Easee Charging Robot Installer's Manual page 12

6
Chargeberry
Attaching
WARNING
Insulation testing should be performed before a
Chargeberry is installed in the backplate. Testing the
circuit insulation with the Chargeberry installed in the
backplate may damage the electronics or impact the
reading negatively.
12
1.
2.
3.
2
Turn on the power. The terminals of the backplates
are now electrically live.
Position the Chargeberry to fit into the slots on the
backplate located in the center of the installation.
When the Chargeberry is in the track, press it
forcefully down until you hear a click.
3
"CLICK!"
