Summary of Contents for ALL-O-MATIC SL-100AC
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY AND INTRODUCTION Safety Instructions ......... . 1-2 UL 325 Cass Types . -
Page 4: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING TO REDUCE THE RISK OF INJURY READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. DO NOT START INSTALLATION UNTIL YOU HAVE READ AND UNDERSTAND THESE DIRECTIONS. IF THERE IS SOMETHING YOU DO NOT UNDERSTAND, PLEASE CALL US. NEVER let children operate or play with gate controls. - Page 5 IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) INSTALL THE GATE OPERATOR ONLY WHEN YOU HAVE READ THE FOLLOWING BEFORE GATE OPERATOR INSTALLATION Confirm that the gate operator being installed is Install a proper electrical ground to the gate Ÿ Ÿ appropriate for the application. operator.
-
Page 6: Ul 325 Cass Types
Each class must have (2) monitored entrapment protection devices in each entrapment zone to sense and react to obstructions within 2 seconds. All-O-Matic’s gate operators conform to the most rigid Class One. UL 325 CLASS TYPES THE SIX TYPES OF OBSTRUCTION... -
Page 7: Operator Specifications
SPECIFICATIONS SW-300 AC SW-350 AC (DISCONTINUED MAY 2022) 1/2 HP: 800 lbs. 800 lbs. Max Gate Weight 1 HP: 1,500 lbs. 20 feet 22 feet Max Gate Length 7 year residential 7 year residential Warranty 5 year commercial 5 year commercial 1/2 HP 1/2 HP &... -
Page 8: Sw-300 Ac Concrete Pad Installation
SW-300 AC CONCRETE PAD INSTALLATION TOP VIEW 4 RED HEAD BOLTS ½”X 3 ½” 13 ” 24” AREA FOR CONDUIT CONCRETE PAD 9” 24” FRONT VIEW 00 uF 2200 uF 2200 uF 2200 u ” 23” INSTALL 4” ABOVE GROUND 4”... -
Page 9: Sw-350 Ac Concrete Pad Installation
SW-350 AC CONCRETE PAD INSTALLATION TOP VIEW 4 RED HEAD BOLTS ½”X 3 ½” 24” 9” AREA FOR CONDUIT CONCRETE PAD ” 30” FRONT VIEW / ” ” INSTALL 4” ABOVE GROUND 4” (WHEN POSSIBLE) 24” FOOTING FOR GATE OPERATOR LOW VOLTAGE CONDUIT HIGH VOLTAGE CONDUIT... -
Page 10: Operator And Arm Dimensions
OPERATOR AND ARM DIMENSIONS Please refer to the chart and drawing below for operator and arm dimensions. A: The distance between the center of the gate bracket and the center of the hinge point. B: The distance between the gate hinge point and the edge of the operator concrete pad. C: The distance from the gate in the open position to the center of the operator shaft. -
Page 11: Operator Placement And Arm Layout
OPERATOR PLACEMENT AND ARM LAYOUT Step 1: With the gate in the desired closed position, mark the ground directly below the center of the gate bracket. Ÿ This will be point . With the gate in the desired open position, mark the ground directly below the center of the gate bracket. Ÿ... - Page 12 OPERATOR PLACEMENT AND ARM LAYOUT Step 3: Measure the distance between point and point . Divide this number in half. Ÿ This number is length of the primary arm section in the next step. Ÿ Please be exact. Ÿ CENTER OF HINGE POINT BRACKET POINT...
