2.11. SPECIAL APPLICATIONS
2.11.1. DSPM offers numerous UL924 optional devices to meet unusual or difficult application parameters normal sw-
itching and/or dimming devices in NON-emergency conditions.
2.11.2. ECM - Environmental Circuit Module allows fixtures and lamps on the emergency circuit (s) to be operated by
normal switching and/or dimming devices in NON-emergency conditions.
2.11.3. Dimming Panel Interface allows use with emergency lights controlled by common dimmer panel.
2.12. WARRANTY
2.12.1. One-Year full warranty on system electronics
2.12.2. Battery warranty 1-year with 9-years pro-rated
2.12.3. System 1-year on-site warranty labor with DSPM phone assisted start-up
2.12.4. Five-Year powertrain warranty
2.12.5. Maintenance contracts available
3. FIELD REPLACEABLE UNITS (FRUS)
Each FRUS comes with detail instructions of how the part should be performed. At the ends of most wires/cables are
labels that indicates their locations. When ordering replacement parts from the factory, supply the information from the
System Label (refer to Technical Assistance section in this manual). Include the model number, serial number, input/
output voltages, and power rating when ordering parts. Replacement parts must be replaced by qualified factory trained
service personnel only.
Circuit boards and IGBTs contain ESDS (Electro-Static Discharge Sus-
ceptible) components. Handle and package ESDS devices in accor-
dance with JEDEC standard JESD625-A. Use a grounded ESD wrist
strap when handling the devices and circuit boards. Always package
components and circuit boards in static-dissipative plastic bags or the
static-dissipative material that the FRUS came in before transporting
(Even if a device has failed). Failure to do so could result in further dam-
3.1. MOTHER/MAIN BOARDS
The Mother/Main Boards are located on the three middle shelves and mounted with 10 screws. Verify that all connectors
are matches with their designations and pins #1, 2, etc (Note: all plugs and connections are not used!) Unplug jumper on
daughter board and all connectors from on Mother Board. Install the new board. Reconnect all plugs and connections
returning them to their original orientations.
3.2. All Other Parts
Verify that the cables are marked before disconnecting. Replace the defective part with the new part. Reconnect wiring
the same way as it was disconnected.
Title: Micro Elite Maintenance's Manual
Title: Micro
05 17
Doc No.: #074-1005-02
Doc No.: 018-1000-02
Description: Emergency Lighting Inverter User's Manual
Description: Emergency Lighting Inverter User's Manual
age, complicating repair and failure analysis.
