Page 1 SERVICE MANUAL Front axle system Steiger® 370 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 370 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 2 4B [JEEZ00000FF314001 - ], Steiger® 620 Powershift, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 620 Quadtrac® Powershift, TIER 4B [JEEZ00000FF314001 - ] 48193194 12/10/2017...
Page 3 48193194 12/10/2017...
Page 4 Contents Front axle system - 25 [25.100] Powered front axle ..............25.1 [25.102] Front bevel gear set and differential .
Page 5 Front axle system - 25 Powered front axle - 100 Steiger® 370 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 370 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 6 TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® CVT, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 7 48193194 12/10/2017 25.1 [25.100] / 1...
Page 8 Contents Front axle system - 25 Powered front axle - 100 TECHNICAL DATA Powered front axle Torque ..................3 Special tools - 400 Series axles (*) .
Page 9 Front axle system - Powered front axle Powered front axle - Torque 300 Series axles Item Metric value U.S. value Wheel to hub bolts 755 – 850 N·m 555 – 625 lb ft Axle to frame mounting bolts (lubed) 665 – 745 N·m 490 –...
Page 10 Front axle system - Powered front axle Item Metric value U.S. value Bevel pinion yoke retaining bolt 377 – 677 N·m 278 – 499 lb ft Port block retaining bolts (if equipped) 89 – 100 N·m 65 – 74 lb ft 500 Series Quadtrac axles Item Metric value...
Page 11 Front axle system - Powered front axle 600 Series Quadtrac axles Item Metric value U.S. value 712 – 793 N·m Axle to frame mounting bolts (lubed) 525 – 585 lb ft Driveshaft mounting bolts 96 – 110 N·m 70 – 80 lb ft Wedge block mounting bolts 13 –...
Page 12 Front axle system - Powered front axle RCPH10FWD450ABJ RCPH10FWD453ABJ CAS2663 Final drive housing bearing cup CAS2666 Axle shaft/pinion bearing cone installer remover/installer RCPH10FWD328ABJ RCPH10FWD468ABJ CAS2750 Axle shaft outer bearing installer CAS2667 CNH299041 Final drive housing inner bearing cup remover RCPH10FWD452ABJ RCPH10FWD470ABJ 380002920 Axle shaft lifting eye CAS2668 CNH299051 Axle shaft outer bearing press...
Page 13 Front axle system - Powered front axle RCPH10FWD451ABJ RCPH10FWD329ABJ CNH299042 Brake carrier bearing cone installer CAS2674 Sun gear torque adapter RCPH10FWD455ABJ 380002851 Axle shaft remover bar CAS2729 Planetary gear pilot tube RCPH10FWD456ABJ RCPH10FWD445ABJ CAS2507 Axle seal installer CAS2676 Planetary assembly lifting hook 48193194 12/10/2017 25.1 [25.100] / 7...
Page 14 Front axle system - Powered front axle RCPH10FWD467ABJ RCPH10FWD457ABJ CAS2692 Bearing heater adapter CAS1675-2 Pinion depth gauge block RCPH10FWD318ABJ RCPH10FWD317ABJ CNH299138 Driver anvil CNH299079 Alignment stud set RCPH10FWD330ABJ RCPH10FWD319ABJ CAS2748 Axle wrench CNH299137 Alignment stud set 48193194 12/10/2017 25.1 [25.100] / 8...
Page 15 Front axle system - Powered front axle RCPH10FWD458ABJ RCPH10FWD449ABJ CNH299077 Short bearing driver handle CAS2501 Bearing cup installer RCPH10FWD447ABJ RCPH10FWD462ABJ 380002921 Lifting eye hook CAS2505 Brake disc aligner RCPH10FWD459ABJ RCPH10FWD448ABJ CAS2496 Alignment stud set CAS2506 Pinion depth gauge arbor 48193194 12/10/2017 25.1 [25.100] / 9...
Page 16 Front axle system - Powered front axle RCPH10FWD460ABJ RCPH10FWD465ABJ CNH299083 Bearing cup installer CAS2503 Bevel pinion seal installer RCPH10FWD463ABJ RCPH10FWD464ABJ CAS2511 Pinion bearing preload compressor CAS2516 Bearing installer RCPH10FWD880AAJ RCPH10FWD466ABJ CNH299134 Gear/bearing heater CNH299075 Lifting hook 48193194 12/10/2017 25.1 [25.100] / 10...
Page 17 Front axle system - Powered front axle RCPH10FWD326ABJ RCPH10FWD327ABJ CNH299141 Differential support bracket CNH299140 Differential lifting bracket RCPH10FWD469ABJ RCPH10FWD444ABJ CAS2510 Adapter plate CAS2405 Long bearing driver handle Powered front axle - Special tools - 500 and 600 Series axles Steiger® 470 Quadtrac® Steiger®...
Page 18 Front axle system - Powered front axle RCPH10FWD598AAJ CAS2695 Jack stand adapter post and dolly cart 500 Series axles RCPH10FWD857AAJ RCPH10FWD854AAJ CAS2663 Trumpet housing bearing cup remover-installer CAS2666 Axle shaft/pinion bearing cone installer RCPH10FWD858AAJ RCPH10FWD855AAJ CNH299050 Pinion inner bearing cup installer CAS2667 CNH299041 Trumpet housing inner bearing cup remover RCPH10FWD856AAJ...
Page 19 Front axle system - Powered front axle RCPH10FWD863AAJ RCPH10FWD860AAJ CNH299042 Brake carrier bearing cone installer CAS2674 Sun gear torque adapter RCPH10FWD864AAJ 380002851 Axle shaft remover bar CAS2675 Brake assembly alignment stud set RCPH10FWD865AAJ RCPH10FWD862AAJ CAS2673 Pinion seal installer CAS2676 Planetary assembly lifting hook 48193194 12/10/2017 25.1 [25.100] / 13...
Page 20 Front axle system - Powered front axle RCPH10FWD866AAJ RCPH10FWD869AAJ CAS2692 Bearing heater adapter CAS1675-2 Pinion depth gauge block RCPH10FWD870AAJ RCPH10FWD867AAJ CNH299048 Planetary gear pilot sleeve CNH299079 Alignment stud set RCPH10FWD871AAJ RCPH10FWD868AAJ CAS2507 Axle seal installer CAS2405 Long bearing driver handle 48193194 12/10/2017 25.1 [25.100] / 14...
Page 21 Front axle system - Powered front axle RCPH10FWD872AAJ RCPH10FWD875AAJ CNH299077 Short bearing driver handle CAS2501 Bearing cup installer RCPH10FWD876AAJ RCPH10FWD873AAJ 380002921 Lifting eye bolt CAS2505 Brake disc aligner RCPH10FWD874AAJ RCPH10FWD877AAJ CAS2496 Alignment stud set CAS2506 Pinion depth gauge arbor RCPH10FWD881AAJ RCPH10FWD878AAJ CAS2510 Bearing cup remover/adapter plate CAS2514-2 Axle shaft outer bearing installer...
Page 22 Front axle system - Powered front axle RCPH10FWD879AAJ RCPH10FWD882AAJ CAS2511 Pinion bearing preload compressor CAS2516 Bearing installer RCPH10FWD883AAJ RCPH10FWD880AAJ CNH299134 Gear/bearing heater CNH299075 Lifting hook 500 Series Quadtrac axles RCPH10FWD855AAJ RCPH10FWD860AAJ CNH299050 Pinion inner bearing cup installer. CNH299042 Bearing cone installer 48193194 12/10/2017 25.1 [25.100] / 16...
Page 23 Front axle system - Powered front axle RCPH10FWD858AAJ RCPH10FWD878AAJ CAS2510 Adapter plate CAS2667 Final drive housing inner bearing cup remover RCPH10FWD857AAJ RCPH10FWD862AAJ CAS2666 Axle shaft pinion bearing cone remover CAS2673 Pinion seal installer RCPH10FWD864AAJ RCPH10FWD128ABJ CAS2675 Brake assembly alignment stud set 380002570 Axle nut spanner wrench 48193194 12/10/2017 25.1 [25.100] / 17...
Page 24 Front axle system - Powered front axle RCPH10FWD865AAJ RCPH10FWD129ABJ CAS2676 Planetary assembly lifting hook CAS2729 Planetary gear pilot sleeve RCPH10FWD871AAJ RCPH10FWD869AAJ CAS1675-2 Pinion depth gauge block CAS2405 Long bearing driver handle RCPH10FWD872AAJ RCPH10FWD870AAJ 380000884 Alignment stud set CNH299077 Short bearing driver handle RCPH10FWD874AAJ RCPH10FWD873AAJ 380002921 Lifting eye bolt...
Page 25 Front axle system - Powered front axle RCPH10FWD858AAJ RCPH10FWD877AAJ CNH299083 Bearing cup installer CAS2506 Pinion depth gauge arbor RCPH10FWD876AAJ RCPH10FWD875AAJ CAS2501 Bearing cup installer CAS2505 Brake disc aligner RCPH10FWD883AAJ RCPH10FWD882AAJ CAS2516 Bearing installer CNH299075 Lifting hook 48193194 12/10/2017 25.1 [25.100] / 19...
Page 26 Front axle system - Powered front axle RCPH10FWD866AAJ RCPH10FWD130ABJ CAS2692 Bearing heater adapter CAS2508 Rolling torque adapter RCPH10FWD879AAJ RCPH10FWD880AAJ CAS2511 Pinion bearing preload compressor CNH299134 Gear/bearing heater RCPH10FWD171ABJ RCPH10FWD170ABJ CAS2739 Bearing driver plate CAS2738 Push out bolts 48193194 12/10/2017 25.1 [25.100] / 20...
Page 27 Front axle system - Powered front axle 600 Series axles RCPH10FWD857AAJ RCPH10FWD854AAJ CAS2663 Trumpet housing bearing cup remover-installer CAS2666 Axle shaft/pinion bearing cone installer RCPH10FWD858AAJ RCPH10FWD855AAJ CNH299050 Pinion inner bearing cup installer CAS2667 CNH299041 Trumpet housing inner bearing cup remover RCPH10FWD856AAJ 380002920 Axle shaft lifting eye RCPH10FWD863AAJ...
Page 28 Front axle system - Powered front axle RCPH10FWD864AAJ 380002851 Axle shaft remover bar CAS2675 Brake assembly alignment stud set RCPH10FWD865AAJ RCPH10FWD862AAJ CAS2673 Pinion seal installer CAS2676 Planetary assembly lifting hook RCPH10FWD866AAJ RCPH10FWD869AAJ CAS2692 Bearing heater adapter CAS1675-2 Pinion depth gauge block 48193194 12/10/2017 25.1 [25.100] / 22...
Page 29 Front axle system - Powered front axle RCPH10FWD870AAJ RCPH10FWD867AAJ CNH299048 Planetary gear pilot sleeve CNH299079 Alignment stud set RCPH10FWD871AAJ CAS2405 Long bearing driver handle RCPH10FWD872AAJ RCPH10FWD875AAJ CNH299077 Short bearing driver handle CAS2501 Bearing cup installer RCPH10FWD876AAJ RCPH10FWD873AAJ 380002921 Lifting eye bolt CAS2505 Brake disc aligner 48193194 12/10/2017 25.1 [25.100] / 23...
Page 30 Front axle system - Powered front axle RCPH10FWD874AAJ RCPH10FWD877AAJ CAS2496 Alignment stud set CAS2506 Pinion depth gauge arbor RCPH10FWD878AAJ CAS2510 Bearing cup remover/adapter plate RCPH10FWD879AAJ RCPH10FWD882AAJ CAS2511 Pinion bearing preload compressor CAS2516 Bearing installer 48193194 12/10/2017 25.1 [25.100] / 24...
Page 31 Front axle system - Powered front axle RCPH10FWD883AAJ RCPH10FWD880AAJ CNH299134 Gear/bearing heater CNH299075 Lifting hook 600 Series Quadtrac axles RCPH10FWD855AAJ RCPH10FWD860AAJ CNH299050 Pinion inner bearing cup installer. CNH299042 Bearing cone installer RCPH10FWD858AAJ RCPH10FWD878AAJ CAS2510 Adapter plate CAS2667 Final drive housing inner bearing cup remover 48193194 12/10/2017 25.1 [25.100] / 25...
Page 32 Front axle system - Powered front axle RCPH10FWD857AAJ RCPH10FWD862AAJ CAS2666 Axle shaft pinion bearing cone remover CAS2673 Pinion seal installer RCPH10FWD864AAJ 380002906 Axle nut spanner wrench CAS2675 Brake assembly alignment stud set RCPH10FWD865AAJ RCPH10FWD129ABJ CAS2676 Planetary assembly lifting hook CAS2729 Planetary gear pilot sleeve 48193194 12/10/2017 25.1 [25.100] / 26...
Page 33 Front axle system - Powered front axle RCPH10FWD871AAJ RCPH10FWD869AAJ CAS1675-2 Pinion depth gauge block CAS2405 Long bearing driver handle RCPH10FWD872AAJ RCPH10FWD870AAJ CNH299077 Short bearing driver handle 380000884 Alignment stud set RCPH10FWD874AAJ RCPH10FWD873AAJ 380002921 Lifting eye bolt CAS2496 Alignment stud set RCPH10FWD858AAJ RCPH10FWD877AAJ CNH299083 Bearing cup installer...
Page 34 Front axle system - Powered front axle RCPH10FWD876AAJ RCPH10FWD875AAJ CAS2501 Bearing cup installer CAS2505 Brake disc aligner RCPH10FWD883AAJ RCPH10FWD882AAJ CAS2516 Bearing installer CNH299075 Lifting hook RCPH10FWD866AAJ RCPH10FWD130ABJ CAS2692 Bearing heater adapter CAS2508 Rolling torque adapter 48193194 12/10/2017 25.1 [25.100] / 28...
Page 35 Front axle system - Powered front axle RCPH10FWD879AAJ RCPH10FWD880AAJ CAS2511 Pinion bearing preload compressor CNH299134 Gear/bearing heater RCPH10FWD171ABJ RCPH10FWD170ABJ CAS2739 Bearing driver plate CAS2738 Push out bolts 48193194 12/10/2017 25.1 [25.100] / 29...
Page 36 Front axle system - Powered front axle Powered front axle - Overview - Axle lubrication system Overview The 4WD tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box, (if equipped). Axle lubrication oil is drawn from and returned back to the hydraulic reservoir (3).
Page 37 Front axle system - Powered front axle 315 and 425 series wheeled axle lubrication - System components involved The main components of the 315 and 425 axle lubrication system are: • 315 or 425 Series 4WD Tractor Drive Axles – The drive axles have internal passages and orifices which deliver the lube oil to the exact area required.
Page 38 Front axle system - Powered front axle RAIL14TR00965HA 48193194 12/10/2017 25.1 [25.100] / 32...
Page 39 Front axle system - Powered front axle 500 and 600 series wheeled axle lubrication - System components involved The main components of the 500and 600 wheeled axle lubrication system are: • 500 or 600 Series 4WD Tractor Drive Axles – The drive axles have internal passages and orifices which deliver the lube oil to the exact area required.
Page 40 Front axle system - Powered front axle RAIL14TR00966HA 48193194 12/10/2017 25.1 [25.100] / 34...
Page 41 Front axle system - Powered front axle Quadtrac series axle lubrication - System components involved The main components of the 500 and 600 Quadtrac axle lubrication system are: • Quadtrac Series 4WD Tractor Drive Axles – The drive axles have internal passages and orifices which deliver the lube oil to the exact area required.
Page 42 Front axle system - Powered front axle RAIL16TR00723HA 48193194 12/10/2017 25.1 [25.100] / 36...
Page 43 Front axle system - Powered front axle Rowtrac series axle lubrication - System components involved The main components of the Rowtrac axle lubrication system are: • Rowtrac Series 4WD Tractor Drive Axles – The drive axles have internal passages and orifices which deliver the lube oil to the exact area required.
Page 44 Front axle system - Powered front axle RAIL14TR00968HA 48193194 12/10/2017 25.1 [25.100] / 38...
Page 45 Front axle system - Powered front axle Rowtrac series axle lubrication - System components involved (continued) The main components of the Rowtrac axle lubrication system are: • Rowtrac Series 4WD Tractor Drive Axles have final drive upboxes at the ends of each axle. These upboxes do not have common passages with the axle center section so they require external plumbing to supply the required lubrication oil and then return it back to the axle center section.
Page 46 Front axle system - Powered front axle RAIL14TR00952FA 1. Front axle 13. Lube pressure test port 2. Rear axle 14. Lube oil return line 3. Hydraulic reservoir 15. Lube oil return fitting 4. Lube pump oil inlet tube 16. Lube oil return manifold 5.
Page 47 Front axle system - Powered front axle 315 and 425 series wheeled axle lube oil system schematic detailed explanation The 4WD tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box (3), (if equipped).
Page 48 Front axle system - Powered front axle RAIL14TR00969HA 48193194 12/10/2017 25.1 [25.100] / 42...
Page 49 Front axle system - Powered front axle 315 and 425 series wheeled axle lube external plumbing components The 4WD tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box, (if equipped). Axle lubrication oil is drawn from and returned back to the hydraulic reservoir.
Page 50 Front axle system - Powered front axle RAIL14TR00963GA 1. Front axle 11. Crossover tube to check valve 2. Rear axle 12. 1.7 bar (25 psi) check valve 5. Lubrication pump 16. External lube tube to pinion 6. Lube pump supply tube 23.
Page 51 Front axle system - Powered front axle 315 and 425 series axle lube oil internal passage detailed explanation Lubrication oil from the lube pump (8) is delivered to a tee on the driveshaft input side of each axle. From the input oil tee, an external tube carries excess lube oil to a 1.7 bar (25 psi) check valve at the opposite side of the differential housing, which regulates the lube oil pressure delivered to each axle.
Page 52 Front axle system - Powered front axle RAIL14TR00953FA 8. Lube oil supply from pump 32. Pinion shaft bearing lube orifice 13. Ring gear mesh area lube elbow 33. Park brake lube orifice 14. Pinion shaft bearing lube 34. Brake side planetary lube orifice 17.
Page 53 Front axle system - Powered front axle Lube oil flows to the remainder of the internal axle components through a jumper tube (17) with a 3.3 mm (0.13 in) orifice (18) in the end of it. The final drive planetary located on the brake (19) side of the axle is lubricated through an internal passage with a 1.9 mm (0.075 in) orifice (34).
Page 54 Front axle system - Powered front axle RAIL14TR00960FA RAIL14TR00961FA 48193194 12/10/2017 25.1 [25.100] / 48...
Page 55 Front axle system - Powered front axle 500 and 600 series wheeled and Quadtrac axle lube oil schematic detailed explanation The 4WD tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box (3), (if equipped).
Page 56 Front axle system - Powered front axle RAIL14TR00970HA 48193194 12/10/2017 25.1 [25.100] / 50...
Page 57 Front axle system - Powered front axle An external pinion bearing and bevel gear mesh lube tube (19) connects to an internal passage at the lube inlet tee. This external tube then connects to the port on the axle front cover which supports the pinion shaft. A pinion bearing and bevel mesh orifice tube (20) is installed under the supply fitting.
Page 58 Front axle system - Powered front axle RAIL14TR00970HA 48193194 12/10/2017 25.1 [25.100] / 52...
Page 59 Front axle system - Powered front axle 500 and 600 series wheeled axle lube external plumbing components The 4WD wheeled tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box, (if equipped). Axle lubrication oil is drawn from and returned back to the hydraulic reservoir.
Page 60 Front axle system - Powered front axle RAIL14TR00956FA 1. Front axle 12. 1.7 bar (25 psi) check valve 2. Rear axle 13. External tube to ring gear side planetary 5. Lubrication pump 19. External tube to pinion and bevel mesh 6.
Page 61 Front axle system - Powered front axle 500 and 600 series wheeled axle lube oil internal passage detailed explanation Lubrication oil from the lube pump (8) is delivered to a tee on the driveshaft input side of each axle. From the input oil tee, an external tube carries excess lube oil to a 1.7 bar (25 psi) check valve fitting (12) , which regulates the lube oil pressure delivered to the axle.
Page 62 Front axle system - Powered front axle RAIL14TR00957FA RAIL14TR00958FA 48193194 12/10/2017 25.1 [25.100] / 56...
Page 63 Front axle system - Powered front axle 500 and 600 series Quadtrac axle lube external plumbing components The 4WD Quadtrac tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box, (if equipped). Axle lubrication oil is drawn from and returned back to the hydraulic reservoir.
Page 64 Front axle system - Powered front axle RAIL14TR00959FA 1. Front axle 13. External tube to ring gear side planetary 2. Rear axle 19. External tube to pinion and bevel mesh 5. Lubrication pump 20. Pinion bearing and bevel mesh orifice tube 6.
Page 65 Front axle system - Powered front axle Rowtrac Aaxle lube oil system schematic detailed explanation The 4WD Rowtrac tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box (3), (if equipped). Axle lubrication oil is drawn from and returned back to the hydraulic reservoir (4).
Page 66 Front axle system - Powered front axle RAIL14TR00971HA 48193194 12/10/2017 25.1 [25.100] / 60...
Page 67 Front axle system - Powered front axle Rowtrac axle lube oil system schematic detailed explanation (continued) An external pinion bearing and bevel gear mesh lube tube (19) connects to an internal passage at the lube inlet cross fitting. This external tube then connects to the port on the axle front cover which supports the pinion shaft. A pinion bearing and bevel mesh orifice tube (20) is installed under the supply fitting.
Page 68 Front axle system - Powered front axle RAIL14TR00971HA 48193194 12/10/2017 25.1 [25.100] / 62...
Page 69 Front axle system - Powered front axle Rowtrac axle lube external plumbing components The 4WD Rowtrac tractors use a pressurized lubrication system for the front drive axle (1), the rear drive axle (2) and also for the optional power take off (PTO) output drop box, (if equipped). Axle lubrication oil is drawn from and returned back to the hydraulic reservoir.
Page 70 Front axle system - Powered front axle RAIL14TR00964GA 1. Front axle 19. External tube to pinion and bevel mesh 2. Rear axle 23. Axle lube return port 5. Lubrication pump 24. Rear axle return hose 6. Lube pump supply tube 25.
Page 71 Front axle system - Powered front axle Powered front axle - Dynamic description - 425 Series axles Steiger® 370 Steiger® 420 Steiger® 470 The axle assembly and components are very heavy. Dry weight of the axle assembly is approximately 1500 kg (3300 lb).
Page 72 Front axle system - Powered front axle Axle identification plate designations Axle series Plate Differential lock Position Type Axle size identification 425FW Front 127 mm (5 in) 425RW Rear 127 mm (5 in) 435FW Front 127 mm (5 in) 435RW Rear 127 mm (5 in) 440FW...
Page 73 Front axle system - Powered front axle Powered front axle - Dynamic description - 500 Series axles Steiger® 500 Steiger® 540 The axle assembly and components are very heavy. Dry weight of the axle assembly is 1875 kg (4133 lb) Be sure all lifting devices and/or support stands are in good shape and have the capacity to lift and/or support the applied load.
Page 74 Front axle system - Powered front axle Powered front axle - Dynamic description - 500 and 600 Series Quadtrac® Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® The axle assembly and components are very heavy. Dry weight of the axle assembly is 2232 kg (4920 lb). Be sure all lifting devices and/or support stands are in good shape and have the capacity to lift and/or support the applied load.
Page 75 Front axle system - Powered front axle Powered front axle - Dynamic description - 600 Series axles Steiger® 580 Steiger® 620 The axle assembly and components are very heavy. Dry weight of the axle assembly is 2170 kg (4784 lb) Be sure all lifting devices and/or support stands are in good shape and have the capacity to lift and/or support the applied load.
Page 76 Front axle system - Powered front axle Powered front axle - Remove - Row crop frame wheeled tractors Steiger® 370 Steiger® 420 Steiger® 470 Steiger® 500 Prior operation: Frame - Raise - Tractor jacking points (39.100) 1. Remove the rear differential plug (1) to drain the center section.
Page 77 Front axle system - Powered front axle 4. Remove the electrical connector (1) from differential lock solenoid (if equipped). Remove regulator pressure line (2) to differential lock (if equipped). Remove lube line (3), and service brake line (4). RCPH11FWD106BAM 15. Remove the wheel bolts. Use a wheel/axle lift to re- move the front wheels from the tractor.
Page 78 Front axle system - Powered front axle 17. Install the CAS2694 axle lifting adapter plate to the 20 ton floor jack. Be sure the plate is centered and bolted securely on the jack pad. RCPH10FWD625AAJ 18. Center the floor jack and adapter plate under the cen- ter of the main axle housing.
Page 79 Front axle system - Powered front axle 20. Install the two straps over the axle center housing. Fasten and tighten both straps. RCPH10FWD628AAJ 21. Loosen and remove the four axle mounting bolts and nuts from both sides of the tractor. RCPH10FWD629AAJ 22.
