Figure 77. IBM Elastic Storage System 3200 power module status LED
The following table describes bi-color power module status LED behavior.
Table 25. IBM Elastic Storage System 3200 power module status LED
Green Color
ON
OFF
OFF
OFF
Flashing 1.0 Hz
OFF

Server canister operator panel LEDs

The IBM Elastic Storage System 3200 server canister consists three status LEDs on the bottom of the
server canister operator panel. In addition, two self-driven Ethernet port LEDs are located to the right of
the server canister status LEDs. These LEDs are used to monitor the status of server canister and Ethernet
ports.
The following figure shows server canister operator panel.
Amber Color
OFF
OFF
ON
Flashing 1.0 Hz
OFF
ON transition to OFF
Chapter 5. Monitoring the system using LEDs 87
Behavior
Power module ON and OK.
No AC power to all power
modules.
A power module critical event is
causing shutdown.
Indicates high temperature, hot
spot temperature, slow fan, high
current, or high-power warning in
power module. In this condition,
power module continues to
operate.
Power module is in standby state.
AC present, 12 V standby ON.
Power module is in cold standby
state or always standby state.
Indicates that the power cord is
unplugged.
