DIGITAL-LOGIC AG
10.3. The COM2 Serial Interface Cable
DT terminal for dual row 0.1" (2.54mm grid) and 1.27mm flat cable.
Connector X39
Pin
Signal
Pin 1
= DCD
Pin 2
= DSR
Pin 3
= RXD
Pin 4
= RTS
Pin 5
= TXD
Pin 6
= CTS
Pin 7
= DTR
Pin 8
= RI
Pin 9
= GND
Pin 10
Attention!
• Do not short circuit these signal lines.
• Never connect any pins on the same plug or to any other plug on the MICROSPACE
MSB900/L. The +/-10 Volts will immediately destroy the MICROSPACE core logic. In this
case the warranty is void!
• Do not overload the output; the maximum output of the current converters is 10mA.
COM2 9pin D-Sub male
1
6
2
7
3
8
4
9
5
57
MSB900/L Detailed Technical Manual V1.0