Page 80 Front axle system - Powered front axle 23. Tighten the two bolts securing the brackets to each wheel hub to secure the axle assembly in position. RCPH10FWD631AAJ 24. Loosen and remove the two straps. Lower and re- move the floor jack. 25.
Page 81 Front axle system - Powered front axle Powered front axle - Install - Row crop frame wheeled tractors Steiger® 370 Steiger® 420 Steiger® 470 Steiger® 500 1. Place and secure the axle assembly on the support stands and dolly cart. RCPH10FWD633AAJ 2.
Page 82 Front axle system - Powered front axle 5. Install the two straps over the axle center housing. Fas- ten and tighten both straps. RCPH10FWD628AAJ 6. Raise and align the axle into position on the mounting pads. Install the axle mounting bolts. NOTE: Apply a light coat of engine oil on the threads of each bolt.
Page 83 Front axle system - Powered front axle 8. Remove the support stand and dolly cart from the axle hubs. RCPH10FWD624AAJ 9. Loosen and remove the two straps, lower and remove the floor jack. 10. Use a wheel and axle lift to install the wheels and wheel bolts.
Page 84 Front axle system - Powered front axle 16. Install the electrical connector (1) to the differential lock solenoid (if equipped). Install the regulator pres- sure line (2) to differential lock (if equipped). Install the lube line (3) and service brake line (4). RCPH11FWD106BAM 22.
Page 85 Front axle system - Powered front axle Powered front axle - Remove - High power frame wheeled tractors Steiger® 540 Steiger® 580 Steiger® 620 Park the tractor on a smooth and level concrete surface. Remove the switch key and install blocks in front and behind both rear wheels.
Page 86 Front axle system - Powered front axle 4. Remove the wire harness mounting bolts (1). Remove park brake hose (2) and service brake tee (3). RCPH11FWD121BAM 5. Remove the hose (1) from the tractor. If equipped, re- move the wire harness connector from the differential lock solenoid coil (2).
Page 87 Front axle system - Powered front axle 15. Remove the wheel bolts. Use a wheel/axle lift to re- move the front wheels from the tractor. RCPH10FWD623AAJ 16. Use two of the wheel bolts with washers to install the 1027004 jack stand adapter post and dolly cart to each wheel hub as shown.
Page 88 Front axle system - Powered front axle 18. Center the floor jack and adapter plate under the cen- ter of the main axle housing. Raise the adapter plate until it touches the axle housing. RCPH10FWD626AAJ 19. Position the four angle brackets against the axle hous- ing and tighten the bolts.
Page 89 Front axle system - Powered front axle 21. Loosen and remove the four axle mounting bolts and nuts from both sides of the tractor. RCPH10FWD629AAJ 22. Slowly and carefully lower the axle until it rest securely on the lowest position of the two support stands. RCPH10FWD630AAJ 23.
Page 90 Front axle system - Powered front axle 25. Carefully remove the axle by rolling it out from under the left hand or right hand side of the tractor. NOTE: Always keep the dolly carts positioned with the widest part of the cart perpendicular to the axle. RCPH10FWD632AAJ 48193194 12/10/2017 25.1 [25.100] / 84...
Page 91 Front axle system - Powered front axle Powered front axle - Install - High power frame wheeled tractors Steiger® 540 Steiger® 580 Steiger® 620 1. Place and secure the axle assembly on the support stands and dolly cart. RCPH10FWD633AAJ 2. Roll the axle assembly into position under the tractor. RCPH10FWD634AAJ 3.
Page 92 Front axle system - Powered front axle 5. Install the two straps over the axle center housing. Fas- ten and tighten both straps. RCPH10FWD628AAJ 6. Raise and align the axle into position on the mounting pads. Install the axle mounting bolts. NOTE: Apply a light coat of engine oil on the threads of each bolt.
Page 93 Front axle system - Powered front axle 8. Remove the support stand and dolly cart from the axle hubs. RCPH10FWD624AAJ 9. Loosen and remove the two straps, lower and remove the floor jack. 10. Use a wheel and axle lift to install the wheels and wheel bolts.
Page 94 Front axle system - Powered front axle 14. Install return hose (1) on to axle. If equipped, install the wire harness connector from the differential lock solenoid coil (2) onto the solenoid. RCPH11FWD119BAM 22. Install the drive shaft and four attaching bolts. Tighten the bolts to the specified torque.
Page 95 Front axle system - Powered front axle 1. Place the tow ring (1) (if equipped) into tow cable mount (2). RCPH11FWD124BAM 25. If necessary, change the hydraulic and axle cooling system oil filters. Fill the hydraulic tank to the full mark on the sight gauge.
Page 96 Front axle system - Powered front axle Powered front axle - Remove - Quadtrac® tractors Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® Park the tractor on a smooth and level concrete surface. Remove the switch key. Provide room to roll the axle out from the left hand or right hand side of the tractor.
Page 97 Front axle system - Powered front axle 4. Remove the lube return hose (1) from the tractor hy- draulic system return tube (2) . RCPH11FWD157AAM 5. Remove the drain plug (1) from the tear drop housing (both sides). Reinstall and tighten the plugs after the oil is drained.
Page 98 Front axle system - Powered front axle 8. Remove the bulkhead nut (1) from the track tensioning tee adapter. RCPH10FWD645AAJ 9. Remove the clamp bolts, nuts and washers from the right and left side track tension hoses. Remove the hose assembly from the tractor. RCPH10FWD646AAJ 10.
Page 99 Front axle system - Powered front axle 12. Remove the slip yoke from the axle. RCPH10FWD649AAJ 13. If equipped, remove the wire harness connector from the differential lock solenoid coil. RCPH10FWD650AAJ 14. Remove the differential lock wire harness mounting bolts . RCPH10FWD651AAJ 15.
Page 100 Front axle system - Powered front axle 16. Remove the two service brake hoses (1) and the park brake hose (2). RCPH10FWD654AAJ 17. Install the CAS2694 axle lifting adapter plate to the 20 ton floor jack. Be sure the plate is centered and bolted securely on the jack pad.
Page 101 Front axle system - Powered front axle 19. Position the four angle brackets against the axle hous- ing and hand tighten the bolts. Raise the jack to take up the weight of the axle. RCPH10FWD665AAJ 20. Install the two straps over the axle center housing, fasten and tighten both straps.
Page 102 Front axle system - Powered front axle 23. Loosen the wedge tensioning bolt (1) . Loosen the two top yoke mounting bolts (2) on both sides of the tractor to lower the axle until the wedge (3) is loose. Remove the tensioning bolt (1) and wedge. Support the axle with the floor jack and remove the remaining yoke mounting bolts.
Page 103 Front axle system - Powered front axle 30. Use the floor jack to lift the frame until the axle will clear the frame. Carefully remove the axle by rolling it out from under the left hand or right hand side of the tractor.
Page 104 Front axle system - Powered front axle Powered front axle - Install - Quadtrac® tractors Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® 1. Place and secure the axle assembly and undercarriage yokes on the support stands (1) and dolly cart (2). RCPH10FWD674AAJ 2.
Page 105 Front axle system - Powered front axle 4. Install the two straps over the axle center housing. Fas- ten and tighten both straps. RCPH10FWD666AAJ 5. Use the floor jack to raise the axle into the front frame. NOTE: Be careful that the pinion input shaft (1) does not contact the lube return tube (2).
Page 106 Front axle system - Powered front axle 8. When the axle is completely seated in the frame, re- move the four top bolts (1) and install the alignment spacers (2) and bolts (1) . Install the two left and right side mounting bolts (3) and alignment washers (4).
Page 107 Front axle system - Powered front axle 12. Loosen and remove the two straps, lower and remove the floor jack. 13. Install the park brake hose (1) and the two service brake hoses (2). Install the differential lock wire har- ness mounting bolt (3) NOTE: Replace all O-rings on all fittings before installing hoses.
Page 108 Front axle system - Powered front axle 16. Install the mounting bolt in the differential lock wire harness clamp. RCPH10FWD652AAJ 17. Install the track tension hose assembly on the mount- ing brackets on both the right and left sides of the axle. RCPH10FWD646AAJ 18.
Page 109 Front axle system - Powered front axle 20. Install the lube return hose (1) on the return tube (2). RCPH11FWD157AAM 21. Install the lube return line and tighten the hose clamp. RCPH11FWD158AAM 22. Install the slip yoke on the pinion input shaft. RCPH10FWD649AAJ 23.
Page 110 Front axle system - Powered front axle 24. Install the drive shaft to the front axle. Tighten the four mounting bolts to specifications. NOTE: If the drive shaft yokes do not align when installing the drive shaft, raise one track off the surface. Use the tow valve to pressurize and release the park brake so that the pinion drive yoke can be turned for alignment with the drive shaft.
Page 111 Front axle system - Powered front axle 2. If necessary, clean the hydraulic tank, change the hy- draulic and axle cooling system oil filters. Fill the hy- draulic tank to the full mark on the sight gauge. Start the engine to fill the axle housing with oil. Run the en- gine a short time and shut down to check the coil level in the hydraulic tank.
Page 112 Index Front axle system - 25 Powered front axle - 100 Powered front axle - Dynamic description - 425 Series axles (*) ......Powered front axle - Dynamic description - 500 Series axles (*) .
Page 113 Front axle system - 25 Front bevel gear set and differential - 102 Steiger® 370 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 370 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 114 TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® CVT, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 115 48193194 12/10/2017 25.2 [25.102] / 1...
Page 116: Table Of Contents
Contents Front axle system - 25 Front bevel gear set and differential - 102 TECHNICAL DATA Differential Torque - Rowtrac™ axles (*) ..............3 Special tools - Rowtrac™...
Page 117: Torque - Rowtrac™ Axles (*)
Front axle system - Front bevel gear set and differential Differential - Torque - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Item Metric value U.S. value differential extension housing mounting bolts 284 – 298 N·m 209 – 220 lb ft Pinion cover mounting bolts 284 –...
Page 118 Front axle system - Front bevel gear set and differential CNH299024 Axle shaft/pinion bearing cone installer CNH299043 Pinion seal installer CNH299044 Brake assembly alignment stud set 48193194 12/10/2017 25.2 [25.102] / 4...
Page 119 Front axle system - Front bevel gear set and differential CNH299050 Bearing cup installer CNH299076 Pinion gauge block CNH299077 Driver handle CNH299082 Alignment stud set 48193194 12/10/2017 25.2 [25.102] / 5...
Page 120 Front axle system - Front bevel gear set and differential CNH299083 Bearing cup installer CNH299087 Brake spline aligner CNH299088 Pinion depth gauge arbor CNH299091 Pinion bearing preload compressor 48193194 12/10/2017 25.2 [25.102] / 6...
Page 121: General Specification - 400 Series Axles (*)
Bevel ring/pinion gear backlash Drive yoke to pinion shaft end 0.1 – 0.2 mm .005 – .007 in clearance Oil type CASE IH AKCELA HY-TRAN® ULTRACTION Differential - General specification - 500 Series axles Steiger® 500 Steiger® 540 Axle specifications Item Metric value U.S.
Page 122: General Specification - 500 Series Quadtrac® Axles (*)
Drive yoke to pinion shaft end 0.1 – 0.2 mm .005 – .007 in clearance Oil type CASE IH AKCELA NEXPLORE™ FLUID Differential - General specification - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac®...
Page 123: Remove - Rowtrac™ Axles (*)
Front axle system - Front bevel gear set and differential Differential - Remove - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Prior operation: Front axle track yoke assembly - Remove - Rowtrac™ axles (25.500) both sides. 1.
Page 124 Front axle system - Front bevel gear set and differential 4. Loosen the hose clamp and carefully remove the lube return hose (1) to drain the differential. Use the hose (1) on the adapter (2) as a valve to control the flow until the hose can be removed.
Page 125 Front axle system - Front bevel gear set and differential 9. Disconnect the track tension supply hose (1) from the tee fitting and bracket assembly (2) on the pinion car- rier. RCPH10FWD756AAJ 10. Install the CAS2694 axle lifting adapter plate to the 20 ton floor jack.
Page 126 Front axle system - Front bevel gear set and differential 12. Position the four angle brackets against the axle hous- ing and tighten the bolts. 13. Raise the jack to support the weight of the axle. RCPH10FWD761AAJ 14. Install the two straps over the axle center housing. Fasten and tighten both straps.
Page 127 Front axle system - Front bevel gear set and differential 16. Loosen the wedge tensioning bolt (1) 17. Loosen the two top yoke mounting bolts (2) on both sides of the tractor to lower the axle until the wedge (3) is loose. 18.
Page 128: Disassemble - Rowtrac™ Axles (*)
Front axle system - Front bevel gear set and differential Differential - Disassemble - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Pinion carrier removal 1. The differential housing must be rotated several times during the disassembly and assembly procedures. If available, the housing should be mounted in a revolver repair stand.
Page 129 Front axle system - Front bevel gear set and differential 3. Remove the tube line from the port block to the park brake supply port. RCPH10FWD944AAJ 4. Remove the tee fittings from the park and service brake pressure ports. RCPH10FWD945AAJ 5.
Page 130 Front axle system - Front bevel gear set and differential 6. Remove the plug (1) and tee fitting (2) from the port block. RAIL13TR00343AA 7. Remove the jumper tube from the lube port. Discard the O-rings. RAIL13TR00352AA 8. Remove the jumper tube from the differential lock sup- ply port.
Page 131 Front axle system - Front bevel gear set and differential 10. Discard the O-rings from the port block. RAIL13TR00346AA 11. Remove the jumper tube from the park brake supply port. Discard the O-rings. RCPH10FWD952AAJ 12. Remove the jumper tubes from the brake supply port. Discard the O-rings.
Page 132 Front axle system - Front bevel gear set and differential 13. If repairing a rear differential, remove the drive yoke retaining bolt, washer, shim pack and O-ring. Retain the shims with the yoke. NOTE: The front axle drive yoke does not use a retaining bolt.
Page 133 Front axle system - Front bevel gear set and differential 17. Use a lifting device to remove the pinion carrier from the housing. Be careful not to damage the shim pack. RCPH10FWD958AAJ 18. Remove and retain the shim pack. RAIL13TR00349AA Pinion carrier assembly 19.
Page 134 Front axle system - Front bevel gear set and differential 22. Pry the pinion seal from the housing. NOTE: The rear axle has an oil seal on the pinion shaft. The front axle has an oil seal on the pinion and a dust/ grease seal on the outside diameter of the drive yoke.
Page 135 Front axle system - Front bevel gear set and differential 28. Remove the spacer ring and shim pack. Retain the shims. RCPH10FWD965AAJ 29. Support the pinion carrier on a press bed. Use the press to push the pinion shaft through the front bearing cone RCPH10FWD966AAJ 30.
Page 136 Front axle system - Front bevel gear set and differential 32. Use the CNH299090 adaptor plate (1) and a bearing puller (2) to remove the inner bearing cup from the carrier housing. 33. Clean and inspect all parts for damage or wear. 34.
Page 137 Front axle system - Front bevel gear set and differential 39. Two threaded holes are provided in the flange of the carrier assembly. Use two of the retainer bolts that were removed to attach a lifting chain and hoist. 40. Use the hoist to slowly and carefully lift the brake car- rier assembly out of the housing.
Page 138 Front axle system - Front bevel gear set and differential 44. Starting with an end gap bolt, loosen each bolt in se- quence one full turn. 45. Repeat until all tension is released against the retain- ing ring. RCPH10FWD212ABJ 46. Remove all bolts from the split ring. 47.
Page 139 Front axle system - Front bevel gear set and differential 50. Use a short burst of compressed air to lift the park brake piston out of its bore. RCPH10FWD216ABJ 51. Remove the piston from the backing plate. RCPH10FWD217ABJ 52. Remove and discard the inner O-ring from the piston. RCPH10FWD218ABJ 53.
Page 140 Front axle system - Front bevel gear set and differential 54. Remove the brake backing plate. RCPH10FWD220ABJ 55. Remove the four brake separator plates and four fric- tion plates from the carrier. RCPH10FWD221ABJ 56. Remove each of the three brake adjuster pins with belleville spring washers.
Page 141 Front axle system - Front bevel gear set and differential 57. Remove the brake return plate from the carrier. RCPH10FWD223ABJ 58. Temporarily install a short jumper tube into the service brake pressure port. RCPH10FWD224ABJ 59. Use a short burst of compressed air to lift the brake piston out of the bore.
Page 142 Front axle system - Front bevel gear set and differential 61. Remove and discard the O-ring from the outside di- ameter of the piston. RCPH10FWD227ABJ 62. Remove and discard the piston inside diameter O-ring from the carrier. RCPH10FWD228ABJ 63. Remove and discard the two seal rings from the hub of the carrier.
Page 143 Front axle system - Front bevel gear set and differential 64. If required, use a split knife edge puller attachment (1) and a puller (2) to remove the bearing cone from the hub of the carrier. NOTE: If possible, place the bearing cup over the bearing cone when removing the bearing.
Page 144 Front axle system - Front bevel gear set and differential 70. If required, use a bearing puller and step plate to re- move the left hand side differential bearing cup. RAIL12TR2261AA 71. If required, use a bearing puller and step plate to re- move the right hand side differential bearing cup.
Page 145 Front axle system - Front bevel gear set and differential 73. Put a mark on the differential case for assembly refer- ence. RAIL12TR2271AA 74. Remove and discard the ring gear and cover attaching bolts. NOTE: The ring gear does not need to be removed unless the case or ring gear is to be replaced.
Page 146 Front axle system - Front bevel gear set and differential 77. Remove the large thrust washer from the cover. RAIL12TR2274AA 78. Remove the differential side gear from the case. RAIL12TR2275AA 79. If equipped with differential lock, remove the four steel separator plates and three friction plates (1) from the case.
Page 147 Front axle system - Front bevel gear set and differential 82. Remove the differential lock piston from the case. RAIL12TR2277AA 83. Remove the bolts securing the short pinion shafts in the case. RAIL12TR2278AA 84. Install an M8 x 1.25 bolt into the threaded hole in the end of each short pinion gear shaft.
Page 148 Front axle system - Front bevel gear set and differential 87. Use the same procedure to remove the long differ- ential pinion gear shaft, spacer and differential pinion gears. RAIL12TR2281AA 88. Remove the side gear from the bottom of the case. RAIL12TR2282AA 89.
Page 149 Front axle system - Front bevel gear set and differential Left hand differential bearing support disassembly 93. Remove the lubrication tube. RAIL13TR00356AA 94. If required, rotate the differential housing so the left hand side differential bearing support carrier is on top. 95.
Page 150 Front axle system - Front bevel gear set and differential 99. Remove and discard the oil seal. RAIL12TR2285AA 100. Remove and discard the seal ring. RAIL12TR2286AA 101. If required, use a bearing puller and step plate to remove the bearing cone from the hub of the bearing carrier.
Page 151: Assemble - Rowtrac™ Axles (*)
Front axle system - Front bevel gear set and differential Differential - Assemble - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Pinion carrier assembly 1. Use CNH299050 bearing driver CNH299077 handle (2) to install the inner bearing cup into the carrier housing.
Page 152 Front axle system - Front bevel gear set and differential 6. Lubricate the inner bearing cone with clean operating oil. 7. Install the bevel pinion gear into the carrier housing. RCPH10FWD026ABJ 8. Lubricate the front bearing cone with clean operating oil or assembly grease.
Page 153 Front axle system - Front bevel gear set and differential 12. Install and tighten the center bolt of the CNH299091 pinion bearing compression tool into the end of the pinion shaft. 13. Install the compression sleeve, thrust washer and nut on the center bolt.
Page 154 Front axle system - Front bevel gear set and differential 19. Remove the compression sleeve, snap ring and thick spacer ring. RCPH10FWD033ABJ 20. Select a shim combination equal to the distance mea- sured in step 18. 21. Install the selected shim pack (thickest shim first) and thick spacer ring on the pinion shaft.
Page 155 Front axle system - Front bevel gear set and differential 26. Loosen the nut on the center bolt at least two full turns. 27. Strike the head of the center bolt two sharp blows with a heavy hammer to back seat the bearing against the snap ring.
Page 156 Front axle system - Front bevel gear set and differential 35. Install snap ring. RAIL17TR01399AA 36. Press the dust seal on until it is flush with the housing. RAIL17TR01398AA Differential case assembly procedures 37. Lubricate the thrust washer for the case with clean assembly grease.
Page 157 Front axle system - Front bevel gear set and differential 41. Install the side gear into the bore in the bottom of the case. RAIL12TR2288AA 42. Lubricate the needle bearing slave ring with clean as- sembly grease. 43. Install the slave ring into the bore of the differential pinion gear.
Page 158 Front axle system - Front bevel gear set and differential 47. Install the opposite side differential pinion gear cen- tered to the case bore and meshed with the side gear. RAIL12TR2290AA 48. Install the long spacer sleeve between the two differ- ential pinion gears so that the hole in the center of the sleeve is horizontal.
Page 159 Front axle system - Front bevel gear set and differential 53. Align the hole in the end of the short pinion pin with the threaded hole in the case. 54. Repeat this procedure for the opposite short pinion shaft. RAIL12TR2292AA 55.
Page 160 Front axle system - Front bevel gear set and differential 58. Lubricate the seals of a new piston with clean assem- bly grease. RAIL12TR2294AA 59. Hand seat the differential lock piston into the bore of the case. RAIL12TR2295AA 60. Install the splined side gear on top of the pinion gears so that all gears are in mesh.
Page 161 Front axle system - Front bevel gear set and differential 62. Starting with a steel separator plate, alternately install 4 separator plates and 3 friction plates. Be sure the slots in the ears of the separator plates engage the dowel pins. NOTE: Soak the friction plates in clean operating fluid be- fore installation.
Page 162 Front axle system - Front bevel gear set and differential 66. Put a light coat of oil around the inside diameter of the ring gear. 67. Install two of the CNH299082 alignment studs into op- posite holes of the ring gear. 68.
Page 163 Front axle system - Front bevel gear set and differential 72. Put a light coat of oil around the outside diameter of the bearing cup 73. Use the CNH299083 bearing cup installer to install the bearing cup into the cover until fully seated. RAIL12TR2302AA 74.
Page 164 Front axle system - Front bevel gear set and differential 77. Lubricate the groove and the Teflon® seal ring liberally with clean assembly grease. 78. Install the Teflon® seal ring in the groove of the hub. Be sure the ends of the seal ring are connected to- gether.
Page 165 Front axle system - Front bevel gear set and differential 82. Use an appropriate size seal driver to install a new oil seal into the bearing carrier. RAIL12TR2303AA Adjusting bevel pinion gear depth 83. Install the CNH299088 pinion depth gauge arbor into the bore for the left hand bearing support.
Page 166 Front axle system - Front bevel gear set and differential 86. Use a lifting eye to install the pinion carrier assembly into the housing. NOTE: Do not install the shims at this time. RCPH10FWD081ABJ 87. Install four equally spaced carrier assembly retaining bolts and washers.
Page 167 Front axle system - Front bevel gear set and differential 91. Remove the pinion carrier retaining bolts and lift the pinion carrier assembly from the housing. 92. Remove the CNH299088 arbor. RCPH10FWD100ABJ 93. A correction factor number is etched onto the head end of the pinion.
Page 168 Front axle system - Front bevel gear set and differential RCPH10FWD120FBJ (1) CNH299088 pinion depth gauge arbor, (2) CNH299076 pinion depth gauge block, (3) pinion Item Metric value U.S. value 97.99 mm 3.858 in 75.82 mm 2.985 in 174.25 mm 6.860 in .44 mm 0.017 in...
Page 169 Front axle system - Front bevel gear set and differential Setting differential carrier bearing preload 96. Install two CNH299044 guide bolts into opposite holes of the left hand side bearing carrier bore. 97. Install the original bearing preload shim pack over the guide bolts so that all holes align.
Page 170 Front axle system - Front bevel gear set and differential 102. Rotate the differential housing so the right hand side is up. 103. Use a hoist to slowly and carefully install the differ- ential assembly into the housing to engage the left hand side bearing support.
Page 171 Front axle system - Front bevel gear set and differential 107. Install four of the carrier retaining bolts with washers 90 degrees from each other. 108. Torque the bolts evenly to 146 – 165 N·m (108 – 122 lb ft). RAIL12TR2310AA 109.
Page 172 Front axle system - Front bevel gear set and differential 113. If differential bearing preload is out of tolerance, add or remove shims as required from the right hand and/or left hand bearing support shim pack until bear- ing preload is correct. NOTE: Adjust used bearings to the low end of the rolling torque specifications.
Page 173 Front axle system - Front bevel gear set and differential 117. Install four pinion carrier retaining bolts and washers equally spaced. 118. Torque the four bolts to 284 – 298 N·m (209 – 220 lb ft). RCPH10FWD114ABJ 119. Install the drive yoke on the pinion gear. 120.
