X61 Serial Port COM1, Parallel Port LPT1
Header onboard D-SUB connector
Pin 1 Pin 1
Pin 2 Pin 6
Pin 3 Pin 2
Pin 4 Pin 7
Pin 5 Pin 3
Pin 6 Pin 8
Pin 7 Pin 4
Pin 8 Pin 9
Pin 9 Pin 5
Pin 10
Pin 11
Pin 12 Pin 12
Pin 13 Pin 11
Pin 14 Pin 10
Pin 15 Pin 9
Pin 16 Pin 8
Pin 17 Pin 7
Pin 18 Pin 6
Pin 19 Pin 5
Pin 20 Pin 17
Pin 21 Pin 4
Pin 22 Pin 16
Pin 23 Pin 3
Pin 24 Pin 15
Pin 25 Pin 2
Pin 26 Pin 14
Pin 27 Pin 1
Pin 28 Pin 23-25
Pin 29
Pin 30
Pin 29
Pin 30
MSB900/L Detailed Technical Manual V1.0
Signal
DCD
DSR
RxD
RTS
TxD
CTS
DTR
RI
GND
GND
select
paper end
busy
acknowledge
data 7
data 6
data 5
data 4
data 3
shift in
data 2
init printer
data 1
error
data 0
auto feed
strobe
GND
power supply GND
power supply 8-30V
power supply GND
power supply 8-30V