-
Page 13: Compact Installation
COMPACT INSTALLATION The gate must be 12’0” long or less to use this installation. The measurements in the installation drawing below will only work if the distance between the gate in the open position and the obstruction (ie: wall, bush, etc) is between 20” and 34”. If you have more than 34”, please refer to the standard installation. -
Page 14: Torque Limiter And Arm Adjustment
TORQUE LIMITER AND ARM ADJUSTMENT The torque limiter on the operator is shipped loose (not adjusted). Use a 20” pipe wrench to adjust the large Ÿ torque limiter nut on the SW-350 operator, as shown in the image below. For the SW-300, equally tighten all (3) adjusting bolts on the torque limiter. -
Page 15: Entrapment Protection Installation
ENTRAPMENT PROTECTION INSTALLATION A minimum of (2) monitored entrapment protection devices are REQUIRED for each entrapment zone. Ÿ An entrapment zone is a location or point of contact where a person can become entrapped between a moving Ÿ gate and a rigid object. The operator is equipped with an inherent entrapment protection system (ERD). -
Page 16: Loop Layout
LOOP LAYOUT Below is a typical loop layout. When connecting to an All-O-Matic circuit board, use the following: — Safety Loop - Normally Closed (N.C) Contacts — Center/Phantom Loop - Normally Open (N.O.) Contacts — Exit Loop - Normally Open (N.O.) Contacts —... -
Page 17: Electrical Connection
ELECTRICAL CONNECTION OPERATORS MUST BE PROPERLY GROUNDED! All gate operators MUST be properly grounded. This minimizes or prevents damage due to electrical charge, Ÿ such as a near lightning strike or an electrical static discharge. Use a single wire for the ground. DO NOT splice two wires for the ground. If the wire breaks or is cut, replace it Ÿ... -
Page 18: Gate Travel Adjustment
GATE TRAVEL ADJUSTMENT After locating the limit switches and identifying which one is open and close, follow the steps below to adjust the gate travel: 1. Turn the power OFF on the gate operator. 2. Use an allen wrench to loosen up the limit cams. Turn the limit cams in the desired direction. 3. -
Page 19: Gate Opening Direction Setting
GATE OPENING DIRECTION SETTING Use OPEN L/R” dipswitch (#8) to change the opening direction of the operator. Ÿ The direction of gate opening is determined from behind the gate operator. Ÿ LEDs will show opening and closing direction when the gate is moving. Ÿ... -
Page 20: Programmable Relay And Leaf Delay
PROGRAMMABLE RELAY AND LEAF DELAY Board model ALL-ACUL includes a programmable relay (N.O.) with four different configurations. See table below for switch settings. Use dipswitch #3 to determine the delay on the open or close and the “Leaf Delay” potentiometer to adjust the delay time from 0 to 6 seconds. (1) 1 second pulse for every open start cycle - Typically used for a cycle counter (2) “ON”... -
Page 21: Timer Adjustment And Radio Setting
TIMER ADJUSTMENT AND RADIO SETTING TIMER ON: Automatic timer to close can be set from 1 to 60 seconds TIMER OFF: Gate operation is “push button to open, push button to close” RADIO ON: To override the timer and allow the radio receiver to close the gate before the timer Turn potentiometer counter clockwise for more time Turn potentiometer clockwise for less time NOTE: If potentiometer is turned all the way counter clockwise, the timer is disabled and the gate WILL NOT... -
Page 22: Dip Switch Functions
DIP SWITCH FUNCTIONS TIMER TIMER TIMER switch “ON” activates the automatic close RADIO timer. RADIO LOCK RADIO switch “ON” allows the radio receiver to override the automatic close timer. 1-PASS SLAVE OSC switch “ON” allows the radio receiver to stop BRAKE and reverse the gate in any direction. -
Page 23: Electronic Reversing Device (Erd) Adjustment
ELECTRONIC REVERSING DEVICE (ERD) ADJUSTMENT All AC boards are equipped with an Electronic Reversing Device (ERD), which will cause the gate to reverse direction when it comes into contact with an obstruction. The amount of force required to reverse the gate’s direction depends on the ERD sensitivity setting and motor rating. -
Page 24: Accessory Connections
ACCESSORY CONNECTIONS The circuit board’s 24 VDC terminal provides up to 700 mAmps to power accessories such as loop detectors, keypads, etc. If the total current draw of your accessories exceeds the 700 mAmps, a separate power supply (transformer) is required. When installing a safety loop detector or pedestrian switch or a stop switch, make sure to REMOVE the black jumper between the 24V-COM and SAFETY and/or STOP_CMD terminals. -
Page 25: Monitored Entrapment Protection Device Connection
MONITORED ENTRAPMENT PROTECTION DEVICE CONNECTION There are 2 types of sensors that can be connected to the gate operator for UL 325 monitored entrapment Ÿ compliance: non-contact sensors (photo eye) and contact sensors (edge sensors). Monitored entrapment protection devices use 4 wires to connect to the board. From the device, connect the RELAY Ÿ... - Page 26 MONITORED ENTRAPMENT PROTECTION DEVICE CONNECTION ENFORCER E-960-D90GQ/ ENFORCER ALLEN BRADLEY E-931-S33RRGQ / E-931-S50RRGQ E-936-S45RRGQ GRU-24 CONTACT BOARD TERMINAL WIRE BOARD TERMINAL WIRE BOARD TERMINAL N.C. MON_CLOSE OR BLACK MON_CLOSE OR BLACK MON_CLOSE OR MON_OPEN MON_OPEN MON_OPEN COMMON WHITE COMMON ORANGE COMMON 12-30 VDC/AC COMMON...
