- Page 1 7404702 ZERO-TURN MOWER ASSEMBLY GUIDE RZ48 www.greenworkstools.com...
-
Page 2: Table Of Contents
SYMBOLS Rules for Safe Assembly...........................2 Symbols..............................3 Tools Needed.............................3 Unpacking........................4 Loose Parts List............................5 Assembly..............................6-7 Final Preparation............................8 RULES FOR SAFE ASSEMBLY product changes at any time, without notice WARNING and without incurring any obligation to make Strictly adhere to all torque wrench tightening the same or similar changes to any products specifications. -
Page 3: Symbols
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will DANGER result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could WARNING result in death or serious injury. -
Page 4: Unpacking
UNPACKING WARNING WARNING If any parts on the Loose Parts List are already Use care when driving the mower off of the assembled to your product when you unpack frame and press the brake pedal as needed it, verify the part is assembled correctly, is to control the speed. -
Page 5: Loose Parts List
LOOSE PARTS LIST WARNING No. Description Qty. Seat assembly with seat switch If any parts are damaged or missing do not assemble this product until the parts are Charger replaced with new original manufacturer’s parts Steer control lever or their equivalent. Assembly of this product with damaged, missing, or incorrect parts could result in serious personal injury. -
Page 6: Assembly
ASSEMBLY WARNING Strictly adhere to all torque wrench tightening specifications. Failure to do so could cause serious personal injury. WARNING Do not attempt to modify this product or create accessories not recommended for use with this product. Any such alteration or modification is misuse and could result in a hazardous condition leading to possible serious personal injury. - Page 7 ASSEMBLY INSTALL THE SEAT 1. Place the seat assembly over the seat plate, insert the seat studs through the holes. 2. Install the washer and nut on all four studs and tighten securely. 3. Connect the seat switch to the machine. 4.
-
Page 8: Final Preparation
FINAL PREPARATION CHECK TIRE PRESSURE TEST THE SAFETY INTERLOCK SYSTEM Check the air pressure in all tires before use. This mower features a Safety Interlock System Improper air pressure will affect handling, to protect the operator by shutting off the blades steering response, traction, tire life, level cutting, if the operator leaves the seat with the blades and operator comfort.
