User's Guide
Compaq P710 Color Monitor
Compaq P910 Color Monitor
Compaq P1210 Color Monitor

Advertisement

Table of Contents

   Related Manuals for Compaq P1210

   Summary of Contents for Compaq P1210

  • Page 1 User’s Guide Compaq P710 Color Monitor Compaq P910 Color Monitor Compaq P1210 Color Monitor...
  • Page 2: Table Of Contents

    Microsoft Corporation. All other product names mentioned herein may be trademarks of their respective companies. Compaq shall not be liable for technical or editorial erros or omissions contained herein. The information in this document is subject to change without notice. First Edition August 2000.
  • Page 3: Introduction

    INTRODUCTION Congratulations on your purchase of the high resolution color monitor. We designed this monitor to provide you with years of reliable trouble-free operation. This guide tells you how to connect, adjust and care for your monitor. This guide also provides technical specifications and instructions for troubleshooting any basic problems you may experience with your monitor.
  • Page 4: Internal Preset Memory Capability

    Internal Preset Memory Capability To minimize adjustment needs, the factory has preset popular display standards into the monitor, as shown in Table 1. If any of these display standards are detected by the microprocessor, the picture size and position are automatically adjusted.
  • Page 5: Location Considerations

    Location Considerations When setting up and using the monitor, keep the following in mind: • For optimum viewing, avoid placing the monitor against a bright background or where sunlight or other light sources may reflect on the display area of the monitor. Place the monitor just below eye level.
  • Page 6: Unpacking

    - 5 - Turn on the color monitor. Turn on the computer. Set the controls. Section 4. OSD(On Screen Display) FUNCTIONS If a problem appears. See Section 5. TROUBLESHOOTING If the problem persists. Call for your authorized Compaq Product Support.
  • Page 7: Part Name

    2 PART NAME Control Names (17" & 19" Models) See figures below for the location of the user controls, indicator and connectors. Each part is identified by number and is described individually. FRONT 1. POWER SWITCH: A push-on / push-off switch for AC power.
  • Page 8 Control Names (22" Model) See figures below for the location of the user controls, indicator and connectors. FRONT FRONT 1. POWER SWITCH: A push-on / push-off switch for AC power. 2. POWER-ON INDICATOR: This indicator illuminates green when AC power is on, and illuminates amber when the monitor is in the power management modes.
  • Page 9: Installation And Connection

    INSTALLATION AND CONNECTION 17" and 19" Models On the back of the monitor two kinds of plug-in connections are provided: AC power connector for the AC input, DB9- 15P connector for video signal input. AC Power Connection One end of the AC power cord is connected to the AC power connector on the back of the monitor.
  • Page 10 22" Model USB System Basic Application Upstream Cable Port Scanner Camera N O T E ® The computer is required to have Windows 98 or later installed and USB functions. REAR Power Cord Downstream Ports SIGNAL-B SIGNAL-A Signal Cable Keyboard - 2 - SIGNAL-A SIGNAL-B...
  • Page 11: Installation Of Usb Function

    Installation of USB Function The following procedure permits your computer to recog- nize or "enumerate"(A USB term) the USB HUB. Power on the display monitor and then the computer. Start "Enumeration" from the Windows N O T E • During the enumeration of the USB Hub, connect the keyboard and mouse, to the computer and not to the downstream ports on the display monitor.
  • Page 12: Osd(on Screen Display) Functions

    (On Screen Display) FUNCTIONS How to adjust the screen The monitor has an OSD(On Screen Display) function. The following procedure shows how to adjust the screen using the OSD function. (1) Turn on the monitor. (2) Press button to display the OSD screen.
  • Page 13: Adjustment Items 22" Model

    Adjustment Items 22" Model Items CONTRAST Adjusts the contrast level. BRIGHT Adjusts the black level of the screen COLOR NO Select the desired color from Color 1, Color 2, and Color 3 presets. R-GAIN Adjusts the red-color balances for the selected color. G-GAIN Adjusts the green-color balances for the selected color.
  • Page 14 22" Model Group Item Item Icon Icon CONTRAST BRIGHT COLOR NO R-GAIN G-GAIN B-GAIN COLOR TEMPERATURE COLOR RESET HORIZ-SIZE HORIZ-PHASE VERT-SIZE VERT-POSITION PINCUSHION KEYSTONE TOP-PIN BOTTOM-PIN PIN-BALANCE KEY-BALANCE VERT-LIN-BALANCE VERT-LIN ROTATION ZOOM GEOMETRY RESET Press the Minus Button To decrease the contrast. To increase the contrast.
  • Page 15 22" Model Group Item Item Icon Icon FINE PICTURE MODE HORIZ-CONVERGENCE VERT-CONVERGENCE CORNER PURITY(TL) CORNER PURITY(TR) CORNER PURITY(BL) CORNER PURITY(BR) MOIRE CANCEL MOIRE CANCEL LEVEL CLAMP PULSE POSITION VIDEO LEVEL DEGAUSS POWER-SAVE CONTROL LOCK OSD POSITION ALL RESET GTF AUTO ADJUST DIAGNOSIS LANGUAGE CONTROL LOCK: This is to lock the OSD function to keep the OSD screen image you set.
  • Page 16: Adjustment Items (19" Model)

