  • Page 1 Installer guide Easee Charge Max...

  • Page 2: Warnings And Cautions

    A Warning indicates a condition, hazard or If data transfer to the Easee cloud is not desired, we unsafe practice that can result in serious advise users to stop using Easee chargers immediately.

  • Page 3: Product Overview

    Product overview Front cover Chargeberry Backplate Protects the electronics from Contains the electronics for For attaching and connecting external influences. charging the vehicle. to the charging infrastructure. Installation kit Strain relief Blind plugs1 Sealing plug Strain relief Wall screws Front cover &...

  • Page 4: Technical Specifications

    1 or 3 (fully dynamic) Voltage 3x 230/400V AC (±10%) Mains frequency 50 Hz Easee Charge MID Load balancing of up to 3 units per circuit Built-in energy meter (± 1%) Measuring instruments (MID) Nominal voltage(s) 230V · 3x230V · 3x230V/400V...
  • Page 5 Active Energy Class B (EN 50470-3:2006) Connectivity Built-in eSIM (LTE Cat M1) WiFi 2.4 GHz b/g/n connection Easee Link RF Control charging via Easee App RFID/NFC reader OCPP 1.6 via our API Bluetooth BLE 4.2 Sensors and indicators Light stripe with LEDs showing the status of the charger...
  • Page 6 5 Nm (torque tool required) Cable strip length 12 mm Ingress protection rating (IP) IP2X (without cover), IP34 (Easee Ready cover) Protection against electric shock in compliance with IEC 60364-4-41, 410.3.3: The backplate is constructed with "double or reinforced insulation" (412).

  • Page 7: Planning The Installation

    Site Key: During installation, a Site Key must — be used to assign the Charging Robots to the correct location in the Easee Cloud. A Site Key will automatically be generated when creating a new charging site using the Easee Installer App or it can...
  • Page 8 (Class I). — Any other electrical equipment apart from Easee Charge Max, including lamps and socket outlets, is connected to the circuit. — Any other conditions identified by the authorized installer requiring an external RCD.

  • Page 9: Installation Instructions

    Installation Charging Robot Opening instructions Bend down the lower part of the rubber cover and WARNING insert the two ends of the supplied tool into the two Always work with the power off and in openings at the bottom of the front cover. accordance with local regulations.
  • Page 10 CAUTION the product. If this is not possible to achieve, it is The wires must not cross over the screw terminals possible to use the Easee Mount. or the Chargeberry slots. This will prevent the — Original mounting holes must be used to secure the Chargeberry from seating in the slots.
  • Page 11 Backplate Wiring TN/TT 3-phase IT/TT 3-phase (3x 230/400 V) (3x 230 V) Strip each wire, exposing 12 mm of copper on each. If the cable has flexible conductors, then you must use ferrules on stranded wires to make the connection. Use correct tools to press them.
  • Page 12 NOTE Your phone must support either Bluetooth or NFC. Scan the QR code to download the Easee Installer App and create a free account. Select one of the two site setups in the Installer App: Create new site: If this is a completely new charging site, select "Create new site".
  • Page 13 Turn on the power. The terminals of the backplates Chargeberry Attaching are now electrically live. Remove the PIN code sticker and attach it to the inside of the fuse cabinet, or another safe location for storage. Position the Chargeberry to fit into the slots on the WARNING backplate located in the center of the installation.
  • Page 14 Bend the lower part of the rubber cover down. Front cover Closing Screw in the locking screw at the bottom of the charger to secure the front cover. NOTE! The locking screw is necessary to secure the cover and protect the charger from exposure. Before closing the front cover, it is possible to lock the Close the rubber cover.
  • Page 15 Easee Keys. Type 2 socket: The Type 2 socket is completely universal and allows you to charge any type of electric vehicle using the appropriate charging cable.
  • Page 16 Contact customer support. General error. Unplug the charging cable and replug it to the Charging Red – constant light Robot. If the red light persists, check the Easee App or our knowledge base for further information.
  • Page 17 White – flashing light, only at the bottom status of the master unit. For further information, please check our knowledge base Yellow – flashing light, only at the bottom The Charging Robot is waiting to be configured. Easee public knowledge base can be found at support.easee.com.
  • Page 18 2. Vertical segments and kWh segment, for 1 s 3. Horizontal segments, decimal point and FW segment, for 1 s 4. Scrolling "EASEE", for 4 s 5. Firmware semantic version (major- minor-patch), for 20 s 6. Firmware unique value (16-bit CRC in hexadecimal), for 20 s 7.
  • Page 19 Easee or its subsidiaries in writing. Any permitted use shall always be done in accordance with good practice and ensure that no harm may be caused to Easee or by misleading the consumer. Easee and Easee products, product names, trademarks and slogans, whether registered or not, are Easee’s...
