- Page 1 TORO 24 PRIME ® Compliant UL325 Compliant SWING GATE OPENER UL991 Compliant Canada CSA C22.2 INSTALLATION MANUAL Compliant Copyright © 2019 All-O-Matic inc. www.allomatic.net...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Ÿ IMPORTANT SAFETY INSTRUCTIONS.............1-2 Ÿ DIFFERENT UL 325 CLASS TYPES..............3 Ÿ PARTS IDENTIFICATION..................4 Ÿ OPEN INSIDE INSTALLATION................5 Ÿ OPEN OUTSIDE INSTALLATION................. 6 Ÿ GATE OPERATOR INSTALLATION..............7 Ÿ MOTOR WIRING....................7 Ÿ EMERGENCY RELEASE..................8 Ÿ... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of injury: READ THE FOLLOWING DIRECTIONS. DO NOT START UNTIL YOU HAVE READ AND UNDERSTAND THESE DIRECTIONS. IF THERE IS SOMETHING YOU DON’T UNDERSTAND CALL US. Never let children operate or play with gate controls. Keep the remote control away from children. - Page 5 INSTALL THE GATE OPERATOR ONLY WHEN YOU HAVE READ THE FOLLOWING: Confirm that the gate operator being installed is appropriate for the application. Confirm that the gate is designed and built according to current published industry standards. Confirm that all appropriate safety features and safety accessory devices are being incorporated, including both primary and secondary entrapment protection devices.
-
Page 6: Different Ul 325 Class Types
DIFFERENT UL 325 CLASS TYPES Class one: Residential A vehicular gate operator intended for use at a home of one to four single family dwellings, garage or parking area. Class two: Commercial or General Public Access A Vehicular gate operator intended for use at a commercial location or building such as a multi-family housing unit (five or more single family units), hotel, garages, retail stores, other buildings servicing the general public. -
Page 7: Parts Identification
PARTS IDENTIFICATION TORO Control Board CONTROL FUNCTION SOL/MAG LOCK AUXILIARY SWITCHES RELAY RELAY 1 OPEN CLOSE ACCESSORY TIMER INPUTS ALL-O-MATIC INC. <ENG. ESP.> MENU NAVIGATION S/N: KEYPAD DATE: 24V AC EXTERNAL LINE IN POWER CONNECTIONS LCD DISPLAY LPR-1 BATTERY 7Ahr... -
Page 8: Open Inside Installation
OPEN INSIDE INSTALLATION ® TORO Positive stops Comply with the measurements shown for proper installation. Adjust the gate structure to optimize for best automation performance, if necessary. Before proceeding with installation, be sure that gate moves freely and the following: 1) Hinges are properly positioned and lubricated. -
Page 9: Open Outside Installation
OPEN OUTSIDE INSTALLATION Comply with the measurements shown for proper installation. Adjust the gate structure to optimize for best automation performance, if necessary. Before proceeding with installation, be sure that gate moves freely and that: 1) Hinges are properly positioned and lubricated. 2) No obstructions are in the path of the swinging gate. -
Page 10: Gate Operator Installation
GATE OPERATOR INSTALLATIONS When a steel post is not available use the back mounting plate to have a welding surface. Mount the back mounting plate to the pillar using anchor bolts. Cut the back mounting bracket to fit the geometry and weld to the back mounting plate or the steel post (if available). NOTE: For OPEN OUTSIDE installation a custom mounting plate(not provided) is required to fit geometry. -
Page 11: Emergency Release
EMERGENCY RELEASE In case of failure, insert the key and turn counter clockwise to unlock, then turn release handle counter clockwise to release. To latch back to normal operation, simply reverse the procedures. Step1. Insert the key and turn Counter Clockwise to unlock Step2. -
Page 12: Ÿlcd Settings And Programming
then press ENTER when desire action is displayed. SETTINGS MENU Set the time for the action. Using the UP/DOWN buttons to Ÿ change the time and RIGHT/LEFT buttons to move from hours, minutes and AM/PM. Press ENTER button to save the action ADVANCED FEATURES time. -
Page 13: Setting Limit Switch Configuration
SETTINGS MENU <ENG: English selection by pressing < left button. ESP.>: Spanish selection by pressing > right button. Setting LIMIT SW CONFIGURATION: 1. SETTINGS: Settings menu selection by pressing enter while From the SETTINGS menu select the LIMIT SW CONF., then press settings is selected. - Page 14 1.9 SET TO DEFAULT 1.9.1 DEFAULT ALL: This selection will set all parameters to factory settings. 1.9.2 DEFAULT SPEED 1.9.3 DEFAULT POWER 1.9.4 DEFAULT 7/D TMR 1.9.5 DEFAULT LEAF DLY 1.9.6 DEFAULT RLY FUNC 1.9.7 DEFAULT SVC C 1.9.8 DEFAULT SW CONF. 2.
