Hayman Reese R2651 Installation Instructions

Towbar for jayco iveco motorhome

Advertisement

HAYMAN REESE
PART No:
R2651
JAYCO IVECO MOTORHOME
PLEASE ENSURE THAT INSTRUCTIONS UNDERSTOOD PRIOR TO FITMENT
Installation Time: Approx
XX
Mins
Towbar Installation Instructions
Towbar capacity
JAYCO IVECO MOTORHOME
Part Number
R2651
Max Towing Braked 3000kg
Max Static Ball Load 300kg
Hayman Reese (Cequent)
PO Box 4050, Dandenong South VIC 3164
Phone 1800 812 017 Email info@haymanreese.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R2651 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hayman Reese R2651

  • Page 1 Installation Time: Approx Mins Towbar Installation Instructions Towbar capacity JAYCO IVECO MOTORHOME Part Number R2651 Max Towing Braked 3000kg Max Static Ball Load 300kg Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au...
  • Page 2 The high tensile fasteners supplied with this product were used to achieve the specified rating. If replacement is required ensure that fasteners of the same rating & quality are used. Contact an authorised Hayman Reese dealer if further information is required.
  • Page 3 DESCRIPTION ITEM NO. QTY. 1 IVECO WELD ASSY. 1 CLASS 4 TBM 21232 2 HAYMAN REESE LOGO STICKER 1 Hitch Box Collar Cover 1 CP LABEL 12 M12 X 28 X 3 Z/P FT WASHER 6 BOLT M12-1.75x40 GR8.8 4 M16 X 33.5-34.5X2.5-3.0Z/P Flat Washer 2 BOLT M16-2.00 X 40 Z/P 8.8...
  • Page 4 HAYMAN REESE PART No: R2651 JAYCO IVECO MOTORHOME INSTALLATION INSTRUCTIONS PLEASE ENSURE THAT INSTRUCTIONS UNDERSTOOD PRIOR TO FITMENT Lower spare wheel for ease of fitment. Insert towbar between chassis rails. Fit M12x40 bolts, spring washers, flat washers and M12 nuts ( 4 on bottom of chassis, 2 on...