    Adjustment Items 19" Model Items Function CONTRAST Adjusts the contrast level. BRIGHT Adjusts the black level of the screen COLOR TEMPERATURE Adjusts the color temperature of the image on the screen. HORIZ-SIZE Adjusts the horizontal size of the image on the screen. HORIZ-PHASE Adjusts the horizontal position of the image on the screen.
  • Page 17 19" Model Group Item Item Icon Icon CONTRAST BRIGHT SCREEN COLOR TEMPERATURE HORIZ-SIZE HORIZ-PHASE VERT-SIZE VERT-POSITION PINCUSHION KEYSTONE GEOM- ETRY TOP-PIN BOTTOM-PIN PIN-BALANCE KEY-BALANCE ROTATION GEOMETRY RESET Press the Minus Button To increase the contrast. To decrease the contrast. To decrease the bright- To increase the bright- ness.
  • Page 18 19" Model Group Item Item Icon Icon HORIZ-STATIC VERT-STATIC MOIRE CANCEL LEVEL CORNER PURITY(TL) CORNER PURITY(TR) VIDEO CORNER PURITY(BL) CORNER PURITY(BR) CLAMP PULSE POSITION VIDEO LEVEL DEGAUSS POWER-SAVE CONTROL LOCK MISC. OSD POSITION DIAGNOSIS LANGUAGE Press the Minus Button To adjust the horizontal beam alignment on the full screen area. To adjust the vertical beam alignment on the full screen area.
  • Page 19: Adjustment Items 17" Model

    Adjustment Items 17" Model Items CONTRAST Adjusts the contrast level. BRIGHT Adjusts the black level of the screen. COLOR TEMPERATURE Adjusts the color temperature of the image on the screen. HORIZ-SIZE Adjusts the horizontal size of the image on the screen. HORIZ-PHASE Adjusts the horizontal position of the image on the screen.
  • Page 20 17" Model Group Item Item Icon Icon CONTRAST BRIGHT SCREEN COLOR TEMPERATURE HORIZ-SIZE HORIZ-PHASE VERT-SIZE VERT-POSITION PINCUSHION KEYSTONE GEOMETRY TOP-PIN BOTTOM-PIN PIN-BALANCE KEY-BALANCE ROTATION GEOMETRY RESET MOIRE CANCEL LEVEL CLAMP PULSE POSITION VIDEO VIDEO LEVEL DEGAUSS POWER-SAVE CONTROL LOCK MISC. DIAGNOSIS LANGUAGE Press the Minus Button...
  • Page 21: Troubleshooting

    Display is dark or your graphics adapter output. (0.7v or 1.0Vp-p). too bright Before calling your 1-800-OK-COMPAQ for service, please check that the items below are properly connected or set. In case of using a non-standard signal, please check the pin assignments and the signal timing of your computer with the specification outlined in Section 6.
  • Page 22 PROBLEM • Thin vertical black lines on one or both sides of the screen. This minor condition is caused by grille element overlap which can occur during shipping. Position an open white window over the affected area of the screen and maximize the brightness and contrast Black vertical controls.
  • Page 23: Specifications

    6 SPECIFICATIONS 22" Model Size Mask type Deflection angle Phosphors Aperture grille pitch Phosphor pitch Face Plate Focusing method Video INPUT SIGNAL Sync Input Connectors SIGNAL INTERFACE Input Impedance SCANNING Horizontal FREQUENCY Vertical RESOLUTION (HxV) 2048 dots x 1536 lines Non-Interlaced maximum addressable resolution format at 75Hz WARM-UP TIME 30 minutes to reach optimum performance level BRIGHTNESS...
  • Page 24: 19" Model

    19" Model Size Mask type Deflection angle Phosphors Aperture grille pitch Face Plate Focusing method Video INPUT SIGNAL Sync Input Connector SIGNAL INTERFACE Input Impedance SCANNING Horizontal FREQUENCY Vertical 1920dots x 1440lines Non-Interlaced maximum addressable resolution format at 60Hz RESOLUTION (HxV) Recommended Resolution: 1280 dots x 1024 lines at 85Hz WARM-UP TIME 30 minutes to reach optimum performance level...
  • Page 25: 17" Model

    17" Model Size Mask type Deflection angle Phosphors Aperture grille pitch Face Plate Focusing method Video INPUT SIGNAL Sync Input Connector SIGNAL INTERFACE Input Impedance SCANNING Horizontal FREQUENCY Vertical RESOLUTION (HxV) 1600dots x 1200lines Non-Interlaced maximum addressable resolution format at 75Hz Recommended Resolution: 1024 dots x 768 lines at 85Hz WARM-UP TIME 30 minutes to reach optimum performance level...
  • Page 26: Appendix

    APPENDIX Monitor Signal Input Connector (DB9-15P) (Female) DB9-15P MOUNTED ON THE REAR PANEL PIN ASSIGNMENTS Pin No. Signal RED VIDEO GREEN VIDEO or COMPOSITE SYNC with GREEN VIDEO BLUE VIDEO GROUND DDC GROUND RED GROUND GREEN GROUND BLUE GROUND SYNC GROUND GROUND HORIZONTAL SYNC or COMPOSITE SYNC...
  • Page 27: Regulatory Compliance

    Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user’s authority to operate the equipment. Cables...
  • Page 28: Japanese Notice

    Energy Star Monitors that are marked with the Energy Star Logo meet the requirements of the EPA Energy Star program. As an Energy Star Partner, Compaq Computer Corporation has determined that this product meets the Energy Star guidelines for energy efficiency. Specific details on using the Energy Saving features can be found in the energy saver or power management section of the computer manual.
  • Page 29 216028-001...