-
Page 15: Electrical Connection
ELECTRICAL CONNECTION OPERATORS MUST BE PROPERLY GROUNDED! Power & Battery Switches NOTE: When applying 230V to GRD LINE 1 LINE 2 operator make sure voltage switch is flipped to 230V position. Power connection | 115VAC | 220VAC Single Phase LINE 1 115V HOT 220V LINE 1 LINE 2... -
Page 16: Ÿswing Gate Loop Layout
Exit loop WHEN USED This is a normal loop layout. Remember when connecting to an All-O-Matic circuit board you use the normally closed contacts (N.C.) from the safety loop detector and normally open contacts from the exit and phantom loop detectors. You must twist the loop wires from the exit point of the saw cut of each loop all the way to the loop rack, no exceptions. -
Page 17: General Loop Installation Guidelines
GENERAL LOOP INSTALLATION GUIDELINES The following loop installation guidelines are for installing typical driveway loops for access control applications (i.e. parking gates, sliding gates, swing gates etc...) Always consult with loop detector manufacturers for specific equipment guidelines. This will confirm that the proper configuration and installation techniques are applied for your application. -
Page 18: Entrapment Protection Installation
ENTRAPMENT PROTECTION INSTALLATION FOR SWINGING GATES A minimum of two monitored entrapment protection devices are required for each entrapment zone. All locations or point of contact where a person can become entrapped between a moving gate and a rigid object is considered an entrapment zone. The operator has an inherent entrapment protection (ERD) system. -
Page 19: Entrapment Protection Device Connections
There are two type of entrapment protection devices that can be connected to the operator, NON- CONTACT SENSOR (PHOTO EYE) and CONTACT SENSOR (EDGE SENSORS). These inputs are for monitored ENTRAPMENT PROTECTION devices. MON-12VDC OPEN COMMON CLOSE MON_CLOSE TIMER ALL-O-MATIC INC. MON_OPEN <ENG. ESP.> MON_12/24VDC COMMON MON_CLOSE MON_OPEN STOP CMD... - Page 20 ENTRAPMENT PROTECTION DEVICE CONNECTIONS ENFORCER E-960-D90GQ/ ENFORCER ALLEN BRADLEY E-931-S33RRGQ / E-931-S50RRGQ E-936-S45RRGQ GRU-24 CONTACT BOARD TERMINAL WIRE BOARD TERMINAL WIRE BOARD TERMINAL N.C. MON_CLOSE OR BLACK MON_CLOSE OR BLACK MON_CLOSE OR MON_OPEN MON_OPEN MON_OPEN COMMON WHITE COMMON ORANGE COMMON 12-30 VDC/AC COMMON BLUE...
- Page 21 ENTRAPMENT PROTECTION DEVICE CONNECTIONS OVERHEAD VIEW OF DRIVEWAY PHOTOCELL PROTECTING REFLECTOR/TX ACROSS DRIVEWAY GATE IN THE OPEN POSITION = MON_OPEN ENTRAPMENT ZONE ENTRAPMENT ZONE DRIVEWAY = MON_CLOSE PHOTOCELL PROTECTING REFLECTOR/TX REAR OPEN SLIDE (RED, BLUE AND WIRING ENTRAPMENT DEVICE TO DC BOARD GOLD BOARDS) 12-24 VDC WIRING DEVICE ACROSS...