Page 174 Front axle system - Front bevel gear set and differential Checking for correct bevel pinion/gear tooth contact 125. After differential bearing preload and ring/pinion gear backlash adjustments have been completed, remove the pinion carrier. RCPH10FWD081ABJ 126. Put Prussian Blue or red lead on both sides of several ring gear teeth.
Page 175 Front axle system - Front bevel gear set and differential 130. Inspect the contact pattern of the gear teeth. Com- pare the contact pattern with the following illustra- tions and tables, for both the right hand (rear) and the left hand (front) pinion sets, and determine the correct tooth contact pattern.
Page 176 Front axle system - Front bevel gear set and differential Values Item Metric value U.S. value 5 – 8 mm 0.197 – 0.315 in 2 – 4 mm 0.079 – 0.157 in 30 – 35 mm 1.181 – 1.378 in 40 –...
Page 177 Front axle system - Front bevel gear set and differential 133. Rotate the differential housing until the right hand side is on top. 134. Remove the brake carrier from the housing. RCPH10FWD209ABJ Right hand brake carrier assembly procedure 135. If removed, install the bearing cone (large side down) on the hub of the carrier.
Page 178 Front axle system - Front bevel gear set and differential 140. Lubricate a new O-ring for the outside diameter of the service brake piston. 141. Install the O-ring in the groove of the piston. Be sure the O-ring is not twisted. 142.
Page 179 Front axle system - Front bevel gear set and differential 145. Place one pin with washers in each of the holes in the carrier. Be sure the spring washers are seated against the brake return plate and the shorter tapered end of the pin is pointed upwards.
Page 180 Front axle system - Front bevel gear set and differential 151. When the brake plates are correctly aligned, the pilot on the bottom of the tool plate must nest in the hub of the carrier as shown. RCPH10FWD257ABJ 152. Install the two proper size guide studs into opposite holes of the support carrier.
Page 181 Front axle system - Front bevel gear set and differential 155. Lubricate and install a new O-ring in the groove of the smaller outside diameter of the piston. Be sure the O-ring is not twisted. RCPH10FWD261ABJ 156. Lubricate the outside diameter and inside diameter of the piston liberally with clean assembly grease.
Page 182 Front axle system - Front bevel gear set and differential 160. Install and hand start the 12 bolts with washers to engage the threads. NOTE: The two shorter length bolts must be installed in the end holes of the ring. RCPH10FWD265ABJ 161.
Page 183 Front axle system - Front bevel gear set and differential 167. Use a hoist to carefully align and install the brake car- rier assembly into the differential housing. Be sure the assembly marks are aligned. RCPH10FWD209ABJ 168. Remove the guide studs. 169.
Page 184 Front axle system - Front bevel gear set and differential 172. Use the two CNH299082 alignment studs and install the pre-selected pinion carrier shim pack. RCPH10FWD244ABJ 173. Use the lifting eye to install the pinion carrier assem- bly into the differential housing. Be sure the assem- bly marks align.
Page 185 Front axle system - Front bevel gear set and differential 178. Lubricate and install new O-rings on the jumper tube for the park brake. 179. Install the jumper tube into the park brake supply port. RCPH10FWD269ABJ 180. Lubricate and install new O-rings on the jumper tube for the service brake.
Page 186 Front axle system - Front bevel gear set and differential 185. Lubricate and install new O-rings on the jumper tube for the differential lock. 186. Install the jumper tube into the differential lock supply port. RAIL13TR00353AA 187. Lubricate and install new O-rings on the jumper tube for the lube supply.
Page 187: Install - Rowtrac™ Axles (*)
Front axle system - Front bevel gear set and differential Differential - Install - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 1. Set the differential on to the CAS2694 axle lifting adapter plate. Be sure the differential housing is cen- tered on the adapter plate.
Page 188 Front axle system - Front bevel gear set and differential 5. Assemble the wedge and the wedge tensioning bolt (1) 6. Loose assemble the two top yoke mounting bolts (2) on both sides of the tractor to draw up the axle until the wedge (3) is tight.
Page 189 Front axle system - Front bevel gear set and differential 10. Connect the track tension supply hose (1) from the tee fitting and bracket assembly (2) on the pinion carrier. RCPH10FWD756AAJ 11. Connect the differential lock wire connector (1) from the rear frame wire harness located on the right hand side above the axle (2).
Page 190 Front axle system - Front bevel gear set and differential 14. Connect the lube return hose (1) and tighten the hose clamp. RAIL12TR02979AA 15. Assemble the four bolts from the drive shaft to the front differential yoke. 16. Torque the bolts to 115 – 129 N·m (85 – 95 lb ft) RCPH10FWD745AAJ 17.
Page 191 Front axle system - Front bevel gear set and differential 18. If equipped with a front tow cable, hook up the tow ring. RCPH11FWD124BAM 48193194 12/10/2017 25.2 [25.102] / 77...
Page 192: Disassemble - 400 Series Axles (*)
Front axle system - Front bevel gear set and differential Differential - Disassemble - 400 Series axles Steiger® 370 Steiger® 420 Steiger® 470 Prior operation: Final drive - Remove - 400 Series bar axles (25.310) Front cover removal 1. If equipped remove the nut retaining the coil on the stem of the differential lock solenoid valve.
Page 193 Front axle system - Front bevel gear set and differential 4. Remove the pinion bearing lube tube (1) and remove the orifice adapter (2). RCPH10FWD335ABJ 5. Remove the port adapter fitting and remove the long jumper tube (1) from the service brake port. Remove and discard the O-rings.
Page 194 Front axle system - Front bevel gear set and differential 7. Remove the drive yoke from the pinion shaft. RCPH10FWD549ABJ 8. Install the CAS2494 lifting eye bolt into the end of the pinion shaft. RCPH10FWD538ABJ 9. Remove all front cover retaining bolts. RCPH10FWD342ABJ 48193194 12/10/2017 25.2 [25.102] / 80...
Page 195 Front axle system - Front bevel gear set and differential 10. Install two of the retaining bolts into the threaded holes of the cover to use as jack screws. Tighten the two bolts evenly to jack the front cover from the dowel pins. RCPH10FWD344ABJ 11.
Page 196 Front axle system - Front bevel gear set and differential Front cover disassembly 13. Drive a sharp pry into the jacket of the outer pinion seal. Pry the seal from the housing. RCPH10FWD347ABJ 14. Remove the snap ring and inner seal from the front cover.
Page 197 Front axle system - Front bevel gear set and differential 16. Align one of the windows of the compression sleeve with the end gap of the snap ring. Use one wrench to hold the center bolt and a second wrench to tighten the nut until pinion bearing preload is noticeably increased to release the pressure against the snap ring.
Page 198 Front axle system - Front bevel gear set and differential 20. Support the front cover assembly on a press bed. Use the press to push the pinion gear through the front bearing cone. RCPH10FWD353ABJ 21. Use a split knife edge bearing puller and press to re- move the rear pinion bearing cone.
Page 199 Front axle system - Front bevel gear set and differential Brake carrier removal 24. Rotate the differential housing so that the right hand side brake carrier is on top and horizontal. Install four CAS2496 alignment studs at 90 degree intervals from each other.
Page 200 Front axle system - Front bevel gear set and differential 28. Loosen and remove each bolt and washer securing the backing plate to the carrier. RCPH10FWD495ABJ 29. Remove the brake backing plate from the carrier as- sembly. RCPH10FWD496ABJ 30. Remove the three brake separator plates and three friction plates from the carrier.
Page 201 Front axle system - Front bevel gear set and differential 31. Remove each of the three brake adjuster pins with belleville spring washers. RCPH10FWD985AAJ 32. Remove the brake return plate from the carrier. RCPH10FWD986AAJ 33. Temporarily install a short jumper tube into the service brake pressure port.
Page 202 Front axle system - Front bevel gear set and differential 35. Remove the service brake piston from the carrier. RCPH10FWD497ABJ 36. Remove and discard the O-ring from the outside di- ameter of the piston. RCPH10FWD990AAJ 37. Remove and discard the piston inside diameter. O-ring from the carrier.
Page 203 Front axle system - Front bevel gear set and differential 38. Remove and discard the two seal rings from the hub of the carrier. RCPH10FWD992AAJ 39. If required, use a Split Knife Edge Puller Attachment and Puller to remove the bearing cone from the hub of the carrier.
Page 204 Front axle system - Front bevel gear set and differential Differential bearing carrier removal and disassembly 41. Install the CAS2502 differential support bracket across the right hand side of the housing. Use two of the socket head bolts to retain the bracket to the housing.
Page 205 Front axle system - Front bevel gear set and differential 44. Remove and discard the seal. RCPH10FWD020ABJ 45. Remove and discard the seal ring. RCPH10FWD021ABJ 46. If required, use a bearing puller and step plate to re- move the bearing cone from the hub of the bearing carrier.
Page 206 Front axle system - Front bevel gear set and differential Differential removal 47. Push the oil tube out of the housing. RCPH10FWD360ABJ 48. Remove and discard the O-ring for the oil tube. RCPH10FWD361ABJ 49. Rotate the housing until the right hand side is on top. Attach a chain fall and overhead hoist to the housing.
Page 207 Front axle system - Front bevel gear set and differential 50. Position the center housing on the floor so the front opening is on top. Attach the CAS2509 differential lifting bracket on the ring gear. RCPH10FWD363ABJ 51. Drive the locating dowel pin for the oil tube outward until flush with the inside of the housing.
Page 208 Front axle system - Front bevel gear set and differential Differential case disassembly procedure 53. If required, use a puller arrangement and step plate to remove the left hand side differential bearing cup. RCPH10FWD366ABJ 54. If required, use a rolling head pry bar to remove the right hand side differential bearing cup.
Page 209 Front axle system - Front bevel gear set and differential 56. Remove the seal ring from the right hand side of the housing. Discard the seal ring. RCPH10FWD002ABJ 57. Match mark the case and ring gear for assembly ref- erence. RCPH10FWD003ABJ 58.
Page 210 Front axle system - Front bevel gear set and differential 59. Remove the top (left hand) differential case half. RCPH10FWD005ABJ 60. Remove the large thrust washer from the left hand case. RCPH10FWD006ABJ 61. Remove the splined differential side gear from the right hand case half.
Page 211 Front axle system - Front bevel gear set and differential 62. If the differential is equipped with differential lock, pro- ceed with the following instructions. If the differential is not equipped with differential lock, proceed the step 65 Remove the four steel separator plates and three fric- tion plates from the case.
Page 212 Front axle system - Front bevel gear set and differential 66. Remove the two cross pin bolts from the short pinion gear shaft locations. RCPH10FWD011ABJ 67. Install an M8 x 1.25 bolt into the threaded hole in the end of each short pinion gear shaft. Remove the short shafts and spacer sleeves from the right hand case.
Page 213 Front axle system - Front bevel gear set and differential 70. Remove the side gear from the bottom of the case. RCPH10FWD015ABJ 71. Remove the thrust washers for each spider gear from the case. RCPH10FWD016ABJ 72. Remove the thrust washer for the side gear from the bottom of the case.
Page 214: Assemble - 400 Series Axles (*)
Front axle system - Front bevel gear set and differential Differential - Assemble - 400 Series axles Steiger® 370 Steiger® 420 Steiger® 470 Front cover assembly 1. Use the CAS2501 bearing cup driver (1) and CAS1716-3 handle (2) to install the inner bearing cup into the cover.
Page 215 Front axle system - Front bevel gear set and differential 4. Lubricate the rear bearing with clean operating oil. In- stall the bevel pinion gear into the front cover. RCPH10FWD376ABJ 5. Lubricate the front bearing cone with clean operating oil. Install the bearing cone and thick spacer washer on the pinion shaft.
Page 216 Front axle system - Front bevel gear set and differential 8. Use a torque wrench on the center bolt to check rolling torque. Tighten the nut until 19 – 20 N·m (170 – 180 lb in) of smooth and continuous rolling torque is mea- sured on the torque wrench.
Page 217 Front axle system - Front bevel gear set and differential 12. Install the selected shim pack (thickest shim first) and thick spacer washer on the pinion shaft. RCPH10FWD351ABJ 13. Install the snap ring on the pinion shaft as far down as possible.
Page 218 Front axle system - Front bevel gear set and differential 16. Install the inner seal and snap ring into the front cover. RCPH10FWD494ABJ 17. Put an adhesive/sealant around the outside diameter. of a new pinion seal. Lubricate the lips of the seal with clean lithium grease.
Page 219 Front axle system - Front bevel gear set and differential 19. Connect the lubrication tube for the bevel pinion gear to the port fitting. Install the tube retaining clip and bolt. Tighten the retaining bolt to the specified torque. Adjust the tube to direct oil flow at the pinion gear teeth.
Page 220 Front axle system - Front bevel gear set and differential 22. Install the side gear into the bore in the bottom of the right hand case. RCPH10FWD037ABJ 23. Lubricate the needle bearing slave ring with clean as- sembly grease. Install the slave ring into the bore on the beveled side of the spider gear.
Page 221 Front axle system - Front bevel gear set and differential 26. Install the opposite side spider gear centered to the case bore and meshed with the side gear. RCPH10FWD041ABJ 27. Install the long spacer sleeve between the two spider gear so that the hole in the center of the sleeve is horizontal.
Page 222 Front axle system - Front bevel gear set and differential 30. Align the hole in the end of the short pinion pin with the threaded hole in the case. Repeat this procedure for the opposite short pinion shaft. RCPH10FWD043ABJ 31. Install the pinion pin retainer bolts. Tighten each bolt to specifications.
Page 223 Front axle system - Front bevel gear set and differential 33. If equipped with differential lock, lubricate the seals of a new piston with clean assembly grease. RCPH10FWD045ABJ 34. Hand seat the differential lock piston into the bore of the right hand case. RCPH10FWD046ABJ 35.
Page 224 Front axle system - Front bevel gear set and differential 37. Starting with a steel separator plate, alternately install 4 separator plates and 3 friction plates. Be sure the slots in the ears of the separator plates engage the dowel pins. NOTE: Soak the friction plates in clean operating fluid be- fore installation.
Page 225 Front axle system - Front bevel gear set and differential 40. Put a light coat of oil around the inside diameter of the ring gear. Install two of the CAS2496 alignment studs into opposite holes of the ring gear. Position the differential case over the ring gear.
Page 226 Front axle system - Front bevel gear set and differential 43. Use the CAS2500 bearing cup installer to install the bearing cup into the left hand case until fully seated. RCPH10FWD053ABJ 44. Position the bearing cup into the bore of the right hand case.
Page 227 Front axle system - Front bevel gear set and differential Differential bearing carrier assembly 47. Position the bearing cone (large side down) on the hub of the carrier. Use the CAS2516 bearing installer and press to install the bearing cone until fully seated. RCPH10FWD392ABJ 48.
Page 228 Front axle system - Front bevel gear set and differential 50. Install the CAS2506 pinion depth gauge arbor into the bore for the left hand bearing support in the housing. RCPH10FWD393ABJ 51. Use two of the bearing support retaining bolts and washers.
Page 229 Front axle system - Front bevel gear set and differential 54. Lift and install the pre-assembled front cover assem- bly onto the guide studs. RCPH10FWD397ABJ 55. Lower the front cover on the guide studs to engage the locating dowel pins. Install retaining bolts and washer in the center top and bottom holes and two bolts on each side of the cover.
Page 230 Front axle system - Front bevel gear set and differential 56. Install the CAS1675-2 gauge block (2) between the pinion and arbor with the hole end of the gauge block held tightly against the head end of the pinion. Use a feeler gauge (3) to measure the distance between the end of the gauge block (2) and the arbor (1).
Page 231 Front axle system - Front bevel gear set and differential RCPH10FWD120FBJ (1) CAS2506 Pinion depth gauge arbor, (2) CAS1675-2 Pinion depth gauge block, (3) Pinion Item Metric value U.S. value 97.99 mm 3.858 in 75.82 mm 2.985 in 174.25 mm 6.860 in .44 mm 0.017 in...
Page 232 Front axle system - Front bevel gear set and differential 59. Remove the front cover assembly, selected shim pack, and the CAS2506 pinion depth gauge. RCPH10FWD400ABJ Setting differential carrier bearing preload 60. Install the CAS2502 differential support bracket across the right hand side of the center housing. Use the CAS2509 differential lifting bracket and hoist to install the differential into the center housing.
Page 233 Front axle system - Front bevel gear set and differential 62. Rotate the center housing so the left hand side is on top and the differential is resting on the support bracket. Install the two CAS2479 alignment studs into opposite holes of the left hand side bearing carrier bore.
Page 234 Front axle system - Front bevel gear set and differential 66. Rotate the housing so the right hand side is on top and the differential is supported in the left hand side bear- ing carrier. Remove the CAS2502 differential support bracket.
Page 235 Front axle system - Front bevel gear set and differential 70. Use a hoist and chain fall to carefully install the right hand side brake carrier into the housing so that the assembly match marks align. NOTICE: The brake friction plates are not installed in the carrier when setting differential carrier bearing preload.
Page 236 Front axle system - Front bevel gear set and differential 74. Connect a torque wrench to the adapter. Rotate the differential and measure differential carrier bearing rolling torque. Bearing preload will be correct when 6 – 14 N·m (55 – 120 lb in) of smooth and consistent rolling torque is registered on the torque wrench.
Page 237 Front axle system - Front bevel gear set and differential 78. Use a hoist to install the pre-assembled front cover assembly onto the alignment studs. RCPH10FWD397ABJ 79. Install retaining bolts with washers in the center top and bottom cover holes and two bolts with washers on each side as shown.
Page 238 Front axle system - Front bevel gear set and differential 81. If too much backlash was measured, the ring gear must be moved closer to the pinion gear. Remove shim from the left hand bearing carrier shim pack and add an equal amount of shim to the right hand bear- ing carrier shim pack to maintain differential bearing preload.
Page 239 Front axle system - Front bevel gear set and differential 84. Use colored lead and brush to paint 3 or 4 teeth of the ring gear in three opposite places. RCPH10FWD416ABJ 85. Temporarily reinstall the front cover and selected shim pack as outlined in Step 56.
Page 240 Front axle system - Front bevel gear set and differential 87. Inspect the contact pattern of the gear teeth. Com- pare the contact pattern with the following illustrations and tables, for both the right hand (rear) and the left hand (front) pinion sets, and determine the correct tooth contact pattern.
Page 241 Front axle system - Front bevel gear set and differential Left hand (front) pinion set contact pattern: RCPH10FWD121FBJ Correct tooth contact pattern: Left hand (front) pinion set Description Item Gear top Gear toe Gear heel Coast side Drive side Values Item Metric value U.S.
Page 242 Front axle system - Front bevel gear set and differential 82. Adding or subtracting pinion carrier shims to change pinion depth must be done in small increments until the correct tooth contact pattern is obtained. (A) Move the drive pinion (1) towards the ring gear (2) to move the contact pattern away from the Toe.
Page 243 Front axle system - Front bevel gear set and differential 84. Lubricate new hub seal rings liberally with clean grease. Install the two seal rings into the grooves in the hub of the carrier. Be sure the seal ends are lapped together and seals are compressed into the grooves as tightly as possible.
Page 244 Front axle system - Front bevel gear set and differential 88. Install the belleville spring washers on the brake ad- juster pins. Slide 3 nested washers onto each pinup against the snap rings. Slide 3 nested washers on each pin in the opposing direction for a total of 9 belleville spring washers on each pin.
Page 245 Front axle system - Front bevel gear set and differential 91. Install a steel separator plate over the first friction plate. Repeat the steps for remaining plates alternat- ing friction and separator plates. RCPH10FWD062ABJ 92. Use the CAS2505 brake disc alignment tool to align the splines of all brake plates.
Page 246 Front axle system - Front bevel gear set and differential 95. Install the backing plate (recessed side up) over the guide studs so that the assembly match marks align. RCPH10FWD066ABJ 102. Install and hand start the bolts with washers to en- gage the threads.
Page 247 Front axle system - Front bevel gear set and differential Bearing carrier/brake support installation 104. Install the four CAS2496 alignment studs into the right hand side of the center housing opposite each other. Use a hoist and chain fall to align and care- fully install the right hand bearing carrier/brake sup- port assembly into the housing.
Page 248 Front axle system - Front bevel gear set and differential 107. Install the oil tube through the bore in the housing. Turn the tube so the hole in the end of the tube will- fully engage the locating dowel pin in the opposite side of the housing.
Page 249 Front axle system - Front bevel gear set and differential 110. Use a hoist to install the front cover assembly on the guide bolts. RCPH10FWD345ABJ 111. Install the front cover retaining bolts with washers. Tighten the bolts evenly to specifications. NOTE: The longer bolts are used on the porting block side.
Page 250 Front axle system - Front bevel gear set and differential 113. Install new O-rings on all oil jumper tubes. Lubricate the O-rings liberally with clean assembly grease. RCPH10FWD426ABJ 114. Install a long jumper tube into the service brake pres- sure port of the front cover. Use a blunt instrument to hand seat the jumper tube into the port until fully seated.
Page 251 Front axle system - Front bevel gear set and differential 116. If the differential is not equipped with differential lock, install the short jumper tube into the differential lock port. Hand seat the tube and assemble port plug. RCPH10FWD338ABJ 117. If equipped with differential lock, install new O-rings and install the solenoid stem into the port for the dif- ferential lock.
Page 252 Front axle system - Front bevel gear set and differential 120. Install the orifice fitting (1) and install the pinion bear- ing lube tube (2). RCPH10FWD335ABJ 121. Lubricate the splines of the pinion shaft with anti- sieze lubricant or clean grease. Install the drive yoke on the pinion shaft.
Page 253: Disassemble - 500 Series Axles (*)
Front axle system - Front bevel gear set and differential Differential - Disassemble - 500 Series axles Steiger® 500 Steiger® 540 Prior operation: Final drive - Remove - 500 Series axles (25.310) Pinion carrier removal 1. The differential housing must be rotated several times during the disassembly and assembly procedures.
Page 254 Front axle system - Front bevel gear set and differential 3. Remove the long tube line from the port block to the differential housing. RCPH10FWD943AAJ 4. Remove the tube line from the port block to the park brake supply port. RCPH10FWD944AAJ 5.
Page 255 Front axle system - Front bevel gear set and differential 6. If equipped, remove the differential lock solenoid from the port block. RCPH10FWD946AAJ 7. Remove the plug (1) and tee fitting (2) from the port block. RCPH10FWD947AAJ 8. Remove the jumper tube from the lube port. Discard the O-rings.
Page 256 Front axle system - Front bevel gear set and differential 9. Remove the jumper tube from the differential lock sup- ply port. Discard the O-rings. RCPH10FWD949AAJ 10. Remove the three bolts securing the port block to the housing. Remove the port block. RCPH10FWD950AAJ 11.
Page 257 Front axle system - Front bevel gear set and differential 12. Remove the jumper tube from the park brake supply port. Discard the O-rings. RCPH10FWD952AAJ 13. Remove the jumper tubes from the brake supply port. Discard the O-rings. RCPH10FWD953AAJ 14. If repairing a rear differential, remove the drive yoke retaining bolt, washer, and shim pack.
Page 258 Front axle system - Front bevel gear set and differential 15. Install the CAS2494 lifting eye into the pinion gear. RCPH10FWD955AAJ 16. Remove the pinion carrier mounting bolts. RCPH10FWD956AAJ 17. Install two CAS2496 alignment studs in opposite holes of the pinion carrier. RCPH10FWD957AAJ 18.
Page 259 Front axle system - Front bevel gear set and differential 19. Remove and retain the shim pack. RCPH10FWD959AAJ Pinion carrier disassembly 20. Remove the bolt securing the pinion gear lube tube. Disconnect and remove the tube, tube clamp and fit- ting.
Page 260 Front axle system - Front bevel gear set and differential 22. Pry the pinion seal from the housing. NOTE: The rear axle has an oil seal on the pinion gear. The front axle has an oil seal on the pinion and a dust/grease seal on the outside diameter of the drive yoke RCPH10FWD961AAJ 23.
Page 261 Front axle system - Front bevel gear set and differential 25. Use a snap ring pliers to remove the snap ring from the groove in the pinion shaft. NOTE: Because of the large diameter of the shaft, it will be necessary to use a flat blade screw driver through the second window of the compression sleeve to work the snap ring from the groove.
Page 262 Front axle system - Front bevel gear set and differential 29. Use a split knife edge puller attachment and press to remove the rear pinion bearing cone. RCPH10FWD967AAJ 30. Use a brass drift to remove the outer bearing cup from the carrier housing.
Page 263 Front axle system - Front bevel gear set and differential Brake carrier/bearing support removal 32. Rotate the differential housing so that the brake carrier side is on top. Remove the brake carrier retaining bolts and washers. RCPH10FWD970AAJ 33. Install two CAS2675 alignment studs opposite each other.
Page 264 Front axle system - Front bevel gear set and differential 35. Remove and retain the differential bearing preload shims. RCPH10FWD973AAJ Brake carrier/bearing support disassembly 36. Position the carrier assembly on a sturdy work surface so that the split ring side is on top. Put a mark across the assembly for reference.
