2.4. MSB900/MSB900L specifications

CPU
CPU
CPU Core Supply
Mode
Compatibility
Word Size
Secondary Cache
Physical Addressing
Virtual Addressing
Clock Rates
Socket Standard
Chipset
Northbridge
Southbridge
LAN
Audio
Codec
Firewire IEEE1394
Video
Power Management:
DMA:
8237A comp.
Interrupts:
8259 comp.
Timers:
8254 comp.
Memory:
SODIMM
Video
Controller
BUS
Enhanced BIOS
Memory
CRT-Monitor
Video Input
Drivers
Specification
GEODE LX900
1.25V very low powered
Real / Protected
x86
32Bits
128kB
32 lines
16GB
600MHz
Soldered BGA
Specification
AMD LX900
AMD CS5536
2x 10/100Mbit Intel 82551QM (LAN A), Intel 82551ER (LAN B)
Stereo In and Stereo Line-Out
AD1985 up to 96kHz sampling rate, 16Bit (Analog Devices)
Not on board
16MByte Video-DDRAM
Specification
The LX900 supports ACPI and APM Version 1.2
The following ACPI Sleep States are supported:
- S1 (Standby)
- S3 (Suspend to RAM) not available
- S4 (Hibernation)
Specification
4 channel 8bit
3 channel 16bit
Specification
8 + 7 levels
PC compatible
Specification
3 programmable counters/timers
Specification
SODIMM200pin DDR PC2700 333MHz 256-1024MByte
Specification
GEODE LX900
32Bit high speed 33MHz PCI bus
VGA / LCD BIOS
2-16MByte shared RAM
VGA, SVGA up to 1920x1440
MSB900: yes, 1 channel
MSB900L: no
WIN2000, XP
14
