product.

  • Page 3: Table Of Contents

    Contents Safety Notices (Please be sure to abide) ........................1     General ..................................2     Menu Page ................................2       Backlight ................................3     Operation Instructions ..............................4     ON/OFF ................................4   Function Setting ..............................4  ...

  • Page 5: Safety Notices (Please Be Sure To Abide)

    Operation Instructions Safety Notices (Please be sure to abide) Do not install the control where it is damp or exposed to direct sunlight. Once the air conditioning unit is installed where possibly subject to electromagnetic interference, shielded twisted pairs should be used as signal lines and other communication lines. Be sure communication lines are wired to the correct ports, or normal communication would fail.

  • Page 6: General

    Operation Instructions 1. General (This picture is just for reference) This display panel uses the capacitor touch screen for input operation. The valid touching area indicates the black rectangle when the display panel lights off. This control panel is of high sensitivity and will response to unexpected click by the foreign matters on the display panel.

  • Page 7: Backlight

    Operation Instructions Icon Description Icon Description Heating Floor commissioning Cooling Floor commissioning error Hot water Card out Heating + Hot water Defrosting Hot water + Heating Holiday Cooling + Hot water WiFi Hot water + Cooling Back Quiet Menu page Sanitation Save Emergency...

  • Page 8: Operation Instructions

    Operation Instructions 2. Operation Instructions 2.1 ON/OFF [Operation Instructions] At the menu page, by touching ON/OFF, the unit will be turned on/off. [Notes]  It is defaulted to be OFF upon first power-on.  ON/OFF operation will be memorized by setting “On/Off Memory” to be “On” at the “GENERAL.” setting page. That is, in case of power failure the unit will resume running upon power recovery.
  • Page 9 Operation Instructions Item Range Default Remarks Cool When the water tank is unavailable, then only Heat “Cool” and “Heat” are available. Mode Hot water Heat For the heating only unit, only "Heat" mode, “Hot Cool + Hot water water”, and “Heat + hot water” are available. Heat + Hot water When the water tank is unavailable, it will be Fast hot water...
  • Page 10 Operation Instructions [Notes]  The default mode is “Heat” upon first power-on.  Mode setting is allowed only when the unit is turned off, otherwise a dialog box will pop up, saying “Please turn off the system first!”  When the water tank is unavailable, only 'Heat” and “Cool” mode are allowed. ...
  • Page 11 Operation Instructions 2.2.5 Quiet Mode [Operation Instructions] At the function setting page with the unit turned off, by touching “Quiet mode”, there will be a choice box, where “Quiet mode” can be set to “On”, “Off”, or “Timer”. When it is set to “Timer”, it is also required to set the “Start timer” and “End timer”. Unless otherwise stated, otherwise time setting is all the same.
  • Page 12 Operation Instructions 2.2.7 Weekly Timer [Operation Instructions] 1. At the function setting page, by touching “Weekly timer”, it will go to the setting page as shown below. 2. At the “Weekly timer” setting page, as shown in the figure below, the weekly timer can be set to “On” or “Off”. 3.
  • Page 13 Operation Instructions [Notes]  This setting can be activated only when “Water tank” is set to “With”. When “Water tank” is set to “Without”, this function will be deactivated.  This setting can be done no matter if the unit is turned on or off. ...
  • Page 14 Operation Instructions [Notes]  When “Clock timer” has been set and “Hot water” mode is involved, in this case, if “Water tank” is changed to “Without”, “Hot water” will be automatically switched to “Heat”, and “Cool/Heat + Hot water” will be switched to “Cool/Heat”.
  • Page 15 Operation Instructions [Notes]  When “Weekly timer”, “Preset mode”, “Clock timer” “Temp. timer” have been set at the same time, then the latter takes the priority.  This setting is valid only when the unit is turned on.  Under the “Cool” or “Cool + Hot water” mode, the setting targets at “WT-Cool”; while under the “Heat” or “Heat + Hot water”...
  • Page 16 Operation Instructions  When “Holiday mode” has been activated, the controller will automatically deactivate the “Weekly timer” and “Preset mode” and “Clock timer” and “Temp.timer”.  Under the “Holiday mode”, when the unit is under the control of room temperature, the set point (room temperature for heating) should be set to 10°C;...

  • Page 17: User Parameter Setting

    Operation Instructions 2.2.15 Error Reset [Operation Instructions] At the function setting page, by touching “Error reset”, a choice box will pop up, where by touching “OK” the error will be reset and by touching “Cancel” the error will not be reset. [Notes] ...