Page 265 Front axle system - Front bevel gear set and differential 38. Remove all bolts from the split ring. Remove the split retainer ring. RCPH10FWD976AAJ 39. Remove the belleville spring. RCPH10FWD977AAJ 40. Temporarily install the short jumper tube into the park brake pressure port.
Page 266 Front axle system - Front bevel gear set and differential 42. Remove the piston from the backing plate. RCPH10FWD980AAJ 43. Remove and discard the inner O-ring from the piston. RCPH10FWD981AAJ 44. Remove and discard the outer O-ring from the piston. RCPH10FWD982AAJ 45.
Page 267 Front axle system - Front bevel gear set and differential 46. Remove the three brake separator plates and three friction plates from the carrier. RCPH10FWD984AAJ 47. Remove each of the three brake adjuster pins with belleville spring washers. RCPH10FWD985AAJ 48. Remove the brake return plate from the carrier. RCPH10FWD986AAJ 49.
Page 268 Front axle system - Front bevel gear set and differential 50. Use a short burst of compressed air to lift the brake piston out of the bore. RCPH10FWD988AAJ 51. Remove the piston from the carrier. RCPH10FWD989AAJ 52. Remove and discard the O-ring from the outside di- ameter of the piston.
Page 269 Front axle system - Front bevel gear set and differential 54. Remove and discard the two seal rings from the hub of the carrier. RCPH10FWD992AAJ 55. If required, use a split knife edge puller attachment (1) and a puller (2) to remove the bearing cone from the hub of the carrier.
Page 270 Front axle system - Front bevel gear set and differential Differential removal and disassembly 57. Remove the lube return mesh screen from the hous- ing. RCPH10FWD995AAJ 58. Position a nylon lifting sling in a choker configuration as low as possible on the differential carrier. Use a hoist to lift the differential from the housing.
Page 271 Front axle system - Front bevel gear set and differential 60. If required, use a bearing puller and step plate to re- move the right hand side differential bearing cup. RCPH10FWD001ABJ 61. Remove and discard the large seal ring. RCPH10FWD002ABJ 62.
Page 272 Front axle system - Front bevel gear set and differential 63. Remove and discard the ring gear and cover attaching bolts. Use a brass drift and hammer to tap the ring gear free from the case. NOTE: The ring gear does not need to be removed unless the case or ring gear is to be replaced.
Page 273 Front axle system - Front bevel gear set and differential 66. Remove the differential side gear from the case. RCPH10FWD007ABJ 67. If equipped with differential lock, remove the four steel separator plates and three friction plates from the case. Remove the 6 anti-rotation dowel pins from the case.
Page 274 Front axle system - Front bevel gear set and differential 70. Remove the bolts securing the short pinion shafts in the case. RCPH10FWD011ABJ 71. Install an M8 x 1.25 bolt into the threaded hole in the end of each short pinion gear shaft. Remove the short shafts and spacer sleeves from the case.
Page 275 Front axle system - Front bevel gear set and differential 74. Remove the side gear from the bottom of the case. RCPH10FWD015ABJ 75. Remove the thrust washers for each spider gear from the case. RCPH10FWD016ABJ 76. Remove the thrust washer for the side gear from the bottom of the case.
Page 276 Front axle system - Front bevel gear set and differential Left hand differential bearing support disassembly 77. If required, rotate the differential housing so the left hand side differential bearing support carrier is on top. Remove the bearing support retaining bolts and wash- ers.
Page 277 Front axle system - Front bevel gear set and differential 80. Remove and discard the seal ring. RCPH10FWD021ABJ 81. If required, use a bearing puller and step plate to re- move the bearing cone from the hub of the bearing carrier.
Page 278: Assemble - 500 Series Axles (*)
Front axle system - Front bevel gear set and differential Differential - Assemble - 500 Series axles Steiger® 500 Steiger® 540 Pinion carrier assembly 1. Use CNH299050 bearing driver CAS1716-3 handle (2) to install the inner bearing cup into the carrier housing. Be sure the bearing cup is seated in the bore.
Page 279 Front axle system - Front bevel gear set and differential 4. Lubricate inner bearing cone with clean operating oil. Install the bevel pinion gear into the carrier housing. RCPH10FWD026ABJ 5. Lubricate the front bearing cone with clean assembly lube. Install the bearing cone on the pinion shaft. RCPH10FWD027ABJ 6.
Page 280 Front axle system - Front bevel gear set and differential 8. Install and tighten the center bolt of the CAS2511 pin- ion bearing compression tool into the end of the pin- ion shaft. Install the compression sleeve, thrust washer and nut on the center bolt. RCPH10FWD030ABJ 9.
Page 281 Front axle system - Front bevel gear set and differential 12. Remove the compression sleeve, snap ring and thick spacer ring. RCPH10FWD033ABJ 13. Select a shim combination equal to the distance mea- sured in Step 11. Install the selected shim pack (thick- est shim first) and thick spacer ring on the pinion shaft.
Page 282 Front axle system - Front bevel gear set and differential 16. Loosen the nut on the center bolt at least two full turns. Strike the head of the center bolt two sharp blows with a heavy hammer to back seat the bearing against the snap ring.
Page 283 Front axle system - Front bevel gear set and differential 20. Install snap ring. RAIL17TR01399AA 21. Press the dust seal on until it is flush with the housing. RAIL17TR01398AA Differential case assembly procedures 22. Lubricate the thrust washer for the case with clean assembly grease.
Page 284 Front axle system - Front bevel gear set and differential 24. Install the side gear into the bore in the bottom of the case. RCPH10FWD037ABJ 25. Lubricate the needle bearing slave ring with clean as- sembly grease. Install the slave ring into the bore of the spider gear.
Page 285 Front axle system - Front bevel gear set and differential 28. Install the opposite side spider gear centered to the case bore and meshed with the side gear. RCPH10FWD041ABJ 29. Install the long spacer sleeve between the two spider gears so that the hole in the center of the sleeve is horizontal.
Page 286 Front axle system - Front bevel gear set and differential 32. Align the hole in the end of the short pinion pin with the threaded hole in the case. Repeat this procedure for the opposite short pinion shaft. RCPH10FWD043ABJ 33. Install the pinion pin retainer bolts. Tighten each bolt to the specified torque.
Page 287 Front axle system - Front bevel gear set and differential 35. Lubricate the seals of a new piston with clean assem- bly grease. RCPH10FWD045ABJ 36. Hand seat the differential lock piston into the bore of the case. RCPH10FWD046ABJ 37. Install the splined side gear on top of the pinion gears so that all gears are in mesh.
Page 288 Front axle system - Front bevel gear set and differential 39. Starting with a steel separator plate, alternately install 4 separator plates and 3 friction plates. Be sure the slots in the ears of the separator plates engage the dowel pins. NOTE: Soak the friction plates in clean operating fluid be- fore installation.
Page 289 Front axle system - Front bevel gear set and differential 42. Put a light coat of oil around the inside diameter of the ring gear. Install two of the CAS2496 alignment studs into opposite holes of the ring gear. Position the differential case over the ring gear.
Page 290 Front axle system - Front bevel gear set and differential 45. Use the CAS2500 bearing cup installer to install the bearing cup into the cover until fully seated. RCPH10FWD053ABJ 46. Position the bearing cup into the bore of the right hand case.
Page 291 Front axle system - Front bevel gear set and differential 48. Install the Teflon seal ring in the groove of the hub. Lubricate the groove and the seal ring liberally with clean assembly grease. Be sure the ends of the seal ring are connected together.
Page 292 Front axle system - Front bevel gear set and differential 51. Use a seal driver to install a new oil seal into the bear- ing carrier. Install the seal retaining screws and wash- ers. RCPH10FWD095ABJ Adjusting bevel pinion gear depth 52.
Page 293 Front axle system - Front bevel gear set and differential 54. Use the CAS2494 lifting eye to install the pinion carrier assembly into the housing. NOTE: Do not install the shims at this time. RCPH10FWD081ABJ 55. Install four equally spaced carrier assembly retaining bolts and washers.
Page 294 Front axle system - Front bevel gear set and differential 57. Remove the pinion carrier retaining bolts and lift the pinion carrier assembly from the housing. Remove the CAS2506 arbor. RCPH10FWD100ABJ 58. A correction factor number is etched onto the head end of the pinion.
Page 295 Front axle system - Front bevel gear set and differential 60. Use the following table and example to calculate the pinion depth shim requirements RCPH10FWD120FBJ (1) CAS2506 Pinion depth gauge arbor, (2) CAS1675-2 Pinion depth gauge block, (3) Pinion Item Metric value U.S.
Page 296 Front axle system - Front bevel gear set and differential 61. After pinion shim placement, remove the pinion carrier assembly. RCPH10FWD081ABJ 48193194 12/10/2017 25.2 [25.102] / 182...
Page 297 Front axle system - Front bevel gear set and differential Setting differential carrier bearing preload 62. Install two CAS2479 guide bolts into opposite holes of the left hand side bearing carrier bore. Install the orig- inal bearing preload shim pack over the guide bolts so that all holes align.
Page 298 Front axle system - Front bevel gear set and differential 66. Install two CAS2675 alignment studs into opposite holes of the housing. RCPH10FWD108ABJ 67. Install the original shim pack for the brake carrier and bearing support over the alignment studs so that all holes align.
Page 299 Front axle system - Front bevel gear set and differential 70. Install four of the carrier retaining bolts with washers 90 degrees from each other. Tighten the bolts evenly to the specified torque. RCPH10FWD109ABJ 71. Install the right hand axle sun gear shaft into the dif- ferential.
Page 300 Front axle system - Front bevel gear set and differential 74. If differential bearing preload is out of tolerance, add or remove shims as required from the right hand and/or left hand bearing support shim pack until bearing preload is correct. NOTE: Adjust used bearings to the low end of the rolling torque specifications.
Page 301 Front axle system - Front bevel gear set and differential 78. Install the drive yoke on the pinion gear. Use a dial indicator to measure ring/pinion gear backlash. Set the pointer of the dial indicator to contact the outer edge of the drive yoke flange. Rotate the pinion gear in either direction to achieve full contact with the ring gear.
Page 302 Front axle system - Front bevel gear set and differential 81. Put Prussian Blue or red lead on the convex side of several ring gear teeth. RCPH10FWD116ABJ 82. Reinstall the pinion gear carrier and tighten the re- taining bolts to the specified torque. Turn the pinion several revolutions in both directions to determine the tooth contact pattern.
Page 303 Front axle system - Front bevel gear set and differential Item Metric value U.S. value 30 – 35 mm 1.181 – 1.378 in 35 – 40 mm 1.378 – 1.575 in 10 – 15 mm 0.394 – 0.591 in 6 – 8 mm 0.236 –...
Page 304 Front axle system - Front bevel gear set and differential NOTICE: If differential carrier bearing preload, or ring gear and beveled pinion adjustment is required, do not install the hub seals or brakes at this time. make the proper shim adjustments as described. When adjustments are completed or not required, proceed to the brake carrier assembly procedure.
Page 305 Front axle system - Front bevel gear set and differential 86. Lubricate a new O-ring for the outside diameter of the service brake piston. Install the O-ring in the groove of the piston. Be sure the O-ring is not twisted. Carefully position the piston (flat side up) into the recessed bore of the carrier.
Page 306 Front axle system - Front bevel gear set and differential 89. Place one pin with washers in each of the holes in the carrier. Be sure the spring washers are seated against the brake return plate and the shorter tapered end of the pin is pointed upwards.
Page 307 Front axle system - Front bevel gear set and differential 93. When the brake plates are correctly aligned, the pilot on the bottom of the tool plate must nest in the hub of the carrier as shown. RCPH10FWD064ABJ 94. Install the two CAS2479 guide studs into opposite holes of the support carrier.
Page 308 Front axle system - Front bevel gear set and differential 97. Lubricate and install a new O-ring in the groove of the smaller outside diameter of the piston. Be sure the O-ring is not twisted. RCPH10FWD068ABJ 98. Lubricate the outside and inside diameters of the pis- ton liberally with clean assembly grease.
Page 309 Front axle system - Front bevel gear set and differential 101. Install and hand start the 12 bolts with washers to engage the threads. NOTE: The two shorter length bolts must be installed in the end holes of the ring. RCPH10FWD072ABJ 102.
Page 310 Front axle system - Front bevel gear set and differential Brake carrier/bearing support installation 106. Using the CAS2675 guide studs, install the prese- lected shim pack for the brake support carrier so that all holes align. RCPH10FWD973AAJ 107. Use a hoist to carefully align and install the brake car- rier assembly into the differential housing.
Page 311 Front axle system - Front bevel gear set and differential Pinion carrier assembly installation 109. Lubricate and install a new O-ring in the groove around the mounting flange of the pinion carrier. Be sure the O-ring is not twisted. RCPH10FWD079ABJ 110.
Page 312 Front axle system - Front bevel gear set and differential 112. Remove the guide studs and lifting eye, install the pinion carrier retaining bolts and washers. Torque the pinion carrier bolts to 284 – 298 N·m (209 – 220 lb ft). 113.
Page 313 Front axle system - Front bevel gear set and differential 117. Lubricate and install new O-rings on the port block. RCPH10FWD085ABJ 118. Install the port block on the differential housing. Tighten the retaining bolts to specifications. RCPH10FWD950AAJ 119. Lubricate and install new O-rings on the jumper tube for the differential lock.
Page 314 Front axle system - Front bevel gear set and differential 120. Lubricate and install new O-rings on the jumper tube for the lube supply. Install the jumper tube into the lube supply port. RCPH10FWD948AAJ 121. If equipped, install the Differential Lock Solenoid on to the Port Block.
Page 315: Disassemble - 500 Series Quadtrac® Axles (*)
Front axle system - Front bevel gear set and differential Differential - Disassemble - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Prior operation: Final drive - Remove - 500 Series Quadtrac® axles (25.310) Pinion carrier removal 1.
Page 316 Front axle system - Front bevel gear set and differential 3. Remove the long tube line from the port block to the differential housing. RCPH10FWD943AAJ 4. Remove the tube line from the port block to the park brake supply port. RCPH10FWD944AAJ 5.
Page 317 Front axle system - Front bevel gear set and differential 6. Remove the differential lock solenoid from the port block. RCPH10FWD946AAJ 7. Remove the plug (1) and tee fitting (2) from the port block. RCPH10FWD947AAJ 8. Remove the jumper tube from the lube port. Discard the O-rings.
Page 318 Front axle system - Front bevel gear set and differential 9. Remove the jumper tube from the differential lock sup- ply port. Discard the O-rings. RCPH10FWD949AAJ 10. Remove the three bolts securing the port block to the housing. Remove the port block. RCPH10FWD950AAJ 11.
Page 319 Front axle system - Front bevel gear set and differential 12. Remove the jumper tube from the park brake supply port. Discard the O-rings. RCPH10FWD952AAJ 13. Remove the jumper tubes from the brake supply port. Discard the O-rings. RCPH10FWD953AAJ 14. If repairing a rear differential, remove the drive yoke retaining bolt, washer, shim pack and O-ring.
Page 320 Front axle system - Front bevel gear set and differential 15. Install the CAS2494 lifting eye into the pinion gear. RCPH10FWD955AAJ 16. Remove the pinion carrier mounting bolts. RCPH10FWD956AAJ 17. Install two CAS2496 alignment studs in opposite holes of the pinion carrier. RCPH10FWD957AAJ 18.
Page 321 Front axle system - Front bevel gear set and differential 19. Remove and retain the shim pack. RCPH10FWD959AAJ Pinion carrier assembly 20. Remove the bolt securing the pinion gear lube tube. Disconnect and remove the tube, tube clamp and fit- ting.
Page 322 Front axle system - Front bevel gear set and differential 23. Use a Snap Ring Pliers to remove the snap ring from the groove in the pinion shaft. NOTE: If pinion bearing preload increased noticeably, re- move the compression sleeve to remove the large snap ring.
Page 323 Front axle system - Front bevel gear set and differential 27. Use a split knife edge puller attachment and press to remove the rear pinion bearing cone. RCPH10FWD967AAJ 28. Use a brass drift to remove the outer bearing cup from the carrier housing.
Page 324 Front axle system - Front bevel gear set and differential Brake carrier/bearing support removal 30. Rotate the differential housing so that the brake carrier side is on top. Remove the brake carrier retaining bolts and washers. RCPH10FWD970AAJ 31. Install two CAS2675 alignment studs opposite each other.
Page 325 Front axle system - Front bevel gear set and differential Brake carrier/bearing support disassembly 34. Position the carrier assembly on a sturdy work surface so that the split ring side is on top. Put a mark across the assembly for reference. RCPH10FWD211ABJ 35.
Page 326 Front axle system - Front bevel gear set and differential 37. Remove the belleville spring. RCPH10FWD214ABJ 38. Temporarily install the short jumper tube into the park brake pressure port. RCPH10FWD215ABJ 39. Use a short burst of compressed air to lift the park brake piston out of its bore.
Page 327 Front axle system - Front bevel gear set and differential 41. Remove and discard the inner O-ring from the piston. RCPH10FWD218ABJ 42. Remove and discard the outer O-ring from the piston. RCPH10FWD219ABJ 43. Remove the brake backing plate. RCPH10FWD220ABJ 48193194 12/10/2017 25.2 [25.102] / 213...
Page 328 Front axle system - Front bevel gear set and differential 44. Remove the four brake separator plates and four fric- tion plates from the carrier. RCPH10FWD221ABJ 45. Remove each of the three brake adjuster pins with belleville spring washers. RCPH10FWD222ABJ 46.
Page 329 Front axle system - Front bevel gear set and differential 47. Temporarily install a short jumper tube into the service brake pressure port. RCPH10FWD224ABJ 48. Use a short burst of compressed air to lift the brake piston out of the bore. RCPH10FWD225ABJ 49.
Page 330 Front axle system - Front bevel gear set and differential 51. Remove and discard the piston inside diameter O-ring from the carrier. RCPH10FWD228ABJ 52. Remove and discard the two seal rings from the hub of the carrier. RCPH10FWD229ABJ 53. If required, use a split knife edge puller attachment (1) and a puller (2) to remove the bearing cone from the hub of the carrier.
Page 331 Front axle system - Front bevel gear set and differential 55. Remove and discard the seal. Clean and inspect all brake carrier parts for damage or wear. Replace any damaged or worn parts found RCPH10FWD994AAJ Differential removal and disassembly 56. Position a nylon lifting sling in a choker configuration as low as possible on the differential carrier.
Page 332 Front axle system - Front bevel gear set and differential 58. If required, use a bearing puller and step plate to re- move the right hand side differential bearing cup. RCPH10FWD001ABJ 59. Remove and discard the large seal ring. RCPH10FWD002ABJ 60.
Page 333 Front axle system - Front bevel gear set and differential 61. Remove and discard the ring gear and cover attaching bolts. Use a brass drift and hammer to tap the ring gear free from the case. NOTE: The ring gear does not need to be removed unless the case or ring gear is to be replaced.
Page 334 Front axle system - Front bevel gear set and differential 64. Remove the differential side gear from the case. RCPH10FWD007ABJ 65. If equipped with differential lock, remove the four steel separator plates and three friction plates from the case. Remove the 6 anti-rotation dowel pins from the case.
Page 335 Front axle system - Front bevel gear set and differential 68. Remove the bolts securing the short pinion shafts in the case. RCPH10FWD011ABJ 69. Install an M8 x 1.25 bolt into the threaded hole in the end of each short pinion gear shaft. Remove the short shafts and spacer sleeves from the case.
Page 336 Front axle system - Front bevel gear set and differential 72. Remove the side gear from the bottom of the case. RCPH10FWD015ABJ 73. Remove the thrust washers for each spider gear from the case. RCPH10FWD016ABJ 74. Remove the thrust washer for the side gear from the bottom of the case.
Page 337 Front axle system - Front bevel gear set and differential Left hand differential bearing support disassembly 75. If required, rotate the differential housing so the left hand side differential bearing support carrier is on top. Remove the bearing support retaining bolts and wash- ers.
Page 338 Front axle system - Front bevel gear set and differential 78. Remove and discard the oil seal. RCPH10FWD020ABJ 79. Remove and discard the seal ring. RCPH10FWD021ABJ 80. If required, use a bearing puller and step plate to re- move the bearing cone from the hub of the bearing carrier.
Page 339: Assemble - 500 Series Quadtrac® Axles (*)
Front axle system - Front bevel gear set and differential Differential - Assemble - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Pinion carrier assembly 1. Use CNH299050 bearing cup driver (1) and an appro- priate handle (2) to install the inner bearing cup into the carrier housing.
Page 340 Front axle system - Front bevel gear set and differential 4. Lubricate the inner bearing cone with clean operating oil. Install the bevel pinion gear into the carrier housing. RCPH10FWD026ABJ 5. Lubricate the front bearing cone with clean operating oil or assembly grease. Install the bearing cone on the pinion shaft.
Page 341 Front axle system - Front bevel gear set and differential 8. Install and tighten the center bolt of the CAS2511 pin- ion bearing compression tool into the end of the pin- ion shaft. Install the compression sleeve, thrust washer and nut on the center bolt. RCPH10FWD030ABJ 9.
Page 342 Front axle system - Front bevel gear set and differential 12. Remove the compression sleeve, snap ring and thick spacer ring. RCPH10FWD033ABJ 13. Select a shim combination equal to the distance mea- sured in step 11. Install the selected shim pack (thick- est shim first) and thick spacer ring on the pinion shaft.
Page 343 Front axle system - Front bevel gear set and differential 16. Loosen the nut on the center bolt at least two full turns. Strike the head of the center bolt two sharp blows with a heavy hammer to back seat the bearing against the snap ring.
Page 344 Front axle system - Front bevel gear set and differential 20. Install snap ring. RAIL17TR01399AA 21. Press the dust seal on until it is flush with the housing. RAIL17TR01398AA Differential case assembly procedures 22. Lubricate the thrust washer for the case with clean assembly grease.
Page 345 Front axle system - Front bevel gear set and differential 24. Install the side gear into the bore in the bottom of the case. RCPH10FWD037ABJ 25. Lubricate the needle bearing slave ring with clean as- sembly grease. Install the slave ring into the bore of the spider gear.
Page 346 Front axle system - Front bevel gear set and differential 28. Install the opposite side spider gear centered to the case bore and meshed with the side gear. RCPH10FWD041ABJ 29. Install the long spacer sleeve between the two spider gears so that the hole in the center of the sleeve is horizontal.
Page 347 Front axle system - Front bevel gear set and differential 32. Align the hole in the end of the short pinion pin with the threaded hole in the case. Repeat this procedure for the opposite short pinion shaft. RCPH10FWD043ABJ 33. Install the pinion pin retainer bolts. Tighten each bolt to specifications.
Page 348 Front axle system - Front bevel gear set and differential 35. Lubricate the seals of a new piston with clean assem- bly grease. RCPH10FWD045ABJ 36. Hand seat the differential lock piston into the bore of the case. RCPH10FWD046ABJ 37. Install the splined side gear on top of the pinion gears so that all gears are in mesh.
Page 349 Front axle system - Front bevel gear set and differential 39. Starting with a steel separator plate, alternately install 4 separator plates and 3 friction plates. Be sure the slots in the ears of the separator plates engage the dowel pins. NOTE: Soak the friction plates in clean operating fluid be- fore installation.
Page 350 Front axle system - Front bevel gear set and differential 42. Put a light coat of oil around the inside diameter of the ring gear. Install two of the CAS2496 alignment studs into opposite holes of the ring gear. Position the differential case over the ring gear.
Page 351 Front axle system - Front bevel gear set and differential 45. Use an appropriate bearing cup Installer to install the bearing cup into the cover until fully seated. RCPH10FWD053ABJ 46. Position the bearing cup into the bore of the right hand case.
Page 352 Front axle system - Front bevel gear set and differential 48. Install the Teflon seal ring in the groove of the hub. Lubricate the groove and the seal ring liberally with clean assembly grease. Be sure the ends of the seal ring are connected together.
Page 353 Front axle system - Front bevel gear set and differential 51. Use a seal driver to install a new oil seal into the bear- ing carrier. RCPH10FWD095ABJ 52. Install the 3 seal retainer bolts and washers. Apply thread sealant on the bolt threads. RCPH10FWD234ABJ Adjusting bevel pinion gear depth 53.
Page 354 Front axle system - Front bevel gear set and differential 55. Use a lifting eye to install the pinion carrier assembly into the housing. NOTE: Do not install the shims at this time. RCPH10FWD081ABJ 56. Install four equally spaced carrier assembly retaining bolts and washers.
Page 355 Front axle system - Front bevel gear set and differential 58. Remove the pinion carrier retaining bolts and lift the pinion carrier assembly from the housing. Remove the CAS2506 arbor. RCPH10FWD100ABJ 59. A correction factor number is etched onto the head end of the pinion.
