7. V I
IDEO NPUT
The MSB900 contains a low-cost video input port. It consist of LX900's video input port (VIP) and the exter-
nal frame grabber chip SAA7111A. This port is capable of digitizing a CVBS video signal with 15 frames per
second at a resolution of 352x288bits. Note that this frame rate is only achievable when the raw data stream
is compressed before being stored on the hard drive. Driver support is currently available for the Windows
XP platform.
8. D
ESCRIPTION OF THE CONNECTORS
Flat cable
44pin IDE is: IDT Terminal for Dual Row (2.00mm grid) and 1.00mm flat cable
•
All others are: IDT Terminal for Dual Row 0.1" (2.54mm grid) and 1.27mm flat cable
•
NC: not connected
•
Connector
X1 Power
X14

Video Input

X15 Operator panel connector / Flat panel
X20 Sound MIC stereo input
X22 Sound speaker stereo output
X31 Keyboard PS/2 and Mouse Utility connector
X33 LAN Port A
X34 LAN Port B
X39 COM2 serial interface connector
X50 USB 0/1 connector
X51 USB 2/3 connector
X52 Socket for USB UDOC
X60 IDE PATA connector
X61 COM1 and LPT connector
X71 CompactFlash Socket
X101 PCI/104 expansion connector
X110 POD-Port interface connector
X120 MiniPCI socket
X230 JTAG-Port
X301 DSUB VGA connector
Structure
41
MSB900/L Detailed Technical Manual V1.0
Pin
2pin jack plug
SMA
44pin RM 2.0 Not assembled
3.5mm jack plug
3.5mm jack plug
PS/2
RJ45
RJ45
10pin RM 2.54mm
Dual-USB
Dual-USB
10pin RM2.54mm Not assembled
44pin RM 2.0
32pin RM 2.54mm
50pin
120pin
14pin
124pin
4 pin
15pin DSUB
Remarks
High-density