-
Page 22: Accessory Connections
ACCESSORY CONNECTIONS The circuit board 12 or 24VDC output provides up to mAmps each of power for accessories. More than two or three accessories will require a separate power supply. NOTE: 12 or 24VDC Accessories only. MOTOR 2 MOTOR 1 Remove wire jumper from SAFETY... -
Page 23: Ÿlpr-1 Loop Rack Installation
LPR-2 LOOP RACK INSTALLATION The Toro operator comes equipped with the pre-wired LPR-2 loop rack for safety, phantom, and exit plug in Ÿ loop detectors, making installation quick and efficient. Hardwired loop detectors with harnesses can also be installed. The circuit board has 12 VDC and 24 VDC Ÿ... -
Page 24: Three Button Station System
THREE BUTTON STATION SYSTEM See push button connections below. A three button station was integrated on the board to make adjustments easier when setting limit switches and adjusting ERDs. CMX-309FB C 8.0000 M 535202 MOTOR 2 MOTOR 1 PED-SW Connect the COMMON from all the push buttons Jumper... -
Page 25: Magnetic/Solenoid Lock Connection
MAGNETIC/SOLENOID LOCK CONNECTION Magnetic lock installation requires a step down transformer with appropriate voltage for the specific lock accessory. Operator will provide a 120VAC outlet for the step down transformer. Connections: Plug the lock device transformer to the 120VAC outlet plug. For Magnetic lock: Connect one wire from transformer directly to one wire of the magnetic lock, the other wire from transformer will be connected to the relay plug input and the... -
Page 26: Radio Receiver Connections
RADIO RECEIVER CONNECTIONS 4 wire receiver: connect the two relay wires to common and radio terminals. 4 wire receiver: connect the two relay wires to common and radio terminals. Black (negative) wire to common and red (positive) wire to +12/24V terminal. MOTOR 2 MOTOR 1 Pcb also provides... -
Page 27: Timer Adjustment
SINGLE/DUAL FAIL SF/SC 1-PASS SLAVE RADIO “ ” = Allows AUTO OPEN OPEN IN/OUT the transmitter to close the gate before the timer. OPEN OPEN CLOSE TIMER CLOSE ALL-O-MATIC INC. <ENG. ESP.> TIMER S/N: DATE: 24V AC EXTERNAL LINE IN... -
Page 28: Dip Switch Functions
DIP SWITCH FUNCTIONS TIMER NOTE: Any changes TIMER TIMER switch “ON” activates the to dip switches wile RADIO TIMER. See page 22 for details power is ON requires SINGLE/DUAL you to reset the RADIO FAIL SF/SC processor in order for RADIO switch “ON”... -
Page 29: Solar Panel Connections
24VDC. The on-board charger is limited to 80 watts. For applications that require more than 80 watts an external charger is required. See diagrams below for the different connection options. NOTE: For information on solar panel calculation call ALL-O-MATIC or your local distributor for Assistance. OPEN CLOSE TIMER ALL-O-MATIC INC. -
Page 30: Led Diagnostics
LED DIAGNOSTICS AC/PWR ON: Will be lit when power is present at LINE-IN power input. ALARM: Two states; 1st state: LED will blink (horn will beep also) every 30 seconds when battery is low, bad or disconnected. 2nd state: LED will turn on for 5 minutes when operator goes into shut down mode do to the gate hitting an obstruction (E.R.D.). - Page 31 OPERATOR CURRENT DRAW & VOLTAGE DROP CHARTS CURRENT CURRENT DC GATE OPERATORS DRAW @ DRAW @ 115VAC 220VAC SL-45DC 2 AMPS 1 AMP SL-90DC 5 AMPS 3 AMPS SL-100FP DC 6 AMPS 3.5 AMPS SL-150DC – ½ HP 4 AMPS 2 AMPS SL-150DC –...
- Page 35 OPERATOR PARTS DIAGRAM...
