- Page 1 RECHARGEABLE INFLATOR MODEL NO: RI150LI PART NO: 7640291 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC10/22...
-
Page 2: Product Specifications
INTRODUCTION Thank you for purchasing this CLARKE Tyre Inflator. The RI150Li can be used for inflating car, motorcycle and bicycle tyres, inflatable sports balls and other inflatables. The compressor is not waterproof and should not be used in any wet applications. -
Page 3: General Safety Warnings
GENERAL SAFETY WARNINGS WARNING: WHEN USING BATTERY POWERED TOOLS, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY. PLEASE READ ALL THE SAFETY AND OPERATING INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT PERSONAL SAFETY 1. -
Page 4: Safety Symbols
7. NEVER use this product if it appears defective or is operating abnormally: If the tyre inflator operates unusually or makes strange noises, switch off immediately. Arrange repairs by your CLARKE dealer. 8. NEVER attempt any repairs yourself. If you have a technical problem contact your local CLARKE dealer. - Page 5 OVERVIEW UNPACKING After removing the tyre inflator from its packaging, check that it has not been damaged in transit. Report any damage immediately to the CLARKE dealer where the item was purchased. ATTACHMENTS Supplied with the tyre inflator are three adaptors for different uses. These are provided to inflate car tyres, sports balls, air beds, small inflatables and bicycle tyres etc.
-
Page 6: Operation
OPERATION THE DISPLAY PANEL The display panel will illuminate and display the following: • Measured pressure value (1) • Battery level (2) • Unit of measurement (3) • Progress bar (4) • Preset pressure value (5) • Operating mode (6) CHARGE AND DISCHARGE MODES Connect the USB-C cable to an adaptor (not supplied) to charge the device. -
Page 7: Using The Pushbuttons
• The unit will automatically shut down when the battery becomes low and will stop charging when fully charged. SELECTING DIFFERENT MODES A short press of the mode button can be used for the following different applications. Car mode; Default pressure: 35psi Adjusting range;-0-65 psi Motorcycle mode;... -
Page 8: Pressure Calibration
PRESSURE DETECTION AND INFLATION A short press on the power button will start inflation. A second short press will stop inflation. When the pressure reaches the pre-set pressure value the pump will automatically stop. After turning on, connect the hose to the object to be measured. -
Page 9: Tyre Inflation
Your tyre inflator has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the tyre inflator to your local CLARKE dealer. Store the tyre inflator in a dry location. -
Page 10: Component Parts
COMPONENT PARTS Description Description Housing - back Motor Battery Support Support Housing-bottom Housing-top Silicone pad Cylinder Motor support Support Battery support Sealing ring Housing-front Silicone pad Lens Pressure-sensitive film Switch Pressure sensor Hose Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Declarations Of Conformity
DECLARATIONS OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