Page 356 Front axle system - Front bevel gear set and differential RCPH10FWD120FBJ (1) CAS2506 pinion depth gauge arbor, pinion depth gauge block, (3) pinion Item Metric value U.S. value 97.99 mm 3.858 in 75.82 mm 2.985 in 174.25 mm 6.860 in .44 mm 0.017 in Gap measurement...
Page 357 Front axle system - Front bevel gear set and differential Setting differential carrier bearing preload 62. Install two CAS2675 guide bolts into opposite holes of the left hand side bearing carrier bore. Install the orig- inal bearing preload shim pack over the guide bolts so that all holes align.
Page 358 Front axle system - Front bevel gear set and differential 66. Install two CAS2675 alignment studs into opposite holes of the housing. RCPH10FWD239ABJ 67. Install the original shim pack for the brake carrier and bearing support over the alignment studs so that all holes align.
Page 359 Front axle system - Front bevel gear set and differential 69. Install four of the carrier retaining bolts with washers 90 degrees from each other. Tighten the bolts evenly to specifications. RCPH10FWD240ABJ 70. Install the right hand axle stub shaft into the differen- tial.
Page 360 Front axle system - Front bevel gear set and differential 73. If differential bearing preload is out of tolerance, add or remove shims as required from the right hand and/or left hand bearing support shim pack until bearing preload is correct. NOTE: Adjust used bearings to the low end of the rolling torque specifications.
Page 361 Front axle system - Front bevel gear set and differential 76. Install four pinion carrier retaining bolts and washers equally spaced. Tighten the four bolts to specifica- tions. RCPH10FWD114ABJ 77. Install the drive yoke on the pinion gear. Use a dial indicator to measure ring/pinion gear backlash.
Page 362 Front axle system - Front bevel gear set and differential Checking for correct bevel pinion/gear tooth contact 79. After differential bearing preload and ring/pinion gear backlash adjustments have been completed, remove the pinion carrier. RCPH10FWD081ABJ 80. Put Prussian Blue or red lead on both sides of several ring gear teeth.
Page 363 Front axle system - Front bevel gear set and differential Inspect the contact pattern of the gear teeth. Compare the contact pattern with the following illustrations and tables, for both the right hand (rear) and the left hand (front) pinion sets, and determine the correct tooth con- tact pattern.
Page 364 Front axle system - Front bevel gear set and differential Values Item Metric value U.S. value 5 – 8 mm 0.197 – 0.315 in 2 – 4 mm 0.079 – 0.157 in 30 – 35 mm 1.181 – 1.378 in 40 –...
Page 365 Front axle system - Front bevel gear set and differential Right hand brake carrier assembly procedure 82. If removed, install the bearing cone (large side down) on the hub of the carrier. Use a bearing installer and handle to drive the bearing cone on the hub until seated.
Page 366 Front axle system - Front bevel gear set and differential 86. Install the brake return plate over the service brake piston aligning the ear tabs with the slots in the support carrier. NOTE: The brake return plate has holes in the ear tabs. RCPH10FWD223ABJ 87.
Page 367 Front axle system - Front bevel gear set and differential 89. Lubricate all friction plates with clean operating fluid. Install the first friction plate over the brake return plate. NOTE: Align the friction plate oil cross holes as they are installed.
Page 368 Front axle system - Front bevel gear set and differential 93. Install the two guide studs into opposite holes of the support carrier. RCPH10FWD258ABJ 94. Install the park brake backing plate (recessed side up) over the guide studs so that the assembly match marks align.
Page 369 Front axle system - Front bevel gear set and differential 97. Lubricate the outside diameter and inside diameter of the piston liberally with clean assembly grease. Hand seat the piston squarely into the bore of the backing plate. RCPH10FWD262ABJ 98. Install the large belleville spring with the cone side down on top of the park brake piston.
Page 370 Front axle system - Front bevel gear set and differential 101. After all bolts have contacted the retainer ring, start- ing with an end bolt, tighten each bolt in sequence one full turn and repeat until the ring has seated on the backing plate.
Page 371 Front axle system - Front bevel gear set and differential 105. Assemble the brake carrier as described in steps 82 through 103. RCPH10FWD259ABJ 106. Using the CAS2675 guide studs, install the pre-se- lected shim pack for the brake support carrier so that all holes align.
Page 372 Front axle system - Front bevel gear set and differential 108. Remove the guide studs. Install the brake carrier re- taining bolts and washers. Tighten the bolts to spec- ifications. RCPH10FWD267ABJ 109. Lubricate and install a new O-ring in the groove around the mounting flange of the pinion carrier.
Page 373 Front axle system - Front bevel gear set and differential 111. Use a lifting eye to install the pinion carrier assembly into the differential housing. Be sure the assembly marks align. 112. Remove the guide studs and the lifting eye. 113.
Page 374 Front axle system - Front bevel gear set and differential 117. Lubricate and install new O-rings on the jumper tube for the service brake. Install the jumper tube into the service brake supply port. RCPH10FWD270ABJ 118. Lubricate and install new O-rings on the port block. RCPH10FWD271ABJ 119.
Page 375 Front axle system - Front bevel gear set and differential 121. Lubricate and install new O-rings on the jumper tube for the lube supply. Install the jumper tube into the lube supply port. RCPH10FWD948AAJ 122. Install the differential lock solenoid on the port block. RCPH10FWD091ABJ Next operation: Hydraulic service brakes - Test - Brake leak down (33.202) Differential lock - Leakage test (25.102)
Page 376: Disassemble - 600 Series Axles (*)
Front axle system - Front bevel gear set and differential Differential - Disassemble - 600 Series axles Steiger® 580 Steiger® 620 Prior operation: 1. The differential housing must be rotated several times during the disassembly and assembly procedures. If available, the housing should be mounted in a revolver repair stand.
Page 377 Front axle system - Front bevel gear set and differential 2. Remove the lube tube from the port block and pinion carrier. RCPH11FWD345CAC 3. Remove the horizontal tube (1) from fittings on differen- tial housing. Remove the tube (2) from the port block to the tee fitting on the differential housing.
Page 378 Front axle system - Front bevel gear set and differential 4. Remove the tube line from the port block to the park brake supply port. RCPH11FWD347BAC 5. If equipped, remove the differential lock solenoid from the port block. RCPH11FWD348BAC 48193194 12/10/2017 25.2 [25.102] / 264...
Page 379 Front axle system - Front bevel gear set and differential 6. Remove the plug (1) and tee fitting (2) from the port block. RCPH11FWD349BAC 7. Remove the jumper tube from the lube port. Discard the O-rings. RCPH11FWD350BAC 8. Remove the jumper tube from the differential lock sup- ply port.
Page 380 Front axle system - Front bevel gear set and differential 9. Remove the three bolts securing the port block to the housing. Remove the port block. RCPH11FWD352BAC 10. Discard the O-rings from the port block. RCPH10FWD951AAJ 11. Remove the tee fittings from the service and park brake pressure ports.
Page 381 Front axle system - Front bevel gear set and differential 12. Remove the jumper tube from the park brake supply port. Discard the O-rings. RCPH11FWD355AAC 13. Use a M10 X 1.5 bolt (1) threaded into the inner di- ameter of the service brake supply port jump tube (2) and remove it.
Page 382 Front axle system - Front bevel gear set and differential 15. Install the CAS2494 lifting eye into the pinion gear. RCPH11FWD363BAC 16. Remove the pinion carrier mounting bolts. RCPH10FWD956AAJ 17. Install two CAS2496 alignment studs in opposite holes of the pinion carrier. RCPH10FWD957AAJ 48193194 12/10/2017 25.2 [25.102] / 268...
Page 383 Front axle system - Front bevel gear set and differential 18. Use a lifting device to remove the pinion carrier from the housing. Be careful not to damage the shim pack. RCPH10FWD958AAJ 19. Remove and retain the shim pack. RCPH10FWD959AAJ Pinion carrier disassembly 20.
Page 384 Front axle system - Front bevel gear set and differential 22. Pry the pinion seal from the housing. RCPH10FWD961AAJ 23. Remove the snap ring (1), seal (2), and snap ring (3) from the inside diameter of the pinion carrier housing. RCPH10FWD547ABJ 24.
Page 385 Front axle system - Front bevel gear set and differential 25. Use a snap ring pliers to remove the snap ring from the groove in the pinion shaft. NOTE: Because of the large diameter of the shaft, it will be necessary to use a flat blade screw driver through the second window of the compression sleeve to work the snap ring from the groove.
Page 386 Front axle system - Front bevel gear set and differential 29. Use a split knife edge puller attachment and press to remove the rear pinion bearing cone. RCPH10FWD967AAJ 30. Use a brass drift to remove the outer bearing cup from the carrier housing.
Page 387 Front axle system - Front bevel gear set and differential Brake carrier/bearing support removal 32. Rotate the differential housing so that the brake carrier side is on top. Remove the brake carrier retaining bolts and washers. RCPH10FWD970AAJ 33. Put a mark (1) on the brake carrier and housing for assembly reference.
Page 388 Front axle system - Front bevel gear set and differential 35. Remove and retain the differential bearing preload shims. RCPH10FWD973AAJ Brake carrier/bearing support disassembly 36. Position the carrier assembly on a sturdy work surface so that the split ring side is on top. Put a mark across the assembly for reference.
Page 389 Front axle system - Front bevel gear set and differential 38. Remove all bolts from the split ring. Remove the split retainer ring. RCPH10FWD976AAJ 39. Remove the belleville spring. RCPH10FWD977AAJ 40. Temporarily install the short jumper tube into the park brake pressure port.
Page 390 Front axle system - Front bevel gear set and differential 42. Remove the piston from the backing plate. RCPH10FWD980AAJ 43. Remove and discard the inner O-ring from the piston. RCPH10FWD981AAJ 44. Remove and discard the outer O-ring from the piston. RCPH10FWD982AAJ 45.
Page 391 Front axle system - Front bevel gear set and differential 46. Remove the four brake separator plates and four fric- tion plates from the carrier. RCPH10FWD984AAJ 47. Remove each of the three brake adjuster pins with belleville spring washers. RCPH11FWD340BAC 48.
Page 392 Front axle system - Front bevel gear set and differential 49. Use a short burst of compressed air to lift the brake piston out of the bore. RCPH10FWD988AAJ 50. Remove the piston from the carrier. RCPH11FWD339BAC 51. Remove and discard the O-ring from the outside di- ameter of the piston.
Page 393 Front axle system - Front bevel gear set and differential 52. Remove the eight bolts (1) and remove the brake in- sert (2). RCPH11FWD337BAC 53. Remove and discard the piston inside diameter O-ring from the brake insert. RCPH11FWD336AAC 54. Remove and discard the brake insert O-ring from car- rier assembly housing.
Page 394 Front axle system - Front bevel gear set and differential 55. Remove and discard the two seal rings from the hub of the carrier. RCPH10FWD992AAJ 56. If required, use a split knife edge puller attachment (1) and a puller (2) to remove the bearing cone from the hub of the carrier.
Page 395 Front axle system - Front bevel gear set and differential Differential removal and disassembly 58. Remove the lube return mesh screen from the hous- ing. RCPH10FWD995AAJ 59. Position a nylon lifting sling in a choker configuration as low as possible on the differential carrier. Use a hoist to lift the differential from the housing.
Page 396 Front axle system - Front bevel gear set and differential 61. If required, use a bearing puller and step plate to re- move the right hand side differential bearing cup. RCPH10FWD001ABJ 62. Remove and discard the large seal ring. RCPH10FWD002ABJ 63.
Page 397 Front axle system - Front bevel gear set and differential 64. Remove and discard the ring gear and cover attaching bolts. Use a brass drift and hammer to tap the ring gear free from the case. NOTE: The ring gear does not need to be removed unless the case or ring gear is to be replaced.
Page 398 Front axle system - Front bevel gear set and differential 67. Remove the differential side gear from the case. RCPH10FWD007ABJ 68. If equipped with differential lock, remove the four steel separator plates and three friction plates from the case. Remove the 6 anti-rotation dowel pins from the case.
Page 399 Front axle system - Front bevel gear set and differential 71. Remove the bolts securing the short pinion shafts in the case. RCPH10FWD011ABJ 72. Install an M8 x 1.25 bolt into the threaded hole in the end of each short pinion gear shaft. Remove the short shafts and spacer sleeves from the case.
Page 400 Front axle system - Front bevel gear set and differential 75. Remove the side gear from the bottom of the case. RCPH10FWD015ABJ 76. Remove the thrust washers for each spider gear from the case. RCPH10FWD016ABJ 77. Remove the thrust washer for the side gear from the bottom of the case.
Page 401 Front axle system - Front bevel gear set and differential Left hand differential bearing support disassembly 78. If required, rotate the differential housing so the left hand side differential bearing support carrier is on top. Remove the bearing support retaining bolts and wash- ers.
Page 402 Front axle system - Front bevel gear set and differential 81. Remove and discard the seal ring. RCPH10FWD021ABJ 82. If required, use a bearing puller and step plate to re- move the bearing cone from the hub of the bearing carrier.
Page 403: Assemble - 600 Series Axles (*)
Front axle system - Front bevel gear set and differential Differential - Assemble - 600 Series axles Steiger® 580 Steiger® 620 Dealer made tool Tool must be fabricated to assist in the shimming of the differential case to the differential housing. Take a 150 mm (6 in) piece (A) of 9.5 mm (0.375 in) steel rod and put a 45°...
Page 404 Front axle system - Front bevel gear set and differential 4. Lubricate inner bearing cone with clean operating oil. Install the bevel pinion gear into the carrier housing. RCPH10FWD026ABJ 5. Lubricate the front bearing cone with clean assembly lube. Install the bearing cone on the pinion shaft. RCPH10FWD027ABJ 6.
Page 405 Front axle system - Front bevel gear set and differential 8. Install and tighten the center bolt of the CAS2511 pin- ion bearing compression tool into the end of the pin- ion shaft. Install the compression sleeve, thrust washer and nut on the center bolt. RCPH10FWD030ABJ 9.
Page 406 Front axle system - Front bevel gear set and differential 12. Remove the compression sleeve, snap ring and thick spacer ring. RCPH10FWD033ABJ 13. Select a shim combination equal to the distance mea- sured in Step 11. Install the selected shim pack (thick- est shim first) and thick spacer ring on the pinion shaft.
Page 407 Front axle system - Front bevel gear set and differential 16. Loosen the nut on the center bolt at least two full turns. Strike the head of the center bolt two sharp blows with a heavy hammer to back seat the bearing against the snap ring.
Page 408 Front axle system - Front bevel gear set and differential 20. Install snap ring. RAIL17TR01399AA 21. Press the dust seal on until it is flush with the housing. RAIL17TR01398AA Differential case assembly procedures 22. Lubricate the thrust washer for the case with clean assembly grease.
Page 409 Front axle system - Front bevel gear set and differential 24. Install the side gear into the bore in the bottom of the case. RCPH10FWD037ABJ 25. Lubricate the needle bearing thrust ring with clean as- sembly grease. Install the thrust ring into the bore of the spider gear at the beveled end.
Page 410 Front axle system - Front bevel gear set and differential 28. Install the opposite side spider gear centered to the case bore and meshed with the side gear. RCPH10FWD041ABJ 29. Install the long spacer sleeve between the two spider gears so that the hole in the center of the sleeve is horizontal.
Page 411 Front axle system - Front bevel gear set and differential 32. Align the hole in the end of the short pinion pin with the threaded hole in the case. Repeat this procedure for the opposite short pinion shaft. RCPH10FWD043ABJ 33. Install the pinion pin retainer bolts. Tighten each bolt to the specified torque.
Page 412 Front axle system - Front bevel gear set and differential 35. Lubricate the seals of a new piston with clean assem- bly grease. RCPH10FWD045ABJ 36. Hand seat the differential lock piston into the bore of the case. RCPH10FWD046ABJ 37. Install the splined side gear on top of the pinion gears so that all gears are in mesh.
Page 413 Front axle system - Front bevel gear set and differential 39. Starting with a steel separator plate, alternately install 4 separator plates and 3 friction plates. Be sure the slots in the ears of the separator plates engage the dowel pins. Go to Step 41.
Page 414 Front axle system - Front bevel gear set and differential 42. Install the cover on top of the case so that the match marks align. RCPH10FWD005ABJ 43. Put a light coat of oil around the inside diameter of the ring gear. Install two of the CAS2496 alignment studs into opposite holes of the ring gear.
Page 415 Front axle system - Front bevel gear set and differential 45. Clamp the differential assembly in a press. Tighten the retaining bolts alternately and evenly in small in- crements in a star pattern to a final torque of 285 – 319 N·m (210 –...
Page 416 Front axle system - Front bevel gear set and differential 48. Use the universal bearing cup installer to install the bearing cup until seated. RCPH10FWD055ABJ 49. Install the Teflon seal ring in the groove of the hub. Lubricate the groove and the seal ring liberally with clean assembly grease.
Page 417 Front axle system - Front bevel gear set and differential 51. Lubricate and install a new seal ring in the groove of the bearing hub. RCPH10FWD021ABJ 52. Use a seal driver to install a new oil seal into the bearing carrier. Install the seal retaining screws and washers using L ®...
Page 418 Front axle system - Front bevel gear set and differential 54. Install two of the CAS2496 alignment studs opposite each other into the mounting flange. RCPH10FWD097ABJ 55. Use the CAS2494 lifting eye to install the pinion carrier assembly into the housing. NOTE: Do not install the shims at this time.
Page 419 Front axle system - Front bevel gear set and differential 57. Install the CAS1675-2 gauge block (1) between the pinion and Arbor (2) with the hole end of the gauge block held tightly against the end of the pinion. Use a feeler gauge to measure and record the distance between the end of the gauge block and arbor.
Page 420 Front axle system - Front bevel gear set and differential 61. Use the following table and example to calculate the pinion depth shim requirements. RCPH10FWD120FBJ (1) CAS2506 Pinion depth gauge arbor, (2) CAS1675-2 Pinion depth gauge block, (3) Pinion Item Metric value U.S.
Page 421 Front axle system - Front bevel gear set and differential 62. After pinion shim placement, remove the pinion carrier assembly. RCPH10FWD081ABJ 48193194 12/10/2017 25.2 [25.102] / 307...
Page 422 Front axle system - Front bevel gear set and differential Setting differential carrier bearing preload 63. Install two CAS2479 guide bolts into opposite holes of the left hand side bearing carrier bore. Install the orig- inal bearing preload shim pack over the guide bolts so that all holes align.
Page 423 Front axle system - Front bevel gear set and differential 67. Install two CAS2675 alignment studs into opposite holes of the housing. RCPH10FWD108ABJ 68. Install the dealer fabricated pin into pinion gears to stop pinion from rotating while shimming the differen- tial carrier to housing bearings.
Page 424 Front axle system - Front bevel gear set and differential 70. Install the bearing cone (large side down) onto the hub of the brake carrier. Use CAS2671 brake carrier bearing cone installer to drive the bearing cone onto the hub until seated. NOTE: The brake discs and seals are not installed in the brake carrier during the bearing preload procedures.
Page 425 Front axle system - Front bevel gear set and differential 74. Install the CAS2674 differential rolling torque adapter over the gear to engage two opposite splines. RCPH10FWD111ABJ 75. Connect a torque wrench to the adapter. Rotate the differential and measure the differential carrier bearing rolling torque.
Page 426 Front axle system - Front bevel gear set and differential Setting ring/pinion gear backlash 76. After adjusting differential carrier bearing preload cor- rectly, rotate the housing so the pinion carrier will be on top. Install two CAS2496 alignment studs oppo- site each other and install the pinion carrier shim pack previously assembled.
Page 427 Front axle system - Front bevel gear set and differential 80. If too much backlash was measured, the ring gear must be moved closer to the pinion gear. If too little backlash was measured, the ring gear must be moved away from the pinion gear.
Page 428 Front axle system - Front bevel gear set and differential 83. Reinstall the pinion gear carrier and tighten the re- taining bolts to the specified torque. Turn the pinion several revolutions in both directions to determine the tooth contact pattern. Remove the pinion carrier. NOTE: See the contact patterns in the following illustra- tions.
Page 429 Front axle system - Front bevel gear set and differential 85. Adding or subtracting pinion carrier shims to change pinion depth must be done in small increments until the correct tooth contact pattern is obtained. (A) Move the Drive Pinion (1) towards the ring gear (2) to move the contact pattern away from the Toe.
Page 430 Front axle system - Front bevel gear set and differential 88. Lubricate a new O-ring for the service brake insert with clean grease. Install the O-ring in the groove in the carrier. Be sure the O-ring is not twisted. RCPH11FWD335BAC 89.
Page 431 Front axle system - Front bevel gear set and differential 91. Lubricate a new O-ring for the outside diameter of the service brake piston. Install the O-ring in the groove of the piston. Be sure the O-ring is not twisted. RCPH11FWD338AAC 92.
Page 432 Front axle system - Front bevel gear set and differential 94. Place one pin with washers in each of the holes in the service brake piston. Be sure the spring washers are seated against the brake piston and the retaining snap ring side is pointed upwards.
Page 433 Front axle system - Front bevel gear set and differential 96. Install a steel separator plate over the first friction plate. Repeat the steps for remaining plates, alter- nating the friction and separator plates. RCPH10FWD127ABJ 97. When all the steel separator plates and the friction plates are installed, use the CAS2505 brake disc alignment tool to align the splines of all the plates.
Page 434 Front axle system - Front bevel gear set and differential 100. Install the park brake backing plate (recessed side up) over the guide studs so that the assembly match marks align. RCPH10FWD066ABJ 101. Lubricate and install a new O-ring for the large out- side diameter of the park brake piston.
Page 435 Front axle system - Front bevel gear set and differential 104. Install the large belleville spring with the cone side down on top of the park brake piston. RCPH10FWD070ABJ 105. Install the retainer ring over the belleville spring. RCPH10FWD071ABJ 106. Install and hand start the 12 bolts with washers to engage the threads.
Page 436 Front axle system - Front bevel gear set and differential 108. Turn the brake carrier assembly over and install the seal in the carrier. Install the seal retaining screws and washers using L ® 242® or equivalent to OCTITE secure screws. Torque screws to specified torque.
Page 437 Front axle system - Front bevel gear set and differential 111. Remove the guide studs. Install the brake carrier retaining bolts and washers. Torque the bolts to the specified torque. RCPH10FWD078ABJ Pinion carrier assembly installation 112. Lubricate and install a new O-ring in the groove around the mounting flange of the pinion carrier.
Page 438 Front axle system - Front bevel gear set and differential 114. Use the CAS2494 lifting eye to install the pinion car- rier assembly into the differential housing. Be sure the assembly marks align. RCPH10FWD081ABJ 115. Remove the guide studs and lifting eye, install the pinion carrier retaining bolts and washers.
Page 439 Front axle system - Front bevel gear set and differential 119. Lubricate and install new O-rings on the jumper tube for the service brake. Install the jumper tube (1) into the service brake supply port using a M10 X 1.5 bolt (2) in the threaded end of the jump tube.
Page 440 Front axle system - Front bevel gear set and differential 122. Install the port block on the differential housing. Tighten the retaining bolts to specifications. RCPH11FWD352BAC 123. Lubricate and install new O-rings on the jumper tube for the differential lock. Install the jumper tube into the differential lock supply port.
Page 441 Front axle system - Front bevel gear set and differential 125. Install the plug and fitting removed during disassem- bly. RCPH11FWD349BAC 126. If equipped, install the Differential Lock Solenoid on to the Port Block. RCPH11FWD348BAC 48193194 12/10/2017 25.2 [25.102] / 327...
Page 442 Front axle system - Front bevel gear set and differential 127. Install the tube line from the port block to the park brake supply port. RCPH11FWD347BAC 128. Install the tube (1) from the port block to the tee fitting on the differential housing. Install the horizontal tube (2) to the fittings on the differential housing.
Page 443 Front axle system - Front bevel gear set and differential 129. Install the lube tube from the port block to the pinion carrier. RCPH11FWD345CAC Next operation: Hydraulic service brakes - Test - Brake leak down (33.202) Differential lock - Leakage test (25.102) Next operation: Final drive - Install - 600 Series axles - wheeled (25.310) 48193194 12/10/2017...
Page 444: Disassemble - 600 Series Quadtrac® Axles (*)
Front axle system - Front bevel gear set and differential Differential - Disassemble - 600 Series Quadtrac® axles Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® Pinion carrier removal 1. The differential housing must be rotated several times during the disassembly and assembly procedures. If available, the housing should be mounted in a revolver repair stand (1).
Page 445 Front axle system - Front bevel gear set and differential 3. Remove the long tube line from the port block to the differential housing. RCPH10FWD943AAJ 4. Remove the tube line from the port block to the park brake supply port. RCPH10FWD944AAJ 5.
Page 446 Front axle system - Front bevel gear set and differential 6. Remove the differential lock solenoid from the port block. RCPH10FWD946AAJ 7. Remove the plug (1) and tee fitting (2) from the port block. RCPH10FWD947AAJ 8. Remove the jumper tube from the lube port. Discard the O-rings.