- Page 27 MONITORED ENTRAPMENT PROTECTION DEVICE CONNECTION OVERHEAD VIEW OF DRIVEWAY PHOTOCELL PROTECTING REFLECTOR/TX ACROSS DRIVEWAY GATE IN THE OPEN POSITION = MON_OPEN ENTRAPMENT ZONE ENTRAPMENT ZONE DRIVEWAY = MON_CLOSE PHOTOCELL PROTECTING REFLECTOR/TX REAR OPEN SLIDE WIRING ENTRAPMENT DEVICE TO AC BOARD (WHITE BOARD) WIRING DEVICE ACROSS 12-24 VDC...
-
Page 28: Loop Rack Installation
LOOP RACK INSTALLATION The SW-350 model comes equipped with the pre-wired LPR-2 loop rack for safety, center/phantom and exit plug Ÿ in loop detectors, making installation quick and efficient. Hardwired loop detectors with harnesses can also be installed. The circuit board has 24 VDC and 120 VAC Ÿ... -
Page 29: Three-Button Station Connection
THREE BUTTON STATION CONNECTION A three button station and reset push button are integrated on the board to make limit and ERD adjustments Ÿ easier. An external three button station may also be installed. See diagram below for wiring instructions, Ÿ... -
Page 30: Master/Slave Connection
MASTER/SLAVE CONNECTION BEFORE CONNECTING MASTER/SLAVE COMMUNICATION WIRES, TAKE THE FOLLOWING STEPS: 1: Test and adjust the limit switches and ERDs for each operator as stand alone machines. 2: Once the machines have been adjusted, turn slave dip switch “ON” on the slave board. Press the RESET button on the slave board or reset the power. -
Page 31: Radio Receiver Connection
RADIO RECEIVER CONNECTION There are two types of receivers: 3-wire and 4-wire: 3 wire receivers can mount on the radio receiver terminal strip located outside of the control box. For 4 wire receivers, connect the 2 gray wires to terminals 1 and 2 on the receiver terminal strip located outside of the control box. -
Page 32: Magnetic/Solenoid Lock Connection
MAGNETIC/SOLONOID LOCK CONNECTION A magnetic lock installation requires a step down transformer with appropriate voltage specific to the lock accessory and two wires. When using a magnetic lock, the LOCK dip switch (#4) must be turned ON. The “LOCK OUTPUT” LED will turn on to show the lock is magnetized. -
Page 33: Emergency Release Instructions
EMERGENCY RELEASE INSTRUCTIONS Procedures to manually open the SW-300 AC: 1. Remove the bolt or pad lock from the arm lever and open the lever fully. 2. Opening the arm lever will allow you to manually open and close the gate. REMOVE BOLT OR PAD LOCK MASTER... -
Page 34: Warranty And Customer Record
In order to obtain this policy, please complete the registration card and send it by mail within 30 days of purchasing from ALL-O-MATIC INC. or your installer. If the product is not registered, only a one year warranty on all parts will be provided. -
Page 35: Swinger Arm Assembly
SWINGER ARM ASSEMBLY DETAIL C 8 8 8 DETAIL B RECTANGULAR ARM ITEM NO. PART NUMBER DESCRIPTION QTY. QRA-300RR SW Quick Release Arm SPA-300RR SW Primary Arm SSA-300RR SW Secondary Arm SAB-300RR SW Arm Connecting Bar SGB-300RR SW Arm Gate Bracket 1/2-13 X 3.5 Hex Bolt Hex Pivot Bolt 1/2-13x2.25 Hex Bolt... -
Page 36: Current Draw And Wire Size
OPERATOR CURRENT DRAW AND VOLTAGE DROP CHART CURRENT AC GATE OPERATORS DRAW @ 115VAC SL-100AC(FP) 4.7 AMPS SL-150AC – ½ HP 6.2 AMPS SL-150AC – 1 HP 8.4 AMPS SW-300AC 4.7 AMPS SW-350AC – ½ HP 4.7 AMPS SW-350 AC – 1 HP 8.4 AMPS... -
Page 37: Technical Tips
TECHNICAL TIPS How to tell what mode your board is in. The firmware must match the entrapment protection device wiring or you will get a “MON-FAULT” on the circuit board. - The number of times the “MON-FAULT” light blinks when you press and release “RESET” on the circuit board: - 1 blink = Pre-UL (monitored entrapment device is NOT required) - 2 blinks = UL-2016 (1 monitored entrapment protection device for the close direction is required) - Page 38 NOTES:__________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________...
