Unpacking

After you unpack the box you should have all of the items
indicated below. Save the box and packing materials in
case you transport the monitor.
2
1
4
1. Color Monitor
2. AC Power Cord
3. Signal Cable

Tilt/Swivel Base

The monitor comes with a tilt/swivel base. This enables
you to position the monitor at the best angle and tilt for
maximum viewing comfort.

Screen Position Adjustment

Adjust the tilt and rotation of the monitor by placing your
hands at opposite sides of the case. You can adjust the
monitor 90 degrees right or left, 10 degrees up or 5 degrees
down (22" model), or 15 degrees up or 5 degrees down (17"
and 19" models) as shown below.
22" Model
90
90
17" and 19" Models
90
CAUTION
Keep your fingers away from the pivot area of the tilt/swivel
base.
3
5
4. User's Guide
(this document)
5. USB Upstream Cable
(22" model only)
10
10
90
90
5
15
90
5

Quick Operation Chart

To summarize the steps in connecting your computer with
the color monitor and setting the necessary controls and
switches, refer to the chart below.
Connect the color monitor and computer with
the necessary cords and cables.
See
Section 3. INSTALLATION AND CONNECTION
Turn on the color monitor.
Turn on the computer.
Set the controls.
OK
OK
See Section 5. TROUBLESHOOTING
Call for your authorized Compaq
Product Support.
- 5 -
See
Section 4. OSD(On Screen
Display) FUNCTIONS
If a problem appears.
If the problem persists.