Page 447 Front axle system - Front bevel gear set and differential 9. Remove the jumper tube from the differential lock sup- ply port. Discard the O-rings. RCPH10FWD949AAJ 10. Remove the three bolts securing the port block to the housing. Remove the port block. RCPH10FWD950AAJ 11.
Page 448 Front axle system - Front bevel gear set and differential 12. Remove the jumper tube from the park brake supply port. Discard the O-rings. RCPH10FWD952AAJ 13. Remove the jumper tubes from the brake supply port. Discard the O-rings. RCPH10FWD953AAJ 14. Remove the drive yoke. NOTE: The front axle drive yoke does not use a retaining bolt.
Page 449 Front axle system - Front bevel gear set and differential 15. Install the CAS2494 lifting eye into the pinion gear. RCPH10FWD955AAJ 16. Remove the pinion carrier mounting bolts. RCPH10FWD956AAJ 17. Install two CAS2496 alignment studs in opposite holes of the pinion carrier. RCPH10FWD957AAJ 18.
Page 450 Front axle system - Front bevel gear set and differential 19. Remove and retain the shim pack. RCPH10FWD959AAJ Pinion carrier assembly 20. Remove the bolt securing the pinion gear lube tube. Disconnect and remove the tube, tube clamp and fit- ting.
Page 451 Front axle system - Front bevel gear set and differential 22. Remove the snap ring (1), seal (2), and snap ring (3) from the inside diameter of the pinion carrier housing. RCPH10FWD547ABJ 23. Support the pinion carrier on wood blocks on the work surface.
Page 452 Front axle system - Front bevel gear set and differential 25. Remove the compression sleeve assembly and snap ring from the pinion shaft. RCPH10FWD964AAJ 26. Remove the spacer ring and shim pack. Retain the shims. RCPH10FWD965AAJ 27. Support the pinion carrier on a press bed. Use the press to push the pinion shaft through the front bearing cone RCPH10FWD966AAJ...
Page 453 Front axle system - Front bevel gear set and differential 29. Use a brass drift to remove the outer bearing cup from the carrier housing. RCPH10FWD968AAJ 30. Use the CAS2510 adaptor plate (1) and a bearing puller (2) to remove the inner bearing cup from the carrier housing.
Page 454 Front axle system - Front bevel gear set and differential 33. Two threaded holes are provided in the flange of the carrier assembly. Use two of the retainer bolts that were removed to attach a lifting chain and hoist. Use the hoist to slowly and carefully lift the brake carrier assembly out of the housing.
Page 455 Front axle system - Front bevel gear set and differential 36. Starting with an end gap bolt, loosen each bolt in se- quence one full turn. Repeat until all tension is re- leased against the retaining ring. RCPH10FWD212ABJ 37. Remove all bolts from the split ring. Remove the split retainer ring.
Page 456 Front axle system - Front bevel gear set and differential 40. Use a short burst of compressed air to lift the park brake piston out of its bore. RCPH10FWD216ABJ 41. Remove the piston from the backing plate. RCPH10FWD217ABJ 42. Remove and discard the inner O-ring from the piston. RCPH10FWD218ABJ 43.
Page 457 Front axle system - Front bevel gear set and differential 44. Remove the brake backing plate. RCPH10FWD220ABJ 45. Remove the four brake separator plates and four fric- tion plates from the carrier. RCPH10FWD221ABJ 46. Remove each of the three brake adjuster pins with belleville spring washers.
Page 458 Front axle system - Front bevel gear set and differential 47. Temporarily install a short jumper tube into the service brake pressure port. RCPH10FWD224ABJ 48. Use a short burst of compressed air to lift the brake piston out of the bore. RCPH10FWD225ABJ 49.
Page 459 Front axle system - Front bevel gear set and differential 51. Remove the eight bolts (1) and remove the brake in- sert (2). RCPH11FWD337BAC 52. Remove and discard the piston inside diameter O-ring from the brake insert. RCPH11FWD336AAC 53. Remove and discard the brake insert O-ring from car- rier assembly housing.
Page 460 Front axle system - Front bevel gear set and differential 54. Remove and discard the two seal rings from the hub of the carrier. RCPH10FWD229ABJ 55. If required, use a split knife edge puller attachment (1) and a puller (2) to remove the bearing cone from the hub of the carrier.
Page 461 Front axle system - Front bevel gear set and differential Differential removal and disassembly 58. Position a nylon lifting sling in a choker configuration as low as possible on the differential carrier. Use a hoist to lift the differential from the housing. RCPH10FWD998AAJ 59.
Page 462 Front axle system - Front bevel gear set and differential 61. Remove and discard the large seal ring. RCPH10FWD002ABJ 62. Put a mark on the differential case for assembly refer- ence. RCPH10FWD003ABJ 63. Remove and discard the ring gear and cover attaching bolts.
Page 463 Front axle system - Front bevel gear set and differential 64. Remove the differential case cover. RCPH10FWD005ABJ 65. Remove the large thrust washer from the cover. RCPH10FWD006ABJ 66. Remove the differential side gear from the case. RCPH10FWD007ABJ 48193194 12/10/2017 25.2 [25.102] / 349...
Page 464 Front axle system - Front bevel gear set and differential 67. If equipped with differential lock, remove the four steel separator plates and three friction plates from the case. Remove the 6 anti-rotation dowel pins from the case. RCPH10FWD008ABJ 68. If equipped with differential lock, use a short burst of compressed air in the oil passage hole in the case to move the differential lock piston out of the bore.
Page 465 Front axle system - Front bevel gear set and differential 71. Install an M8 x 1.25 bolt into the threaded hole in the end of each short pinion gear shaft. Remove the short shafts and spacer sleeves from the case. NOTE: There are 28 uncaged needle roller bearings in each of the four pinion gears.
Page 466 Front axle system - Front bevel gear set and differential 75. Remove the thrust washers for each spider gear from the case. RCPH10FWD016ABJ 76. Remove the thrust washer for the side gear from the bottom of the case. Clean and inspect all differential parts for damage or wear.
Page 467 Front axle system - Front bevel gear set and differential 78. Install two CAS1995-6 guide bolts. Use three of the retaining bolts in the threaded holes provided. Tighten the bolts alternately and evenly to jack the bearing carrier out of the housing. Remove the bearing carrier and shims.
Page 468 Front axle system - Front bevel gear set and differential 81. Remove and discard the seal ring. RCPH10FWD021ABJ 82. If required, use a bearing puller and step plate to re- move the bearing cone from the hub of the bearing carrier.
Page 469: Assemble - 600 Series Quadtrac® Axles (*)
Front axle system - Front bevel gear set and differential Differential - Assemble - 600 Series Quadtrac® axles Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® Dealer made tool Tool must be fabricated to assist in the shimming of the differential case to the differential housing. Take a 150 mm (6 in) piece (A) of 9.5 mm (0.375 in) steel rod and put a 45°...
Page 470 Front axle system - Front bevel gear set and differential 4. Lubricate the inner bearing cone with clean operating oil. Install the bevel pinion gear into the carrier housing. RCPH10FWD026ABJ 5. Lubricate the front bearing cone with clean operating oil or assembly grease. Install the bearing cone on the pinion shaft.
Page 471 Front axle system - Front bevel gear set and differential 8. Install and tighten the center bolt of the CAS2511 pin- ion bearing compression tool into the end of the pin- ion shaft. Install the compression sleeve, thrust washer and nut on the center bolt. RCPH10FWD030ABJ 9.
Page 472 Front axle system - Front bevel gear set and differential 12. Remove the compression sleeve, snap ring and thick spacer ring. RCPH10FWD033ABJ 13. Select a shim combination equal to the distance mea- sured in step 11. Install the selected shim pack (thick- est shim first) and thick spacer ring on the pinion shaft.
Page 473 Front axle system - Front bevel gear set and differential 16. Loosen the nut on the center bolt at least two full turns. Strike the head of the center bolt two sharp blows with a heavy hammer to back seat the bearing against the snap ring.
Page 474 Front axle system - Front bevel gear set and differential 20. Install snap ring. RAIL17TR01399AA 21. Press the dust seal on until it is flush with the housing. RAIL17TR01398AA Differential case assembly procedures 22. Lubricate the thrust washer for the case with clean assembly grease.
Page 475 Front axle system - Front bevel gear set and differential 24. Install the side gear into the bore in the bottom of the case. RCPH10FWD037ABJ 25. Lubricate the needle bearing slave ring with clean as- sembly grease. Install the slave ring into the bore of the spider gear.
Page 476 Front axle system - Front bevel gear set and differential 28. Install the opposite side spider gear centered to the case bore and meshed with the side gear. RCPH10FWD041ABJ 29. Install the long spacer sleeve between the two spider gears so that the hole in the center of the sleeve is horizontal.
Page 477 Front axle system - Front bevel gear set and differential 32. Align the hole in the end of the short pinion pin with the threaded hole in the case. Repeat this procedure for the opposite short pinion shaft. RCPH10FWD043ABJ 33. Install the pinion pin retainer bolts. Tighten each bolt to specifications.
Page 478 Front axle system - Front bevel gear set and differential 35. Lubricate the seals of a new piston with clean assem- bly grease. RCPH10FWD045ABJ 36. Hand seat the differential lock piston into the bore of the case. RCPH10FWD046ABJ 37. Install the splined side gear on top of the pinion gears so that all gears are in mesh.
Page 479 Front axle system - Front bevel gear set and differential 39. Starting with a steel separator plate, alternately install 4 separator plates and 3 friction plates. Be sure the slots in the ears of the separator plates engage the dowel pins. NOTE: Soak the friction plates in clean operating fluid be- fore installation.
Page 480 Front axle system - Front bevel gear set and differential 42. Put a light coat of oil around the inside diameter of the ring gear. Install two of the CAS2496 alignment studs into opposite holes of the ring gear. Position the differential case over the ring gear.
Page 481 Front axle system - Front bevel gear set and differential 45. Use an appropriate bearing cup Installer to install the bearing cup into the cover until fully seated. RCPH10FWD053ABJ 46. Position the bearing cup into the bore of the right hand case.
Page 482 Front axle system - Front bevel gear set and differential 48. Install the Teflon seal ring in the groove of the hub. Lubricate the groove and the seal ring liberally with clean assembly grease. Be sure the ends of the seal ring are connected together.
Page 483 Front axle system - Front bevel gear set and differential 51. Use a seal driver to install a new oil seal into the bear- ing carrier. RCPH10FWD095ABJ 52. Install the 3 seal retainer bolts and washers. Apply thread sealant on the bolt threads. RCPH10FWD234ABJ Adjusting bevel pinion gear depth 53.
Page 484 Front axle system - Front bevel gear set and differential 55. Use a lifting eye to install the pinion carrier assembly into the housing. NOTE: Do not install the shims at this time. RCPH10FWD081ABJ 56. Install four equally spaced carrier assembly retaining bolts and washers.
Page 485 Front axle system - Front bevel gear set and differential 58. Remove the pinion carrier retaining bolts and lift the pinion carrier assembly from the housing. Remove the CAS2506 arbor. RCPH10FWD100ABJ 59. A correction factor number is etched onto the head end of the pinion.
Page 486 Front axle system - Front bevel gear set and differential RCPH10FWD120FBJ (1) CAS2506 pinion depth gauge arbor, (2) pinion depth gauge block, (3) pinion Item Metric value U.S. value 97.99 mm 3.858 in 75.82 mm 2.985 in 174.25 mm 6.860 in .44 mm 0.017 in Gap measurement...
Page 487 Front axle system - Front bevel gear set and differential Setting differential carrier bearing preload 62. Install two CAS2675 guide bolts into opposite holes of the left hand side bearing carrier bore. Install the orig- inal bearing preload shim pack over the guide bolts so that all holes align.
Page 488 Front axle system - Front bevel gear set and differential 66. Install two CAS2675 alignment studs into opposite holes of the housing. RCPH10FWD239ABJ 67. Install the dealer fabricated pin into pinion gears to stop pinion from rotating while shimming the differen- tial carrier to housing bearings.
Page 489 Front axle system - Front bevel gear set and differential 68. Install the original shim pack for the brake carrier and bearing support over the alignment studs so that all holes align. RCPH10FWD210ABJ 69. Use a hoist to carefully install the brake carrier into the housing so that the marks put on during disassembly, align.
Page 490 Front axle system - Front bevel gear set and differential 71. Install the right hand axle stub shaft into the differen- tial. RCPH10FWD241ABJ 72. Install the CAS2508 differential rolling torque adapter over the gear. RCPH10FWD242ABJ 73. Connect a torque wrench to the adapter. Rotate the differential and measure the differential carrier bearing rolling torque.
Page 491 Front axle system - Front bevel gear set and differential ATTENTION: Differential locking pin MUST be removed at this time. RCPH11FWD368BAC Setting the ring/pinion gear backlash 75. After adjusting differential carrier bearing preload cor- rectly, rotate the housing so the pinion carrier will be on top.
Page 492 Front axle system - Front bevel gear set and differential 77. Install four pinion carrier retaining bolts and washers equally spaced. Tighten the four bolts to specifica- tions. RCPH10FWD114ABJ 78. Install the drive yoke on the pinion gear. Use a dial indicator to measure ring/pinion gear backlash.
Page 493 Front axle system - Front bevel gear set and differential Checking for correct bevel pinion/gear tooth contact 80. After differential bearing preload and ring/pinion gear backlash adjustments have been completed, remove the pinion carrier. RCPH10FWD081ABJ 81. Put Prussian Blue or red lead on both sides of several ring gear teeth.
Page 494 Front axle system - Front bevel gear set and differential Inspect the contact pattern of the gear teeth. Compare the contact pattern with the following illustrations and tables, for both the right hand (rear) and the left hand (front) pinion sets, and determine the correct tooth con- tact pattern.
Page 495 Front axle system - Front bevel gear set and differential Values Item Metric value U.S. value 5 – 8 mm 0.197 – 0.315 in 2 – 4 mm 0.079 – 0.157 in 30 – 35 mm 1.181 – 1.378 in 40 –...
Page 496 Front axle system - Front bevel gear set and differential Right hand brake carrier assembly procedure 85. If removed, install the bearing cone (large side down) on the hub of the carrier. Use an appropriate bearing installer and handle to drive the bearing cone on the hub until seated.
Page 497 Front axle system - Front bevel gear set and differential 88. Lubricate a new O-ring for the inside diameter of the service brake piston with clean grease. Install the O-ring in the groove of the brake insert. Be sure the O-ring is not twisted.
Page 498 Front axle system - Front bevel gear set and differential 91. Install the service brake piston into the recessed bore of the carrier with the flat side up, aligning the ear tabs with the slots in the support carrier. RCPH11FWD339BAC 92.
Page 499 Front axle system - Front bevel gear set and differential 94. Lubricate all friction plates with clean operating fluid. Install the first friction plate over the brake return plate. NOTE: Align the friction plate oil cross holes as they are installed.
Page 500 Front axle system - Front bevel gear set and differential 98. Install the two guide studs into opposite holes of the support carrier. RCPH10FWD258ABJ 99. Install the park brake backing plate (recessed side up) over the guide studs so that the assembly match marks align.
Page 501 Front axle system - Front bevel gear set and differential 102. Lubricate the outside diameter and inside diameter of the piston liberally with clean assembly grease. Hand seat the piston squarely into the bore of the backing plate. RCPH10FWD262ABJ 103. Install the large belleville spring with the cone side down on top of the park brake piston.
Page 502 Front axle system - Front bevel gear set and differential 106. After all bolts have contacted the retainer ring, start- ing with an end bolt, tighten each bolt in sequence one full turn and repeat until the ring has seated on the backing plate.
Page 503 Front axle system - Front bevel gear set and differential 110. Assemble the brake carrier as described in steps 85 through 108. RCPH10FWD259ABJ 111. Using the CAS2675 guide studs, install the pre-se- lected shim pack for the brake support carrier so that all holes align.
Page 504 Front axle system - Front bevel gear set and differential 113. Remove the guide studs. Install the brake carrier re- taining bolts and washers. Tighten the bolts to spec- ifications. RCPH10FWD267ABJ 114. Lubricate and install a new O-ring in the groove around the mounting flange of the pinion carrier.
Page 505 Front axle system - Front bevel gear set and differential 116. Use a lifting eye to install the pinion carrier assembly into the differential housing. Be sure the assembly marks align. RCPH10FWD081ABJ 117. Remove the guide studs and lifting eye, install the pinion carrier retaining bolts and washers.
Page 506 Front axle system - Front bevel gear set and differential 121. Lubricate and install new O-rings on the jumper tube for the service brake. Install the jumper tube into the service brake supply port. RCPH10FWD270ABJ 122. Lubricate and install new O-rings on the port block. RCPH10FWD271ABJ 123.
Page 507 Front axle system - Front bevel gear set and differential 125. Lubricate and install new O-rings on the jumper tube for the lube supply. Install the jumper tube into the lube supply port. RCPH10FWD948AAJ 126. Install the differential lock solenoid on the port block. RCPH10FWD091ABJ Next operation: Hydraulic service brakes - Test - Brake leak down (33.202) Differential lock - Leakage test (25.102)
Page 508 Front axle system - Front bevel gear set and differential Differential lock - Leakage test 1. Connect the Test Coupler Assembly to the differential lock port fitting. RCPH10FWD436ABJ 2. Connect the Air/Hydraulic Pump to the test coupler. Operate the pump slowly until 20 bar (290 psi) is in- dicated on the pressure gauge.
Page 509 Index Front axle system - 25 Front bevel gear set and differential - 102 Differential - Assemble - 400 Series axles (*) ..........Differential - Assemble - 500 Series Quadtrac®...
Page 510 48193194 12/10/2017 25.2 [25.102] / 396...
Page 511 Front axle system - 25 Final drives - 310 Steiger® 370 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 370 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 512 TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® CVT, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 513 48193194 12/10/2017 25.3 [25.310] / 1...
Page 514 Contents Front axle system - 25 Final drives - 310 SERVICE Final drive Remove - 400 Series bar axles (*) ............3 Disassemble - 400 Series bar axles (*) .
Page 515 Front axle system - Final drives Final drive - Remove - 400 Series bar axles Steiger® 370 Steiger® 420 Steiger® 470 1. Position the axle assembly (pinion carrier up) on short heavy boards (planking). Put assembly reference marks across each final drive housing and center housing.
Page 516 Front axle system - Final drives 4. Remove the bolts securing the axle housing and sta- tionary ring gear to the differential housing. RCPH10FWD286FBJ 5. Use the hoist to lift and release the final drive housing a small amount several times to weaken the sealant bond.
Page 517 Front axle system - Final drives Final drive - Disassemble - 400 Series bar axles Steiger® 370 Steiger® 420 Steiger® 470 1. Use the CNH299075 lifting hook to remove the station- ary ring gear from the axle housing. RCPH10FWD289FBJ 2. Remove the nylon thrust button from the end of the axle shaft.
Page 518 Front axle system - Final drives 4. Use the CAS2676 planetary carrier lifting hook to re- move the planetary assembly from the housing. NOTICE: Be sure the retaining strap is positioned behind the gear to prevent the lifting fixture from pulling out of the planetary gear shaft.
Page 519 Front axle system - Final drives 7. Remove the snap ring from the groove of the axle. RCPH10FWD294FBJ 8. Remove the thrust ring from the axle shaft. RCPH10FWD896AAJ 9. Remove and retain the shims from the axle shaft. RCPH10FWD897AAJ 48193194 12/10/2017 25.3 [25.310] / 7...
Page 520 Front axle system - Final drives 10. For the 450 series axles, remove the axle outer oil seal retaining bolts and washers. RCPH10FWD295FBJ For the 425 series axles, drill a hole, install a screw to pry against and remove the oil seal from the final drive housing.
Page 521 Front axle system - Final drives 12. Install the hydraulic ram between the puller bridge and the end of the axle. Press the axle through the inner bearing cone. Remove the axle from the housing. Discard the outer seal. Remove the puller bridge and ram.
Page 522 Front axle system - Final drives 15. To remove the axle outer bearing, oil seal and bush- ing, place an appropriate sized press plate on a press bed. Install the 380002920 lifting eye into the threaded hole in the end of the axle shaft. Use a lifting device to place the axle on the press plate so that the oil seal is resting on the press plate.
Page 523 Front axle system - Final drives Planetary carrier disassembly 18. If the gears are to be reused, mark each gear and the carrier so that the gears and pins are assembled in their original location in the gear carrier. RCPH10FWD297FBJ 19.
Page 524 Front axle system - Final drives 21. Carefully remove the planetary gear assembly with thrust washers from the carrier. RCPH10FWD300FBJ 22. Remove the needle roller bearings and separator ring from within the gear. Repeat steps 18 through 22 for each remaining planet gear. Clean and inspect all final drive gears, bearings and other parts for too much wear or other damage.
Page 525 Front axle system - Final drives Final drive - Replace - 425 bar axle, outer seal Steiger® 370 Steiger® 420 Steiger® 470 Prior operation: Frame - Raise - Tractor jacking points (39.100) 1. Remove the wheel and tire. 2. Drain enough oil from the final drive of the axle to below the bottom of the seal bore.
Page 526 Front axle system - Final drives 5. Drill a hole and install a screw into the seal for a pry point. RAIL12TR2339AA 6. Pry out and remove the seal. RAIL12TR2340AA 7. Clean all sealant from the housing (1) where the outer diameter of the seal sits.
Page 527 Front axle system - Final drives 8. Fill the inner two grooves of a new axle seal approx- imately half full with clean grease. Apply L ® OCTITE 515™ sealant around the outside diameter of the new seal. RAIL12TR2342AA 9. Install the seal over the axle shaft and align squarely to the bore of the axle housing.
Page 528 Front axle system - Final drives 11. Use the 380003282 axle seal installer (1) and the ta- pered split bushing (2), as shown, to install the seal to the correct depth in the housing. RAIL12TR2345AA 12. Remove the tapered split bushing (1) and 380003282 seal installation tool (2) from the axle.
Page 529 Front axle system - Final drives Final drive - Assemble - 400 Series bar axles Steiger® 370 Steiger® 420 Steiger® 470 Planetary carrier assembly 1. Lubricate the needle roller bearings with clean grease or petroleum jelly and load 33 bearings on one side of the gear.
Page 530 Front axle system - Final drives 4. Lubricate the thrust washers with clean grease or pe- troleum jelly. Install one thrust washer on each side of the gear. Adjust the pilot sleeve to engage the thrust washers to hold them in place. RCPH10FWD304FBJ 5.
Page 531 Front axle system - Final drives 8. Install a new spring pin into the gear shaft until the pin is midway into the gear shaft. Repeat steps 1 through 8 for each planet gear assembly installation. RCPH10FWD298FBJ Final drive housing assembly CAUTION Hot area! Use care when working near hot components.
Page 532 Front axle system - Final drives 10. Install the bushing onto the axle shaft. Use a suitable driver anvil to drive the bushing until it is fully seated on the flange. RCPH10FWD331ABJ 11. Use a bearing oven to heat the bearing to 110 °C (230 °F).
Page 533 Front axle system - Final drives 13. Put a light film of anti-sieze compound around the outside diameter of the outer bearing cup. Use the CAS2501 bearing cup installer (1) and a short handle (2) to install the bearing cup into the final drive hous- ing until the cup is seated.
Page 534 Front axle system - Final drives 16. Install the CAS2666 puller screw with washer tightly into the end of the axle shaft. RCPH10FWD893AAJ 17. Install the CAS2666 spacer sleeve (or suitable spacer sleeve) over the axle and against the bearing cone. RCPH10FWD929AAJ 18.
Page 535 Front axle system - Final drives 19. Temporarily install the thrust ring (1) and new retaining ring (2) on the axle. Be sure the snap ring is against the outer side of the groove and fully seated. RCPH10FWD895AAJ 20. Use a thickness gauge to measure and record the distance between the thrust ring and the snap ring in at least two locations.
Page 536 Front axle system - Final drives 22. Install the 380002851 axle shaft remover bridge and twin ram onto the housing. Press on the axle until 14000 – 24500 kPa (2031 – 3553 psi) is shown on the pressure gauge to back seat the bearing against the retaining ring.
Page 537 Front axle system - Final drives 25. For the 450 series axles: Install the outer oil seal, retaining screws and flat washers. RCPH10FWD295FBJ For the 425 series axles: Fill the inner two grooves of a new axle seal approximately half full with clean grease. Apply L ®...
Page 538 Front axle system - Final drives 27. Install the planetary carrier retaining ring in the groove on the end of the axle shaft. RCPH10FWD310FBJ 28. Install a new nylon thrust insert in the counter-bore on the end of the axle shaft. Retain the insert with clean grease.
Page 539 Front axle system - Final drives 30. Carefully align and install the stationary ring gear on the housing so the dowel pin holes and match marks made at disassembly will align. NOTE: Repeat steps 1 through 29 to assemble the oppo- site side final drive.
