Mass Storage
FD
HD
Standard AT Interfaces:
Serial
SuperIO Chip
Parallel
Keyboard
Mouse
Speaker
RTC
Backup current
RTC-backup MSB900
RTC-backup MSB900L
BUS
PCI/104
Clock
USB
USB
Transfer rate
Channels
Peripheral Extension
ISA
PCI MSB900
PCI MSB900L
Power Supply
Working
Power Rise Time
Power consumption
Standby power consumption
Physical Characteristics
Dimensions
Weight
PCB Thickness
PCB Layer
Specification
Floppy disk interface not supported
E-IDE interface, AT-type, for max. 2 hard disks, 44pin connector,
for 1.3, 1.8 and 2.5" hard disk with 44 pins IDE
Specification
Name FIFO IRQs
COM1 yes IRQ4
COM2 yes IRQ3
COM1/2 available on headers onboard.
For DSub-connectors, option MSB800-CON is needed.
W83627HF from WINBOND
LPT1 printer interface mode: SPP (output), EPP (bidir.)
AT or PS/2-keyboard
PS/2
No speaker
Integrated into the chipset, RTC with CMOS-RAM 256Byte
<5 µA
Onboard 3.6Volt Lithium 400mAh available
External connection, no onboard battery available
Specification
PCI 32Bit Bus, 1 slot
33MHz defined by the GEODE
Specification
2.0
480MBps, 12.5MBps / 1.5MBps
4
Specification
Not supported
With PCI/104 BUS (1 slot), limited I/O space
Not available
Specification
8-32Volt ± 5% (peak 36Volt)
Unspecified
MSB900/L with HD, MS/KB (PS/2), CRT Monitor
Windows XP Desktop: type 8.5-10W
MSB900/L:
Windows Standby: 2.5W (without MS/KB wakeup function)
Windows Standby: 4.5W (with PS/2 wakeup function)
Specification
Length: 146 mm
Depth: 102 mm
Height: 20 mm
160g
1.6mm / 0.0625 inches nominal
Multilayer
15
MSB900/L Detailed Technical Manual V1.0
Addr. Standard
3F8 RS232C
2F8 RS232C
Option
