3.
USE TOOLS WITH INSULATED HANDLES (FOR A METHOD OF INSULATING YOUR EXISTING TOOLS,REFER
TO FIGURE 4 a-f).
4.
WEAR RUBBER GLOVES AND BOOTS.
5.
DO NOT LAY TOOLS OR METAL PARTS ON TOP OF BATTERIES.
6.
DISCONNECT CHARGING SOURCE PRIOR TO CONNECTING OR DISCONNECTING BATTERY TERMINALS.
7.
DETERMINE IF BATTERY IS INADVERTENTLY GROUNDED. IF SO, REMOVE THE SOURCE OF THE GROUND.
CONTACT WITH ANY PART OF A GROUNDED BATTERY CAN RESULT IN ELECTRICAL SHOCK. THE LIKELI-
HOOD OF SUCH SHOCK WILL BE REDUCED IF SUCH GROUNDS ARE REMOVED DURING INSTALLATION AND
MAINTENANCE.
8.
LEAD-ACID BATTERIES CAN PRESENT A RISK OF FIRE BECAUSE THEY GENERATE HYDROGEN GAS. THE
FOLLOWING PROCEDURES SHOULD BE FOLLOWED:
DO NOT SMOKE WHEN NEAR BATTERIES.
DO NOT CAUSE FLAME OR SPARK IN BATTERY AREA.
9.
DISCHARGE STATIC ELECTRICITY FROM YOUR BODY BEFORE TOUCHING BATTERIES BY FIRST TOUCHING
A GROUNDED SURFACE.
WARNING!
MAKE SURE THE PROPER POLARITY IS OBSERVED. DC BUS VOLTAGE FOR A TWO (2) BATTERY STRING
SHOULD BE BETWEEN 24 AND 27.2 VDC AS TESTED AT THE TOP OF TB2 (REFER TO FIGURE 5—SYSTEM COM-
PONENT LAYOUT).
WARNING!
AFTER SERVICING THE BATTERIES, ENSURE THAT EACH STRING (EACH STRING IS 2 BATTERIES TOTAL) CON-
SIST OF THE NUMBER OF BATTERIES INDICATED BY THE BATTERY LAYOUT AND THE MEASURED VOLTAGE
FROM THE FIRST TO THE LAST BATTERY IS WITHIN THE VOLTAGE RANGE STATED ABOVE.
4.4.6. CHARGING OF THE BATTERIES
The Emergency Lighting Inverter System charges its battery whenever it is connected to utility power and is
turned on. Disconnect charging source prior to connecting or disconnecting battery terminals. For the best
results, charge the battery for 24 hours after they are hooked up and the ELI is brought on line.
Title: Micro Elite Maintenance's Manual
Title: Micro
28
Doc No.: #074-1005-02
Doc No.: 018-1000-02
Description: Emergency Lighting Inverter User's Manual
Description: Emergency Lighting Inverter User's Manual
Rev: NR
Date: 02/26/2022
Rev: NR
Date: 07/26/2016
Phone :
1.877.DSPM.POWER
Phone :
1.877.DSPM.POWER-1.877.377.6769
Fax:
909.930.3335
Fax:
1.877.DSPM.POWER-1.877.377.6769
Website:
www.dspmanufacturing.com
Website:
www.dspmanufacturing.com
E-Mail:
techsupport@dspmanufacturing.com
E-Mail:
techsupport@dspmanufac-
-
1.877.377.6769