Page 540 Front axle system - Final drives Final drive - Install - 400 Series bar axles Steiger® 370 Steiger® 420 Steiger® 470 1. Put a 3 mm (0.12 in) bead of anaerobic sealant around the mating flange of the final drive housing. RCPH10FWD311FBJ 2.
Page 541 Front axle system - Final drives 4. If not previously installed, install the short axle sun gear into the planetary carrier. Install the stationary ring gear on the planetary carrier so that the assembly match marks align and the dowel pins engage the ring gear. NOTICE: The longer of the two short axles must be in- stalled on the right hand (brake carrier) side of the differ- ential housing.
Page 542 Front axle system - Final drives 7. Install the final drive housing retaining bolts with wash- ers. Tighten the bolts alternately from side to side to pull the final drive onto the dowel pins. Tighten the bolts to specifications. Repeat the above procedures for the opposite side final drive.
Page 543 Front axle system - Final drives Final drive - Remove - 500 Series axles Steiger® 500 Steiger® 540 1. Position the axle assembly on a clean shop floor. Put assembly reference marks across each final drive housing to the differential housing. RCPH10FWD884AAJ 2.
Page 544 Front axle system - Final drives 4. Remove the 18 bolts securing the trumpet housing and stationary ring gear to the differential housing. RCPH10FWD887AAJ 5. Use the hoist to lift and release the trumpet housing a small amount several times to weaken the sealant bond.
Page 545 Front axle system - Final drives Final drive - Disassemble - 500 Series axles Steiger® 500 Steiger® 540 1. Remove the nylon thrust button from the end of the axle shaft. RCPH10FWD889AAJ 2. Remove the snap ring securing the planetary carrier assembly to the axle.
Page 546 Front axle system - Final drives 4. Use the CNH299075 lifting hook to remove the station- ary ring gear from the axle housing. RCPH10FWD892AAJ 5. Remove the oil seal and the retaining screws and wash- ers from the final drive housing. RCPH10FWD546ABJ 6.
Page 547 Front axle system - Final drives 7. Install the CAS2666 bearing installer tube (1) over the axle and against the bearing cone. Install a twin ram over the puller screw and install the nut (2) on the puller screw. Hand tighten the nut to hold the spacer centered against the bearing.
Page 548 Front axle system - Final drives 10. Remove and retain the shims from the axle shaft. RCPH10FWD897AAJ 11. Install the 380002851 axle shaft remover bridge (1) securely on the axle housing in the location shown. Tighten the eight attaching bolts (2) tightly on the axle housing and puller bridge.
Page 549 Front axle system - Final drives 13. Use CAS2663 bearing driver and CAS2405 long bear- ing driver handle to remove the outer bearing cup from the housing. RCPH10FWD900AAJ 14. Use the appropriate size bearing driver and CAS2405 long bearing driver handle to remove the inner bearing cup from the housing.
Page 550 Front axle system - Final drives 16. Use the press to remove the outer axle bearing cone and seal wear ring. NOTE: Place a heavy wood block under the press bed for the axle to fall on. RCPH10FWD903AAJ 17. Remove and discard the O-ring from the seal wear ring.
Page 551 Front axle system - Final drives 19. Drive the spring pin into the center of the gear shaft. RCPH10FWD912AAJ 20. Use the CNH299048 pilot sleeve to push the gear shaft out and retain the needle roller bearings in the gear. NOTE: There is a double row of non caged needle roller bearings in each gear.
Page 552 Front axle system - Final drives Final drive - Assemble - 500 Series axles Steiger® 500 Steiger® 540 Planetary carrier assembly 1. Lubricate the needle roller bearings with clean grease or petroleum jelly and load 29 bearings on one side of the gear.
Page 553 Front axle system - Final drives 4. Carefully put the planet gear into its original position in the gear carrier while holding the pilot sleeve in place. RCPH10FWD914AAJ 5. While maintaining tension on the pilot sleeve from the bottom, align the gear and carefully push the gear shaft through the thrust washer and bearings.
Page 554 Front axle system - Final drives Final drive housing assembly 8. Lubricate and install a new O-ring into the groove in the inside diameter of the axle seal wear ring. RCPH10FWD921AAJ 9. Install the axle seal wear ring on the axle shaft (flat side up) until the seal ring is seated on the flange of the axle.
Page 555 Front axle system - Final drives 11. Install the heated bearing cone on the axle shaft (large side down) against the seal wear ring. RCPH10FWD924AAJ If the bearing cone did not seat against the seal ring (or if a bearing heater was not available), temporarily in- stall the cup over the cone.
Page 556 Front axle system - Final drives 12. Put a light coat of anti-sieze compound around the outside diameter of the outer bearing cup. Use the CAS2501 bearing cup installer (1) and 380001108 short handle (2) to install the bearing cup into the trum- pet housing until the cup is seated.
Page 557 Front axle system - Final drives 15. Install the CAS2666 puller screw with washer tightly into the end of the axle shaft. RCPH10FWD893AAJ 16. Install the CAS2666 spacer sleeve over the axle and against the bearing cone. RCPH10FWD929AAJ 17. Install the twin ram. Press the inner bearing cone onto the axle shaft while rotating the ram back and forth by hand until there is a noticeably tight preload on the axle bearings.
Page 558 Front axle system - Final drives 18. Temporarily install the thrust ring (1) and new retaining ring (2) on the axle. Be sure the snap ring is against the far side of the groove and fully seated. RCPH10FWD895AAJ 19. Use a thickness gauge to measure and record the distance between the thrust ring and the snap ring in at least two locations.
Page 559 Front axle system - Final drives 21. Install the 380002851 axle shaft remover bridge and a 45.36 t (100000 lb) twin ram onto the trumpet hous- ing. Press on the axle until 13790 – 24132 kPa (2000 – 3500 psi) is shown on the pressure gauge to back seat the bearing against the retaining ring.
Page 560 Front axle system - Final drives 24. Use the CNH299075 lifting hook to carefully align and install the stationary ring gear on the housing so the dowel pin holes will align. NOTE: The lifting hook must be placed mid way between the two dowel pin holes in the ring gear.
Page 561 Front axle system - Final drives 26. On each large planetary gear, there are light scribe lines on the tips of two consecutive gear teeth. The lines vary in length, but are always found on the side farthest from the small gear. The gap between the two teeth must point to the center of the axle.
Page 562 Front axle system - Final drives 29. Install a new nylon thrust insert in the counter-bore on the end of the axle shaft. Retain the insert with clean grease. Install the short axle sun gear into the planetary gears so that every 7th tooth on the sun gear will be in the root between the two marked teeth of each planet gear.
Page 563 Front axle system - Final drives Final drive - Install - 500 Series axles Steiger® 500 Steiger® 540 1. Install the short axle sun gear shafts into the left hand and right hand sides of the differential. The longer of the two shafts must be installed in the brake carrier (right hand) side.
Page 564 Front axle system - Final drives 4. Lift and align the final drive housing with the differential housing so the short axle shaft will engage the differen- tial and the assembly marks on the differential housing and final drive housing align and the housing will en- gage the alignment studs.
Page 565 Front axle system - Final drives Final drive - Remove - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® 1. Position the axle assembly on a clean shop floor with access to an overhead hoist. Disconnect both track tension pressure hoses at the tee fitting in the center housing.
Page 566 Front axle system - Final drives 4. Put blocking under one final drive housing to keep the axle assembly level when the opposite final drive hous- ing is removed. RCPH10FWD135ABJ 5. Connect an overhead hoist to the final drive housing. Take-up the weight of the housing.
Page 567 Front axle system - Final drives 7. Use the hoist to lift and release the final drive housing a small amount several times to weaken the sealant bond. Use a pry bar between the stationary ring gear and differential housing to pry the ring gear out of the dowel pins.
Page 568 Front axle system - Final drives Final drive - Disassemble - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® 1. Remove the stationary ring gear from the axle housing. RCPH10FWD140ABJ 2. Remove the nylon thrust button from the end of the axle shaft.
Page 569 Front axle system - Final drives 4. Use the CAS2676 planetary carrier lifting hook to re- move the planetary assembly from the housing. NOTICE: Be sure the retaining strap is positioned behind the gear to prevent the lifting fixture from pulling out of the pinion gear shaft.
Page 570 Front axle system - Final drives 7. Use the 380002570 spanner wrench to loosen the lock nut two complete turns. NOTE: The number of complete turns required to remove the nut must be counted and recorded for proper installa- tion. RCPH10FWD146ABJ 8.
Page 571 Front axle system - Final drives 11. Remove the inner face seal from the axle housing. RCPH10FWD150ABJ 12. Use CAS2739 bearing driver and CAS2405 long bear- ing driver handle to remove the inner bearing cup from the housing. RCPH10FWD151ABJ 13. Use CAS2667 plate (1) and a bearing puller (2) to remove the outer bearing cup from the housing.
Page 572 Front axle system - Final drives 14. Remove the outer face seal from the axle shaft. RCPH10FWD153ABJ 15. Use a bearing puller and 30 ton ram to remove the outer bearing cone. RCPH10FWD154ABJ 48193194 12/10/2017 25.3 [25.310] / 60...
Page 573 Front axle system - Final drives Planetary carrier disassembly 16. If the gears are to be reused, mark each gear and the carrier so that the gears and pins are assembled in their original location in the gear carrier. RCPH10FWD155ABJ 17.
Page 574 Front axle system - Final drives 19. Carefully remove the planetary gear assembly with thrust washers from the carrier. RCPH10FWD158ABJ 20. Remove the needle roller bearings and separator ring from within the gear. Repeat steps 16 through 20 for each remaining planet gear. Clean and inspect all final drive gears, bearings and other parts for too much wear or other damage.
Page 575 Front axle system - Final drives 22. Mark the location of the clamp bracket. Remove the bolts securing the offset housing to the center hous- ing. RCPH10FWD161ABJ 23. Install two CAS2496 alignment studs in the locations shown. Separate the offset housing from the center housing dowel pins.
Page 576 Front axle system - Final drives 26. Mark the top side of each gear assembly for reference. Remove the gears from the housing. RCPH10FWD165ABJ 27. Use a split flange type bearing puller and 89 mm (3.5 in) press sleeve to press the bearing cones from each side of the gears requiring bearing or gear replacement.
Page 577 Front axle system - Final drives 30. Repeat step 28 to remove the bearing cups from the cover. Clean and inspect all parts. RCPH10FWD169ABJ 48193194 12/10/2017 25.3 [25.310] / 65...
Page 578 Front axle system - Final drives Final drive - Assemble - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Planetary carrier assembly 1. Lubricate the needle roller bearings with clean grease or petroleum jelly and load 29 bearings on one side of the gear.
Page 579 Front axle system - Final drives 4. Lubricate the thrust washers with clean grease or pe- troleum jelly. Install one thrust washer on each side of the gear. Adjust the pilot sleeve to engage the thrust washers to hold them in place. RCPH10FWD175ABJ 5.
Page 580 Front axle system - Final drives 8. Install a new spring pin into the gear shaft until the end of the pin is flush or slightly below the edge of the carrier housing. Repeat steps 1 through 8 for each planet gear assembly installation.
Page 581 Front axle system - Final drives 11. Put a light coat of anti-sieze compound around the outside diameter of the outer bearing cup. Use the CAS2501 bearing cup installer (1) and a short driver handle (2) to install the bearing cup into the final drive housing until the cup is seated.
Page 582 Front axle system - Final drives 14. Seat the seal assembly squarely in the bore of the hub as shown. Put a light film of clean CASE IH AKCELA HY-TRAN® ULTRACTION oil on the steel face of the seal. RCPH10FWD180ABJ 15.
Page 583 Front axle system - Final drives 17. Install the inner bearing cone (1) and lock nut (2) on the axle shaft. RCPH10FWD144ABJ 18. Use the 380002906 spanner wrench and torque wrench to tighten the lock nut to a rolling torque of 27 –...
Page 584 Front axle system - Final drives 20. Install the inner bearing cone (1) and lock nut (2) on the axle shaft. RCPH10FWD144ABJ 21. Use the 380002906 spanner wrench to tighten the lock nut the same number of complete turns that were required for removal.
Page 585 Front axle system - Final drives 23. Coat the splines of the axle shaft with anti-sieze com- pound. Use the CAS2676 Planetary Lifting Hook to install the planetary carrier assembly on the axle shaft. RCPH10FWD143ABJ 24. Install the planetary carrier retaining ring in the groove on the end of the axle shaft.
Page 586 Front axle system - Final drives 26. Clean the mating surface of the final drive housing of all residual sealant. Apply a 3 mm (0.12 in) bead of anaerobic sealant around the mounting surface of the axle housing. RCPH10FWD184ABJ 27. Carefully align and install the stationary ring gear on the housing so the dowel pin holes will align.
Page 587 Front axle system - Final drives 30. Use a bearing cup installer to install both bearing cups in the cover. RCPH10FWD187ABJ 31. Use a bearing cup installer to seat the bearing cup in the bore of the housing. RCPH10FWD188ABJ 32. Install the remaining bearing cup in the housing. RCPH10FWD189ABJ 33.
Page 588 Front axle system - Final drives 34. Align and install the gear cover. Torque the bolts to 90 – 100 N·m (66 – 74 lb ft). RCPH10FWD191ABJ 35. Install one of the short differential axle shafts into the gear. RCPH10FWD192ABJ 36.
Page 589 Front axle system - Final drives 38. If rolling torque is not within tolerance, remove the cover, gear and bearing cup from the housing and add or remove selective shims as required. Reassemble and check rolling torque. RCPH10FWD168ABJ 39. After the rolling torque has been adjusted for the 36 tooth gear, remove the cover and gear.
Page 590 Front axle system - Final drives Final drive - Install - 500 Series Quadtrac® axles Steiger® 470 Quadtrac® Steiger® 500 Quadtrac® Steiger® 540 Quadtrac® Offset housing installation 1. Install the short axle stub shafts (1) into the left hand and right hand sides of the differential. The longer of the two shafts must be installed in the brake carrier (right hand) side.
Page 591 Front axle system - Final drives 4. Push the offset housing onto the dowel pins. RCPH10FWD200ABJ 5. Install the offset housing mounting bolts. Tighten the bolts alternately and evenly to 284 – 298 N·m (209 – 220 lb ft). Be sure the clamp bracket (1) is installed in the right location.
Page 592 Front axle system - Final drives 7. Install the sun gear into the housing. RCPH10FWD203ABJ 8. Install two CAS2496 alignment studs into the offset housing horizontally opposite each other. RCPH10FWD204ABJ 9. Lift and align the final drive assembly to the offset hous- ing so the assembly marks align and the housing will engage the alignment studs.
Page 593 Front axle system - Final drives 10. Install the final drive mounting bolts and washers. Tighten the bolts alternately and evenly to 284 – 298 N·m (209 – 220 lb ft). NOTE: Repeat steps 6 through 10 for the opposite side final drive installation.
Page 594 Front axle system - Final drives Final drive - Remove - 600 Series axles - wheeled Steiger® 580 Steiger® 620 Prior operation: Powered front axle - Remove - High power frame wheeled tractors (25.100) 1. Position the axle assembly on a clean shop floor. Put assembly reference marks across each final drive housing to the differential housing.
Page 595 Front axle system - Final drives 4. Remove the 18 bolts securing the trumpet housing and stationary ring gear to the differential housing. RCPH10FWD887AAJ 5. Use the hoist to lift and release the trumpet housing a small amount several times to weaken the sealant bond.
Page 596 Front axle system - Final drives Final drive - Disassemble - 600 Series axles - wheeled Steiger® 580 Steiger® 620 1. Remove the nylon thrust button from the end of the axle shaft. RCPH10FWD889AAJ 2. Remove the snap ring securing the planetary carrier assembly to the axle.
Page 597 Front axle system - Final drives 4. Use the CNH299075 lifting hook to remove the station- ary ring gear from the axle housing. NOTE: Use a pry bar between the trumpet housing and the stationary ring gear to pry the ring gear off the dowel pins. RCPH10FWD892AAJ 5.
Page 598 Front axle system - Final drives 7. Install the CAS2666 bearing installer tube (1) over the axle and against the bearing cone. Install a twin ram over the puller screw and install the nut (2) on the puller screw. Hand tighten the nut to hold the spacer centered against the bearing.
Page 599 Front axle system - Final drives 10. Remove and retain the shims from the axle shaft. RCPH10FWD897AAJ 11. Install the 380002851 axle shaft remover bridge (1) securely on the axle housing in the location shown. Tighten the eight attaching bolts (2) tightly on the axle housing and puller bridge.
Page 600 Front axle system - Final drives 13. Use a three jaw puller and a slide hammer to remove the outer bearing cup from the housing. RCPH11FWD328BAC 14. Use a three jaw puller and a slide hammer to remove the inner bearing cup from the housing. RCPH11FWD327BAC 15.
Page 601 Front axle system - Final drives 16. Use the press to remove the outer axle bearing cone and seal wear ring. NOTE: Place a heavy wood block under the press bed for the axle to fall on. RCPH10FWD903AAJ 17. Remove and discard the O-ring from the seal wear ring.
Page 602 Front axle system - Final drives 19. Drive the spring pin into the center of the gear shaft. RCPH10FWD912AAJ 20. Use the CNH299048 pilot sleeve to push the gear shaft out and retain the needle roller bearings in the gear. NOTE: There is a double row of non caged needle roller bearings in each gear.
Page 603 Front axle system - Final drives Final drive - Assemble - 600 Series axles - wheeled Steiger® 580 Steiger® 620 Planetary carrier assembly 1. Lubricate the needle roller bearings with clean grease or petroleum jelly and load 29 bearings on one side of the gear.
Page 604 Front axle system - Final drives 4. Carefully put the planet gear into its original position in the gear carrier while holding the pilot sleeve in place. RCPH10FWD914AAJ 5. While maintaining tension on the pilot sleeve from the bottom, align the gear and carefully push the gear shaft through the thrust washer and bearings.
Page 605 Front axle system - Final drives Final drive housing assembly 8. Lubricate and install a new O-ring into the groove in the inside diameter of the axle seal wear ring. RCPH10FWD921AAJ 9. Coat the inside diameter of the axle seal wear ring be- low the O-ring with L ®...
Page 606 Front axle system - Final drives 11. Install the heated bearing cone on the axle shaft (large side down) against the seal wear ring. RCPH10FWD924AAJ If the bearing cone did not seat against the seal ring (or if a bearing heater was not available), temporarily install the cup over the cone.
Page 607 Front axle system - Final drives 12. Put a light coat of L ® A compound OCTITE EIZE around the outside diameter of the outer bearing cup. Use the appropriate size bearing cup installer (1) and 380001108 short handle (2) to install the bearing cup into the trumpet housing until the cup is seated.
Page 608 Front axle system - Final drives 15. Install the CAS2666 CNH299024 puller screw with washer tightly into the end of the axle shaft. RCPH10FWD893AAJ 16. Install the CAS2666 spacer sleeve over the axle and against the bearing cone. RCPH10FWD929AAJ 17. Install the twin ram. Press the inner bearing cone onto the axle shaft while rotating the ram back and forth by hand until there is a noticeably tight preload on the axle bearings.
Page 609 Front axle system - Final drives 18. Temporarily install the thrust ring (1) and new retaining ring (2) on the axle. Be sure the snap ring is against the far side of the groove and fully seated. RCPH10FWD895AAJ 19. Use a thickness gauge to measure and record the distance between the thrust ring and the snap ring in at least two locations.
Page 610 Front axle system - Final drives 21. Install the 380002851 axle shaft remover bridge and a 45.36 t (100000 lb) twin ram onto the trumpet hous- ing. Press on the axle until 13790 – 24132 kPa (2000 – 3500 psi) is shown on the pressure gauge to back seat the bearing against the retaining ring.
Page 611 Front axle system - Final drives 24. Use the CNH299075 lifting hook to carefully align and install the stationary ring gear on the housing so the dowel pin holes will align. NOTE: The lifting hook must be placed mid way between the two dowel pin holes in the ring gear.
Page 612 Front axle system - Final drives 26. On each large planetary gear, there are light scribe lines on the tips of two consecutive gear teeth. The lines vary in length, but are always found on the side farthest from the small gear. The gap between the two teeth must point to the center of the axle.
Page 613 Front axle system - Final drives 29. Install a new nylon thrust insert in the counter-bore on the end of the axle shaft. Retain the insert with clean grease. Install the short axle sun gear into the planetary gears so that every 7th tooth on the sun gear will be in the root between the two marked teeth of each planet gear.
Page 614 Front axle system - Final drives Final drive - Install - 600 Series axles - wheeled Steiger® 580 Steiger® 620 1. Install the short axle sun gear shaft (1) into the left hand or right hand side of the planetary carriers. The longer of the two shafts must be installed in the brake carrier (right hand) side.
Page 615 Front axle system - Final drives 3. Lift and align the final drive housing with the differential housing so the short axle shaft will engage the differen- tial and the assembly marks on the differential housing and final drive housing align and the housing will en- gage the alignment studs.
Page 616 Front axle system - Final drives Powered front axle - Install - High power frame wheeled tractors (25.100) 48193194 12/10/2017 25.3 [25.310] / 104...
Page 617 Front axle system - Final drives Final drive - Remove - 600 Series Quadtrac® axles Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® 1. Position the axle assembly on a clean shop floor with access to an overhead hoist. Disconnect both track tension pressure hoses at the tee fitting in the center housing.
Page 618 Front axle system - Final drives 4. Put blocking under one final drive housing to keep the axle assembly level when the opposite final drive hous- ing is removed. RCPH10FWD135ABJ 5. Connect an overhead hoist to the final drive housing. Take-up the weight of the housing.
Page 619 Front axle system - Final drives 7. Use the hoist to lift and release the final drive housing a small amount several times to weaken the sealant bond. Use a pry bar between the stationary ring gear and differential housing to pry the ring gear out of the dowel pins.
Page 620 Front axle system - Final drives Final drive - Disassemble - 600 Series Quadtrac® axles Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® 1. Remove the stationary ring gear from the axle housing with lifting hook 58-272. RCPH10FWD140ABJ 2. Remove the nylon thrust button from the end of the axle shaft.
Page 621 Front axle system - Final drives 4. Use the CAS2676 planetary carrier lifting hook to re- move the planetary assembly from the housing. NOTICE: Be sure the retaining strap is positioned behind the gear to prevent the lifting fixture from pulling out of the pinion gear shaft.
Page 622 Front axle system - Final drives 7. Use the 380002906 spanner wrench to loosen the lock nut two complete turns. NOTE: The number of complete turns required to remove the nut must be counted and recorded for proper installa- tion. RCPH10FWD146ABJ 8.
Page 623 Front axle system - Final drives 11. Remove the inner face seal from the axle housing. RCPH10FWD150ABJ 12. Use CAS2739 bearing driver and CAS2405 long bear- ing driver handle to remove the inner bearing cup from the housing. RCPH10FWD151ABJ 13. Use CAS2667 plate (1) and a bearing puller (2) to remove the outer bearing cup from the housing.
Page 624 Front axle system - Final drives 14. Remove the outer face seal from the axle shaft. RCPH10FWD153ABJ 15. Use a bearing puller and 30 ton ram to remove the outer bearing cone. RCPH10FWD154ABJ 48193194 12/10/2017 25.3 [25.310] / 112...
Page 625 Front axle system - Final drives Planetary carrier disassembly 16. If the gears are to be reused, mark each gear and the carrier so that the gears and pins are assembled in their original location in the gear carrier. RCPH10FWD155ABJ 17.
Page 626 Front axle system - Final drives 19. Carefully remove the planetary gear assembly with thrust washers from the carrier. RCPH10FWD158ABJ 20. Remove the needle roller bearings and separator ring from within the gear. Repeat steps 16 through 20 for each remaining planet gear. Clean and inspect all final drive gears, bearings and other parts for too much wear or other damage.
Page 627 Front axle system - Final drives 22. Mark the location of the clamp bracket. Remove the bolts securing the offset housing to the center hous- ing. RCPH10FWD161ABJ 23. Install two CAS2496 alignment studs in the locations shown. Separate the offset housing from the center housing dowel pins.
Page 628 Front axle system - Final drives 26. Mark the top side of each gear assembly for reference. Remove the gears from the housing. RCPH10FWD165ABJ 27. Use a split flange type bearing puller and 89 mm (3.5 in) press sleeve to press the bearing cones from each side of the gears requiring bearing or gear replacement.
Page 629 Front axle system - Final drives 30. Repeat step 28 to remove the bearing cups from the cover. Clean and inspect all parts. RCPH10FWD169ABJ 48193194 12/10/2017 25.3 [25.310] / 117...
Page 630 Front axle system - Final drives Final drive - Assemble - 600 Series Quadtrac® axles Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® Planetary carrier assembly 1. Lubricate the needle roller bearings with clean grease or petroleum jelly and load 29 bearings on one side of the gear.
