DSPM Defender Micro Elite Maintenance Manual page 31

6. OPERATION AND PROCEDURE
The initial startup must be done in conjunction with DSPM or by a factory authorized technician.
PLEASE CALL FOR STARTUP BEFORE APPLYING POWER TO THE UPS!
6.1. START-UP PROCEDURE
6.1.1. After making all power and grounding connections to the Emergency Lighting Inverter System; ver
ify that the system is OFF (Non of the LEDs are lit).
Note: The Red LED indicates an alarm, a Yellow LED indicates inverter is running on
batteries power, and a solid Green LED indicates inverter is running on utility power.
6.1.2. Energize the building feeder circuit for the input power for the UPS.
6.1.3. Verify the output voltage is correct BEFORE POWERING the inverter.
6.1.4. Power up all electrical equipment connected to the UPS, as specified by the equipment manufacturers.
6.1.5. Press and hold the Off/On push button until you hear a beep and release the button. Verify that each of the
following items takes place:
6.1.5.1. The fan come on.
6.1.5.2. The Processor perform a series of checks (These checks will be indicated by a delay in the red LED extin-
guishing and the green LED illuminating (see Figure 4).
6.1.6. The unit is on the inverter.
Note: With the Batteries properly connected about 20 Second after unit is up and
6.2. SHUT-DOWN PROCEDURE
6.2.1. Power down all electrical equipment connected to the UPS.
6.2.2. Press and hold the "Off/On switch" until the inverter beeps.
6.2.3. Set all BREAKERS to the OFF position.
Title: Micro Elite Maintenance's Manual
Title: Micro
05 31
Doc No.: #074-1005-02
Doc No.: 018-1000-02
Description: Emergency Lighting Inverter User's Manual
Description: Emergency Lighting Inverter User's Manual
running, the batteries will automatically be placed online to the UPS.