  • Page 18: Commissioning Parameter Setting

    Operation Instructions [Notes] For parameters with different defaults under different conditions, when conditions changes, the default value also will change as the corresponding condition changes. All parameters will be memorized upon power failure. Parameter Setting Displayed Name Range Range Full Name Default Remarks (°C)
  • Page 19 Operation Instructions [Notes] At the commissioning parameter setting page, when the state of any function changes, the system will automatically save this change and this change will remain upon power failure. Do not modify any commissioning parameter except the approved qualified servicemen, as it would give birth to adverse effects to the unit.
  • Page 20 Operation Instructions Commissioning Parameters Setting Full Name Display Name Range Default Remark T-HP max T-HP max 40~55 °C 104~131°C 50/122°C 3min [2-way valve Off] Cool run time Cool run time 1~10min 5min [2-way valve On] 3min [2-way valve Off] Heat run time Heat run time 1~10min 5min...
  • Page 21 Operation Instructions 2.4.2 2-Way valve [Operation Instructions] At the commissioning parameter setting page, by touching “Cool 2-Way valve” or “Heat 2-Way valve”, the control panel will access to the corresponding setting page. [Notes]  Under “Cool”, or “Cool + Hot water” mode, “Cool 2-Way valve” will decide the status of the 2-way valve; while under “Heat”...
  • Page 22 Operation Instructions [Notes]  When “Water tank” is set to “Without”, the “Air + hot water” mode is unavailable.  When “Floor debug” and “Emergen.mode” have activated, function of the thermostat will be invalid.  When “Thermostat” is set to “Air” or “Air + hot water”, timer function will be disabled and the unit will run based on the mode set by the thermostat.
  • Page 23 Operation Instructions During heating operation, the water pump of the heat pump unit will be stopped; however, during standby status, the water pump will start but the other thermal will stop. Under the “Hot water” mode, the 3-way valve will switch to the water tank, the water pump of the heat pump will always stop but the other thermal will start.
  • Page 24 Operation Instructions  Only when “Remote sensor” is set to “With”, the “Ctrl. State” can be set to “T-room”. 2.4.9 Air Removal [Operation Instructions] At the commissioning parameter setting page, by touching “Air removal”, the control panel will access to the corresponding setting page, where it can be set to “On”...
  • Page 25 Operation Instructions  When this function has been activated, “On/Off” operation will be deactivated. By pressing On/Off , a window will pop up, saying “Please disable the floor debug!".  When “Floor debug” has been activated; “Weekly timer”, “Clock Timer”, “Temp timer” and “Preset mode” will be deactivated.
  • Page 26 Operation Instructions 2.4.14 Current Limit [Operation Instructions] 1. At the commissioning parameter setting page, by touching “Current limit”, it can be set to “On” or “Off”. 2. When it is set to “On”, it is able to set the limited current value. 3.
  • Page 27 Operation Instructions  This setting can be done only when the unit is off.  This function can be memorized upon power failure. 2.4.18 Parameter Setting [Operation Instructions] At the commissioning parameter setting page, by touching “PARAM.”, it will access to the pages as shown below. Page of Commissioning Parameters At this page, select the desired option and then go to the corresponding page.

  • Page 28: Viewing

    Operation Instructions 2.5 Viewing [Operation Instructions] 1. At the menu page, by touching “VIEW”, the control panel will go to the sub-menu page as shown in the figure below. VIEW Page 2.5.1 Status Viewing [Operation Instructions] 1. At the “VIEW” page, by touching “Status”, it is able to view status of the unit, as shown in the figure below. Status View Page Viewable Status Full Name...
  • Page 29 Operation Instructions Status of other thermal source Other thermal On/Off Status of the 2-way valve 2-way valve On/Off Status of antifreeze HP-Antifree On/Off Status of the door guard Gate-Ctrl. Card in/Card out Status of the 4-way valve 4-way valve On/Off Status of disinfection Disinfection Off/Running/Done/Fail...
  • Page 30 Operation Instructions Error View Page [Notes]  The control panel can display real-time errors. And at these pages, all errors will be listed here.  Each page displays at most 5 pieces of errors. Others can be viewed by touching the page turning keys. Error List Full Name Displayed Name...
  • Page 31 Operation Instructions Communication error with the drive board Driver Com. Driver resetting Driver reset Compressor overcurrent Com. over-cur. Current sensing circuit error or current sensor error Current sen. Desynchronization Desynchronize Radiator or IPM or PFC over-temperature Overtemp.-mod. Radiator or IPM or PFC temperature sensor error T-mod.

  • Page 32: General Setting

    Operation Instructions 2.5.5 Version Viewing [Operation Instructions] At the “VIEW” page, by touching “Version”, the control panel will go to the version view page, where it is able to view both the program version and protocol version. 2.6 General Setting [Operation Instructions] 1.

  • Page 33: Intelligent Control

    Operation Instructions [Operation Instructions] 1. At the “GENERAL” setting page, by touching “Time&Data”, it will go to the setting page as shown in the figure below. Time&Data Page 2. The mouse roller can change the date and time value. After it, by touching the “Save” icon, this setting will be saved and directly displayed;...

  • Page 34: Install Ewpe Smart App

    Operation Instructions 3.1 Install Ewpe Smart APP [Operation Instructions] 1. Scan the following QR code with your smart phone to download and install Ewpe Smart APP directly. 2. Open Ewpe Smart APP and click “Sign up” for registration. 3. Except sign in in the prompt interface, you can also enter the homepage and click the profile picture at the left upper corner to sign in.
  • Page 35 Operation Instructions 4. Click "+" at the right upper corner of homepage to add device.
  • Page 36 Operation Instructions After selecting “AC”, you can select different reset tools according to actual situation. The APP interface will provide relevant operation instructions for different tools.
  • Page 37 Operation Instructions Reset the air conditioner (refer to the operation instructions in APP interface) and click “Next” to add home appliance automatically (Wi-Fi password shall be input). Or after setting and energizing the air conditioner, click “Add appliance manually” at the right upper corner to select the wireless network for controlling the device. Then confirm family Wi-Fi and arrange configuration.

  • Page 38: Setting Of Main Functions

    3.2 Setting of Main Functions 1. Set mode and temperature.

  • Page 39: Setting Of Other Functions

    2. Click Func at the left lower corner in device operation interface to enter advanced settings. 3.3 Setting of Other Functions Click the profile picture at the left upper corner of homepage and set each function in the following menu.
  • Page 40 3.3.1 Home management Click “Home management” to create or manage family. You can also add family members according to the registered account.
  • Page 41 3.3.2 Help Click “Help" and view the operation instructions of the APP. 3.3.3 Feedback Click “Feedback” to submit feedback.
  • Page 42 www.argoclima.com...

This manual is also suitable for:

Aghp121phAghp161phAghp123phAghp163ph

Table of Contents
