10.2. The COM1/LPT Serial Interface Cable

Terminal for dual row 2mm grid and 1mm flat cable.
Connector X61
Pin Signal
Pin 1 = DCD
Pin 2 = DSR
Pin 3 = RXD
Pin 4 = RTS
Pin 5 = TXD
Pin 6 = CTS
Pin 7 = DTR
Pin 8 = RI
Pin 9 = GND
Pin 10
Pin Signal
Pin 11 = SELECT
Pin 12 = Paper end
Pin 13 = Busy
Pin 14 = Acknowledge
Pin 15 = Data 7
Pin 16 = Data 6
Pin 17 = Data 5
Pin 18 = Data 4
Pin 19 = Data 3
Pin 20 = Shift in
Pin 21 = Data 2
Pin 22 = Init
Pin 23 = Data 1
Pin 24 = Error
Pin 25 = Data 0
Pin 26 = Autofeed
Pin 27 = Strobe
Pin 28 = GND
Attention!
• Do not short circuit these signal lines.
• Never connect any pins on the same plug or to any other plug on the MICROSPACE
MSB900/L. The +/-10 Volts will immediately destroy the MICROSPACE core logic. In this
case the warranty is void!
• Do not overload the output; the maximum output of the current converters is 10mA.
COM1 9pin D-Sub male
1
6
2
7
3
8
4
9
5
LPT1 25pin D-Sub female
13
12
11
10
9
8
7
6
5
17
4
16
3
15
2
14
1
18-25
56
