Adjustment Items
17" Model
Items
CONTRAST
BRIGHT
COLOR TEMPERATURE
HORIZ-SIZE
HORIZ-PHASE
VERT-SIZE
VERT-POSITION
PINCUSHION
KEYSTONE
TOP-PIN
BOTTOM-PIN
PIN-BALANCE
KEY-BALANCE
ROTATION
GEOMETRY RESET
*MOIRE CANCEL LEVEL Adjusts the moire level on the screen.
CLAMP PULSE POSITION
VIDEO LEVEL
DEGAUSS
POWER-SAVE
CONTROL LOCK
DIAGNOSIS
LANGUAGE
A. Press "GEOMETRY RESET" to restore to the factory preset level.
B. Press
and
buttons together, to restore to the factory preset level.
C. Set data does not change by the change of the signal timing.
*Moire is a series of wavy patterns caused by the interference between the aperture grille
of the CRT and the raster generated by the video card. Adjust the level to the minimum
value at which moire is no longer observed.
Adjusts the contrast level.
Adjusts the black level of the screen.
Adjusts the color temperature of the image on the screen.
Adjusts the horizontal size of the image on the screen.
Adjusts the horizontal position of the image on the screen.
Adjusts the vertical size of the image on the screen.
Adjusts the vertical position of the image on the screen.
Straightens the left and right sides of the image on the screen.
Adjusts the parallelism of the left and right sides of the image on the screen.
Adjusts the pincushioning at the top corners of the screen.
Adjusts the pincushioning at the bottom corners of the screen.
Adjusts the curvature of the left and right sides of the screen image.
Adjusts the vertical slant or tilt of the screen image.
Adjusts the rotation of the image.
Restore to the factory preset level. (Only function on factory preset timing)
Use this function to eliminate excessive green or white background that
may occur when external sync signals are applied to the monitor.
Selects video level 1.0V or 0.7V. (0.7V Standard)
Eliminates possible color shading or impurity.
When setting to ON, the power consumption of the monitor will be reduced
when not in use.
Locks the OSD function to keep the screen you desired.
Indicates the current scanning frequency and factory or user preset
timing number.
Selects the language used on OSD screen.
Function
- 8 -
X: Available
A
B
C
X X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
-
-
-
X
-
-
-
X
X
-
-
-
X