Page 631 Front axle system - Final drives 4. Lubricate the thrust washers with clean grease or pe- troleum jelly. Install one thrust washer on each side of the gear. Adjust the pilot sleeve to engage the thrust washers to hold them in place. RCPH10FWD175ABJ 5.
Page 632 Front axle system - Final drives 8. Install a new spring pin into the gear shaft until the end of the pin is flush or slightly below the edge of the carrier housing. Repeat steps 1 through 8 for each planet gear assembly installation.
Page 633 Front axle system - Final drives 11. Put a light coat of anti-sieze compound around the outside diameter of the outer bearing cup. Use the CAS2501 bearing cup installer (1) and CNH299077 short handle (2) to install the bearing cup into the final drive housing until the cup is seated.
Page 634 Front axle system - Final drives 14. Seat the seal assembly squarely in the bore of the hub as shown. Put a light film of clean CASE IH AKCELA HY-TRAN® ULTRACTION oil on the steel face of the seal. RCPH10FWD180ABJ 15.
Page 635 Front axle system - Final drives 17. Turn the housing on its side to access the inner bear- ing locking nut. RCPH11FWD298BAM 18. Use the 380002906 spanner wrench and torque wrench to tighten the lock nut to a rolling torque of 27 –...
Page 636 Front axle system - Final drives 20. Coat the splines of the axle shaft with anti-sieze com- pound. Use the CAS2676 Planetary Lifting Hook to install the planetary carrier assembly on the axle shaft. RCPH10FWD143ABJ 21. Install the planetary carrier retaining ring in the groove on the end of the axle shaft.
Page 637 Front axle system - Final drives 23. Clean the mating surface of the final drive housing of all residual sealant. Apply a 3 mm (0.12 in) bead of anaerobic sealant around the mounting surface of the axle housing. RCPH10FWD184ABJ 24. Carefully align and install the stationary ring gear on the housing so the dowel pin holes will align.
Page 638 Front axle system - Final drives 27. Use a bearing cup installer to install both bearing cups in the cover. RCPH10FWD187ABJ 28. Use a bearing cup installer to seat the bearing cup in the bore of the housing. RCPH10FWD188ABJ 29. Install the remaining bearing cup in the housing. RCPH10FWD189ABJ 30.
Page 639 Front axle system - Final drives 31. Align and install the gear cover. Torque the bolts to 90 – 100 N·m (66 – 74 lb ft). RCPH10FWD191ABJ 32. Install one of the short differential axle shafts into the gear. RCPH10FWD192ABJ 33.
Page 640 Front axle system - Final drives 35. If rolling torque is not within tolerance, remove the cover, gear and bearing cup from the housing and add or remove selective shims as required. Reassemble and check rolling torque. RCPH10FWD168ABJ 36. After the rolling torque has been adjusted for the 36 tooth gear, remove the cover and gear.
Page 641 Front axle system - Final drives Final drive - Install - 600 Series Quadtrac® axles Steiger® 580 Quadtrac® Steiger® 620 Quadtrac® Offset housing installation 1. Install the short axle stub shafts (1) into the left hand and right hand sides of the differential. The longer of the two shafts must be installed in the brake carrier (right hand) side.
Page 642 Front axle system - Final drives 4. Push the offset housing onto the dowel pins. RCPH10FWD200ABJ 5. Install the offset housing mounting bolts. Tighten the bolts alternately and evenly to 284 – 298 N·m (209 – 220 lb ft). Be sure the clamp bracket (1) is installed in the right location.
Page 643 Front axle system - Final drives 7. Install the sun gear into the housing. RCPH10FWD203ABJ 8. Install two CAS2496 alignment studs into the offset housing horizontally opposite each other. RCPH10FWD204ABJ 9. Lift and align the final drive assembly to the offset hous- ing so the assembly marks align and the housing will engage the alignment studs.
Page 644 Front axle system - Final drives 10. Install the final drive mounting bolts and washers. Tighten the bolts alternately and evenly to 284 – 298 N·m (209 – 220 lb ft). NOTE: Repeat steps 6 through 10 for the opposite side final drive installation.
Page 645 Index Front axle system - 25 Final drives - 310 Final drive - Assemble - 400 Series bar axles (*) ......... . . Final drive - Assemble - 500 Series Quadtrac®...
Page 646 48193194 12/10/2017 25.3 [25.310] / 134...
Page 647 Front axle system - 25 Front axle track yoke assembly - 500 Steiger® 370 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 370 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 420 Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 648 TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® CVT, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Quadtrac® Powershift, scraper, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ CVT, TIER 4B [JEEZ00000FF314001 - ], Steiger® 500 Rowtrac™ Powershift, TIER 4B [JEEZ00000FF314001 - ], Steiger®...
Page 649 48193194 12/10/2017 25.4 [25.500] / 1...
Page 650 Contents Front axle system - 25 Front axle track yoke assembly - 500 TECHNICAL DATA Front axle track yoke assembly Torque - Rowtrac™ axles (*) ..............3 Special tools - Rowtrac™...
Page 651 Front axle system - Front axle track yoke assembly Front axle track yoke assembly - Torque - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Item Metric value U.S. value Yoke to differential extension housing bolts 845 – 950 N·m 623 –...
Page 652 Front axle system - Front axle track yoke assembly 380003328 Alignment Dowels (Set of 2) RAIL12TR02579AA 380003339 Small universal rolling torque tool 380003348 Upbox Input Gear Seal Installer 48193194 12/10/2017 25.4 [25.500] / 4...
Page 653 Front axle system - Front axle track yoke assembly CAS2694 Axle handler adapter 48193194 12/10/2017 25.4 [25.500] / 5...
Page 654 Front axle system - Front axle track yoke assembly Track yoke final drive assembly - Special tools - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 380003349 Upbox final drive bearing compressor 48193194 12/10/2017 25.4 [25.500] / 6...
Page 655 Front axle system - Front axle track yoke assembly Front axle track yoke assembly - Remove - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Prior operation: Track frame - Remove - Rowtrac™ models (48.130) Prior operation: Sprocket - Remove - Rowtrac™...
Page 656 Front axle system - Front axle track yoke assembly 3. In a suitable container, drain the upbox/yoke assembly and reinstall the drain plug. RAIL12TR02714AA 4. Remove the two nuts and the studs. RAIL12TR01592AA 5. Install the two 380003328 alignment dowels. RAIL12TR01618AA 48193194 12/10/2017 25.4 [25.500] / 8...
Page 657 Front axle system - Front axle track yoke assembly 6. Remove the four bolts, as shown, to attach the lifting fixture to the upbox/yoke assembly. RAIL12TR01593AA 7. Use a fork truck to position the 380003324 lifting frame and bolt the lifting frame to the upbox/yoke assembly using the correct length bolts.
Page 658 Front axle system - Front axle track yoke assembly For the 2032 mm (80 in) spacing 9. Remove two top inner mounting bolts securing the upbox assembly to the center section extension as shown. 10. Loosen and remove the two outer upper mounting bolts.
Page 659 Front axle system - Front axle track yoke assembly 12. Use three washers on each of two mounting bolts (1) and install, from the inside, in the bolt holes below the alignment dowels. 13. Install the 380003327 shaft holding fixture (2) and hold in place with two nuts.
Page 660 Front axle system - Front axle track yoke assembly For the 2235 mm (88 in) spacing 15. Remove top nuts securing the upbox assembly to the center section extension as shown. RAIL12TR02710AA 16. Separate the upbox/yoke assembly (1) approximately 38 mm (1.5 in) from the center section extension (2). Use a pry bar (3) to keep the shaft in position in the differential.
Page 661 Front axle system - Front axle track yoke assembly 18. Slide the loose studs to the inside of the differential extension casting and assemble two M24 nuts (1) on to the studs. 19. Install the 380003327 shaft holding fixture (2) and hold in place with two nuts (3).
Page 662 Front axle system - Front axle track yoke assembly 23. Remove the guard (1) for the track tension cylinder and the lubrication inlet tube from the extension hous- ing. 24. Disconnect and remove the lubrication inlet and the tension cylinder tubes (2) from the extension housing. RAIL12TR03334AA 25.
Page 663 Front axle system - Front axle track yoke assembly 26. Remove the lubrication inlet tube. RAIL13TR00357AA 27. In a suitable container, drain the upbox/yoke assembly and reinstall the drain plug. RAIL12TR02714AA 48193194 12/10/2017 25.4 [25.500] / 15...
Page 664 Front axle system - Front axle track yoke assembly 28. Remove the two nuts and the studs. RAIL12TR01592AA 29. Install the two 380003328 alignment dowels. RAIL12TR01618AA 30. Remove the four bolts, as shown, to attach the lifting fixture to the upbox/yoke assembly. RAIL12TR01593AA 48193194 12/10/2017 25.4 [25.500] / 16...
Page 665 Front axle system - Front axle track yoke assembly 31. Use a fork truck to position the 380003324 lifting frame and bolt the lifting frame to the upbox/yoke assembly using the correct length bolts. RAIL12TR01634AA 32. With the upbox/yoke assembly supported with the fork tuck, remove the mounting bolts.
Page 666 Front axle system - Front axle track yoke assembly 33. Separate the upbox/yoke assembly (1) approximately 38 mm (1.5 in) from the center section extension (2). Use a pry bar (3) to keep the shaft in position in the differential. RAIL12TR01597AA 48193194 12/10/2017 25.4 [25.500] / 18...
Page 667 Front axle system - Front axle track yoke assembly 34. Use three washers on each of two mounting bolts (1) and install, from the inside, in the bolt holes below the alignment dowels. 35. Install the 380003327 shaft holding fixture (2) and hold in place with two nuts.
Page 668 Front axle system - Front axle track yoke assembly Front axle track yoke assembly - Disassemble - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 1. Install two M12 x 1.75 bolts (1) in the two threaded holes in the output bearing carrier as shown.
Page 669 Front axle system - Front axle track yoke assembly 6. Install two lifting eyelets and straps as shown. 7. Lift the upbox/yoke assembly, stand upright and re- move the lifting straps and eyelets. RAIL12TR03052AA 8. Install eyelets and lifting straps to the input side of the upbox/yoke assembly.
Page 670 Front axle system - Front axle track yoke assembly 10. Install two M12 x 1.75 bolts (1) in the two threaded holes in the input bearing carrier as shown. 11. Remove the input bearing carrier mounting bolts (2). 12. Tighten the two M12 x 1.75 bolts and remove the bear- ing carrier from the upbox/yoke assembly.
Page 671 Front axle system - Front axle track yoke assembly 15. Using the appropriate size split bearing puller, remove the both bearings from the output gear. RAIL12TR03058AA 16. Using the appropriate size split bearing puller, remove the both bearings from the input gear. RAIL12TR03061AA 48193194 12/10/2017 25.4 [25.500] / 23...
Page 672 Front axle system - Front axle track yoke assembly 17. In a press, press out the bearing cup from the output bearing carrier and remove the shims. RAIL12TR03060AA 18. Remove the oil seal from the input bearing carrier. RAIL12TR03065AA 19. Use a brass punch an remove the input bearing carrier cup and shims.
Page 673 Front axle system - Front axle track yoke assembly Front axle track yoke assembly - Assemble - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 1. Rotate the upbox/yoke assembly and set the inboard side on the floor. 2.
Page 674 Front axle system - Front axle track yoke assembly 5. Press the bearing cup into the output bearing carrier, without any shims. RAIL12TR03071AA 6. Set the bearing carrier in position on the dowel pins. RAIL12TR03072AA 7. Assemble the mounting bolts and torque to 101 – 113 N·m (74 –...
Page 675 Front axle system - Front axle track yoke assembly 9. Setup a height indicator on the housing to the output gear as shown. RAIL12TR03074AA 10. Use a rolling wedge pry bar to pry up the output gear and obtain the shim pack reading. Write it down. 11.
Page 676 Front axle system - Front axle track yoke assembly 15. In a press, remove the bearing cup from the output gear bearing carrier. RAIL12TR03060AA 16. Take the reading measured in step 10 and add 0.13 – 0.22 mm (0.005 – 0.009 in) to preload the output gear. 17.
Page 677 Front axle system - Front axle track yoke assembly 20. Reassemble the cover on to the upbox/yoke assembly with the mounting bolts and torque to 101 – 113 N·m (74 – 83 lb ft). RAIL12TR03073AA 21. Insert the sun shaft (1) into the output gear. 22.
Page 678 Front axle system - Front axle track yoke assembly 25. Attach the lifting straps and rotate the upbox/yoke as- sembly housing. Stand the housing on the yoke arms and a jack stand. RAIL12TR03080AA 26. Use the appropriate size driver and install the inner bearing cup for the input gear.
Page 679 Front axle system - Front axle track yoke assembly 28. With the appropriate size driver, press the inner diam- eter cover into the outboard side of the input gear. RAIL12TR03084AA 29. Press the bearing cup into the input bearing carrier cover, without any shims.
Page 680 Front axle system - Front axle track yoke assembly 31. Set the bearing carrier in position on the dowel pins and assemble the mounting bolts. RAIL12TR03086AA 32. Torque the mounting bolts to 101 – 113 N·m (75 – 83 lb ft). RAIL12TR03087AA 33.
Page 681 Front axle system - Front axle track yoke assembly 35. Use two pry bars to pry up the input gear and obtain the shim pack reading. Write it down. RAIL12TR03089AA 36. Remove the height indicator. 37. Install two M12 x 1.75 bolts (1) in the two threaded holes in the output bearing carrier as shown.
Page 682 Front axle system - Front axle track yoke assembly 41. Take the reading measured in step 35 and add 0.05 – 0.12 mm (0.002 – 0.005 in) to preload the output gear. RAIL12TR03090AA 42. Flip the input gear bearing carrier and assemble the shims on the bearing cup.
Page 683 Front axle system - Front axle track yoke assembly 45. Insert the sun shaft (1) into the output gear. 46. Assemble the special tool 380003339 (2) on the sun gear as shown. 47. Check the rolling torque. The rolling torque must between 2.84 – 7.34 N·m (25.14 –...
Page 684 Front axle system - Front axle track yoke assembly 51. Install the output gear. RAIL12TR03050AA 52. Assemble the output carrier (1) and secure with the mounting bolts (2). 53. Torque the mounting bolts to 101 – 113 N·m (74 – 83 lb ft).
Page 685 Front axle system - Front axle track yoke assembly 58. Use the lifting straps and set the upbox/yoke assembly on the yoke arms. 59. Use the special tool seal driver 380003348 and install the seal into the input cover. RAIL12TR03093AA Next operation: Front axle track yoke assembly - Install - Rowtrac™...
Page 686 Front axle system - Front axle track yoke assembly Front axle track yoke assembly - Install - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ For 3048 mm (120 in) tread width spacing 1. Lightly grease a new O-ring and assemble on to the shaft.
Page 687 Front axle system - Front axle track yoke assembly 4. Move the upbox/yoke assembly close enough to en- gage the spline and have enough space to remove the nuts securing the shaft holding fixture. 5. Remove the nuts and the fixture. Remove the washers from the bolts.
Page 688 Front axle system - Front axle track yoke assembly 9. Put L ® 242® on the inside thread of the two OCTITE studs and install into spacer. 10. Assemble the nuts to the studs and torque to 845 – 950 N·m (623 – 701 lb ft). RAIL12TR01633AA 11.
Page 689 Front axle system - Front axle track yoke assembly 16. Install the lubrication inlet tube. 17. Tighten all the connections. RAIL13TR00357AA 18. Assemble the lubrication return tube (1) to the bracket fittings. 19. Secure the guard (2) with the original bolts. RAIL13TR00359AA 48193194 12/10/2017 25.4 [25.500] / 41...
Page 690 Front axle system - Front axle track yoke assembly 20. Install the lubrication outlet tube. RAIL13TR00358AA For the 2032 mm (80 in) tread width spacing 21. Lightly grease a new O-ring and assemble on to the shaft. RAIL12TR01599AA 48193194 12/10/2017 25.4 [25.500] / 42...
Page 691 Front axle system - Front axle track yoke assembly 22. With the help of an assistant align the spline on the shaft with the gear in the upbox/yoke assembly. Have the assistant slightly rotate the flanged hub, back and forth, to align the input gear spline with the splined end of the shaft.
Page 692 Front axle system - Front axle track yoke assembly 25. Install all the mounting bolts. 26. Using a torque multiplier and torque wrench, torque the bolts to 845 – 950 N·m (623 – 701 lb ft) RAIL12TR03274AA 27. Remove the alignment dowels. RAIL12TR01618AA 28.
Page 693 Front axle system - Front axle track yoke assembly 30. Remove the lifting frame. 31. Install the original bolts and torque to 251 – 280 N·m (185 – 207 lb ft). RAIL12TR01595AA For the 2235 mm (88 in) tread width spacing 32.
Page 694 Front axle system - Front axle track yoke assembly 33. Pick up the upbox/yoke assembly with the fork truck and line up with the spacer. Use the bolts on top of the lifting fixture for rotation adjustment. RAIL12TR01613AA RAIL12TR01612AA 34. With the help of an assistant align the spline on the shaft with the gear in the upbox/yoke assembly.
Page 695 Front axle system - Front axle track yoke assembly 35. Remove the nuts from both ends of the studs securing the shaft holding fixture and remove the fixture. 36. Put L ® 242® on the outside end of the studs OCTITE and assemble into the upbox/yoke assembly.
Page 696 Front axle system - Front axle track yoke assembly 39. Remove the alignment dowels. RAIL12TR01618AA 40. Put L ® 242® on the inside thread of the two OCTITE studs and install through the upbox/yoke assembly. 41. Assemble the nuts to the studs and torque to 845 – 950 N·m (623 –...
Page 697 Front axle system - Front axle track yoke assembly 43. Install the lubrication return tube. RAIL13TR00357AA 48193194 12/10/2017 25.4 [25.500] / 49...
Page 698 Front axle system - Front axle track yoke assembly Track yoke final drive assembly - Remove - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ Prior operation: Front axle track yoke assembly - Remove - Rowtrac™ axles (25.500) 1.
Page 699 Front axle system - Front axle track yoke assembly 4. Remove the ring (1) and the sun (2) gears. RAIL12TR03001AA 48193194 12/10/2017 25.4 [25.500] / 51...
Page 700 Front axle system - Front axle track yoke assembly Track yoke final drive assembly - Disassemble - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 1. Rotate the hub assembly and set down on the work surface with the planetary facing up. RAIL12TR03003AA 2.
Page 701 Front axle system - Front axle track yoke assembly 4. Remove the planetary from the shaft. RAIL12TR03037AA 5. Use special tool 380003349 to compress the bearings to allow the snap ring to be removed. RAIL12TR03018AA 6. Remove the snap ring from the snap ring groove. RAIL12TR03025AA 48193194 12/10/2017 25.4 [25.500] / 53...
Page 702 Front axle system - Front axle track yoke assembly 7. Remove the special tool, the snap ring (1), the thrust ring (2) and the shims (3) from the shaft. RAIL12TR03026AA 8. Attach lifting eyelets and strap to a hoist. RAIL12TR03027AA 9.
Page 703 Front axle system - Front axle track yoke assembly 10. Remove the half of the face seal from the flanged shaft assembly. RAIL12TR03031AA 11. Remove the half of the face seal from the hub assem- bly. RAIL12TR03033AA 48193194 12/10/2017 25.4 [25.500] / 55...
Page 704 Front axle system - Front axle track yoke assembly 12. To remove the inner bearing, cut the bearing cage and remove the tapered roller bearings. Use a split bearing puller under the lip of the cone to remove the cone as shown in the example below. RAIL12TR03007AA RAIL12TR03006AA 13.
Page 705 Front axle system - Front axle track yoke assembly 14. Flip the hub 180°. Use a brass punch and hammer to remove the inner bearing cup. RAIL12TR03012AA 48193194 12/10/2017 25.4 [25.500] / 57...
Page 706 Front axle system - Front axle track yoke assembly Track yoke final drive assembly - Assemble - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 1. Use the appropriate size cylinder and a hydraulic power unit to press the new bearing cone on to the flange shaft.
Page 707 Front axle system - Front axle track yoke assembly 4. Assemble lifting eyelets and straps to the housing and an overhead crane. Set the housing onto the shaft and bearing. Remove the lifting devices. RAIL12TR03013AA 5. Assemble the inner bearing onto the shaft. NOTE: It may be necessary to press the bearing on to the shaft.
Page 708 Front axle system - Front axle track yoke assembly 7. Assemble the snap ring into place on the shaft. RAIL12TR03017AA 8. Use special tool 380003349 to secure the bearing in place. Tighten until there is no end play in the bearings –...
Page 709 Front axle system - Front axle track yoke assembly 10. Remove the special tool, the snap ring and the thrust ring. Obtain the correct shim pack and add 0.076 – 0.152 mm (0.0030 – 0.0060 in) of shims to preload the bearings.
Page 710 Front axle system - Front axle track yoke assembly 13. Assemble the snap ring onto the shaft. RAIL12TR03023AA 14. Use the special tool 380003349 to compress the bear- ings and assemble the snap ring into the snap ring groove. RAIL12TR03025AA 15.
Page 711 Front axle system - Front axle track yoke assembly 16. Check the rolling torque. The rolling torque must be between 9.3 – 21 N·m (82.3 – 185.9 lb in). RAIL12TR03024AA 17. Use the special tool 380003349 to compress the bear- ings and remove the snap ring from the snap ring groove.
Page 712 Front axle system - Front axle track yoke assembly 19. If the rolling torque is not within specifications go back to Step 9 and adjust the shimming until within specifi- cations. If the rolling torque is within specifications proceed to the next step.
Page 713 Front axle system - Front axle track yoke assembly 21. Flood the rubber load ring and metal face seal with denatured alcohol and wipe with a lint free clean cloth. RAIL12TR03028AA RAIL12TR03029AA 22. Assemble the load ring on the face seal as shown. The lip of the load ring is against the back side of the face seal.
Page 714 Front axle system - Front axle track yoke assembly 24. Assemble the seal assembly into the seal cup area. RAIL12TR03031AA 25. Wipe the metal face seal surface with denatured alco- hol and a lint free clean cloth. RAIL12TR03032AA 26. Flood the hub area where the rubber load ring and metal face seal be located and wipe with a lint free clean cloth.
Page 715 Front axle system - Front axle track yoke assembly 27. Wipe the metal face seal surface with denatured alco- hol and a lint free clean cloth. RAIL12TR03034AA 28. Apply a thin coat of oil on the face seal. RAIL13TR00494AA 29. Set hub (1) assembly down onto the output side bear- ing and face seal.
Page 716 Front axle system - Front axle track yoke assembly 30. Assemble the predetermined shims (1), the thrust ring (2) and the snap ring (3) to the shaft. RAIL12TR03026AA 31. Install special tool 380003349 to compress the bear- ings and assemble the snap ring into the snap ring groove.
Page 717 Front axle system - Front axle track yoke assembly 33. Set the planetary assembly in place on the flange shaft. RAIL12TR03037AA 34. Assemble the snap ring into the snap ring groove on the shaft to secure the planetary assembly. RAIL12TR03038AA 35.
Page 718 Front axle system - Front axle track yoke assembly Track yoke final drive assembly - Install - Rowtrac™ axles Steiger® 420 Rowtrac™ Steiger® 470 Rowtrac™ Steiger® 500 Rowtrac™ 1. Clean the mating surfaces of the upbox housing, both sides of the ring gear and the hub housing. 2.
Page 719 Front axle system - Front axle track yoke assembly 5. Put a bead of L ® 515™ on the inside of the hub OCTITE mounting holes as shown. RAIL12TR03044AA 6. Assemble the sun gear in place in the output gear. RAIL12TR03045AA 7.
Page 720 Front axle system - Front axle track yoke assembly 8. Remove the two guide pins, install and tighten the mounting bolts. RAIL12TR03047AA 9. Torque the mounting bolts to 251 – 280 N·m (185 – 207 lb ft). RAIL12TR03048AA 48193194 12/10/2017 25.4 [25.500] / 72...
Page 721 Index Front axle system - 25 Front axle track yoke assembly - 500 Front axle track yoke assembly - Assemble - Rowtrac™ axles (*) ......Front axle track yoke assembly - Disassemble - Rowtrac™...
Page 722 Availability of some models and equipment builds varies according to the country in which the equipment is being used. For exact information about any particular product, please consult your CASE IH dealer. CASE IH is a trademark registered in the United States and many other countries, owned or licensed to CNH Industrial N.V., its subsidiaries or affiliates.

This manual is also suitable for:

Steiger 370 powershift Steiger 420 cvt Steiger 420 powershift Steiger 420 rowtrac cvt Steiger 420 rowtrac powershift Steiger 470 cvt ... Show all

Case IH Steiger 370 CVT Service Manual

Quick Links

Related Manuals for Case IH Steiger 370 CVT

Summary of Contents for Case IH Steiger 370 CVT

This manual is also suitable for:

Table of Contents
