Figure 76. IBM Elastic Storage System 3200 fan LEDs
The following table describes the behavior of IBM Elastic Storage System 3200 fan LEDs.
Table 24. IBM Elastic Storage System 3200 fan LEDs
Amber
OFF
ON
Power module LEDs
These LEDs are used to monitor power modules of the IBM Elastic Storage System 3200.
The power module status LEDs are visible from the rear of the enclosure. The following figure provides a
close view of the power module status LED.
86 IBM Elastic Storage System 3200: Hardware Planning and Installation Guide
Green
ON
ON
Behavior
The fan module is functioning
properly.
A fan module fault is detected.
