O P E R A T I N G I N S T R U C T I O N S
ReLy OSSD4
Safety relay

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ReLy OSSD4 and is the answer not in the manual?

Questions and answers

Related Manuals for SICK ReLy OSSD4

Summary of Contents for SICK ReLy OSSD4

  • Page 1 O P E R A T I N G I N S T R U C T I O N S ReLy OSSD4 Safety relay...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Disassembly....................Module exchange..................Electrical installation................ 19 Device connection..................8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 4 List of figures..................32 List of tables..................33 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 5: About This Document

    The following symbols and conventions are used in this document: 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 6 Ö The LED is flashing. O The LED is illuminated continuously. O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 7: Safety Information

    At altitudes of over 4,000 m above sea level • In explosion-hazardous areas 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 8: Requirements For The Qualification Of Personnel

    For maintenance, you must be able to assess if the machine is operating safely. O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK...

  • Page 9: Product Description

    Feedback current path (for use as external device monitoring, not safe) • Signaling current path (non-safety) 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 10: Compatible Sensor Types

    Further topics • "Status indicator (LED)", page 22 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 11: Project Planning

    Sufficient distance must be kept for the connected cables before the module (front side). 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 12: Electrical Integration

    The electrical voltage supply has a suitable electrical fuse. Further topics • "Data sheet", page 24 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 13: Enabling Current Paths

    (13, 14, 23, 24, 33, 34, 43, 44) switch. The signaling current path is not safe. 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 14: Connection Diagrams

    After exceptional events, such as after manipulation has been detected, after modification of the machine, or after replacing components O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK...

  • Page 15: Planning The Regular Thorough Check

    7, page 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 16: Mounting

    Attach the end clamps on the mounting rail on the left and right of the module. Figure 6: Mounting the end clamps O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK...

  • Page 17: Disassembly

    Figure 8: Removing the plug 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 18 ✓ The front connector engages with an audible click. O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 19: Electrical Installation

    Enabling current path 23, 24 Enabling current path 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 20 "Data sheet", page 24 • "Electrical integration", page 12 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 21: Commissioning

    Carry out the checks specified in the test plan of the manufacturer of the machine and the operating entity. 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 22: Troubleshooting

    Voltage on I1 O Green Voltage on I2 O Green O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 23: Decommissioning

    SICK will be glad to help you dispose of these devices on request. 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 24: Technical Data

    Table 8: Mechanical data Weight 180 g Mounting Mounting rail (IEC 60715) O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...
  • Page 25 11, page 28 AC switching capacity 0.1 VA … 1,500 VA 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 26 Switching voltage 10 V DC … 30 V DC 10 V AC … 30 V AC O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...
  • Page 27 At altitudes up to 2,000 m above sea level –25 °C … +55 °C (UL/CSA: surrounding air temperature) 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 28 Figure 12: Electrical endurance of contacts 13/14, 23/24, 33/34 and 43/44 Switching operations × 1,000 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK...

  • Page 29: Dimensional Drawings

    Figure 14: Internal circuitry (hardware version 1.02.0 and above) 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 30: Ordering Information

    ReLy OSSD4 Opto-electronic protec‐ RLY3-OSSD400 1099971 tive devices O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 31: Annex

    • EMC DIRECTIVE 2014/30/EU • MACHINERY DIRECTIVE 2006/42/EC 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...

  • Page 32: List Of Figures

    13. Dimensional drawing....................29 14. Internal circuitry (hardware version 1.02.0 and above)...........29 O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...

  • Page 33: List Of Tables

    14. Feedback current path (61, 62)................27 15. Ambient data.......................27 16. Ordering information....................30 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 34 LIST OF TABLES O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 8023931/1FH0/2022-10-27 | SICK Subject to change without notice...
  • Page 35 LIST OF TABLES 8023931/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy OSSD4 Subject to change without notice...
  • Page 36 Phone +7 495 283 09 90 E-Mail info@sick.com E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG  |  Waldkirch  |  Germany  |  www.sick.com...
