1

INTRODUCTION

Congratulations on your purchase of the high resolution
color monitor. We designed this monitor to provide you
with years of reliable trouble-free operation.
This guide tells you how to connect, adjust and care for your
monitor. This guide also provides technical specifications
and instructions for troubleshooting any basic problems
you may experience with your monitor.

Features

This monitor is an intelligent, microprocessor-based moni-
tor compatible with most analog RGB (Red, Green, Blue)
display standards available in the following sizes:
45 cm/17" (41cm/16" Diagonal Viewable Image)
50 cm/19" (46 cm/18" Diagonal Viewable Image)
55cm/22" (51cm/20" Diagonal Viewable Image)
It provides crisp text and vivid color graphics.
The monitor's wide auto-scanning compatibility range
makes it possible to upgrade video cards or software
without purchasing a new monitor.
Digitally controlled auto-scanning is done using an
internal microprocessor. The microprocessor-based
intelligence allows the monitor to operate in each
frequency mode with the precision of a fixed frequency
monitor. The monitor operates in the following frequen-
cies:
17" Monitor - horizontal scan frequencies between
30kHz and 96kHz, and vertical scan frequencies be-
tween 50Hz and 130Hz
19" Monitor - horizontal scan frequencies between
30kHz and 108kHz, and vertical scan frequencies
between 50Hz and 140Hz
22" Monitor - horizontal scan frequencies between
30kHz and 121kHz, and vertical scan frequencies
between 50Hz and 160Hz.
The monitor contains resident memory for pre-pro-
grammed screen display standards and is also ca-
pable of storing additional user adjustment param-
eters.
The monitor is capable of producing a non-interlaced
maximum addressable resolution format of 1600 dots
x 1200 lines (17" monitor), 1920 x 1440 lines (19"
monitor) and 2048 dots x 1536 lines (22" monitor). This
display is well suited for windowing environments.
Because of the analog signal inputs, the monitor can
display an unlimited palette of colors that can be
manually adjusted to suit your specific needs.
The monitor has a power management function ac-
TM
corded to VESA
-DPMS
the monitor must be connected to a system compliant
TM
with the VESA
-DPMS
computer and/or video card instructions for proper
operation.)
To ensure ease of installation and ongoing use, the
TM
-standard. To save energy,
TM
-standard. (Refer to your
monitor features On Screen Display (OSD) of all moni-
tor set-up and adjustment functions.
For use in a variety of applications, the monitor com-
plies with UL 1950, CSA C22.2 No.950 and EN60950
for safety, FCC Class-B, VCCI Class-B and EN55022
Class-B for EMI, MPR-II, ISO 9241-3, ISO9241-7 and
ISO9241-8 for ergonomics. The monitor also complies
with TCO'99 guideline for environmental safe use.
The world's standard DIAMONDTRON NF CRT up-
graded with improved focus and convergence for super
sharp and pure picture images.
The monitor complies with Video Electronics Stan-
dards Association (VESA
fication. If your computer is Plug & Play compliant
setup will be done automatically.
The monitor provides:
fine 0.25mm aperture grille pitch/Maximum address-
able resolution of 1600 x 1200 (17")
fine 0.24mm (for Northern hemisphere and 0.25/
0.27mm for Southern hemisphere aperture grille pitch/
Maximum addressable resolution of 1920 x 1440 (19")
fine 0.24mm aperture grille pitch/Maximum address-
able resolution of 2048 x 1536 (22")
The monitor has a contrast enhancement function
(FPM: Fine Picture Mode) to accentuate pictures and
graphical image.
- 2 -
TM
TM
) DDC
1/2B(EDID) speci-
