External power operating. When using the external
power supply the battery level indicator is replaced
by the external power icon.
If the Smart Interrupter connection
cables become damaged, they should
be returned to an Authorised Service
Center for replacement.
Cleaning
Wipe down with a moist cloth.
Maintenance
There are no user serviceable
parts within the equipment.

Specifications

This equipment is intended to be connected to a secondary source
isolated from CATII 300Vrms mains by reinforced insulation
CP Current Output:
Frequency (of CP
system being switched): DC to 60Hz
Connection Outputs:
Switching Patterns:
Synchronisation:
Batteries:
CP Power:
Environmental:
Temperature:
Humidity:
Altitude:
Dimensions:
Weight:
Compliance:
RS232 connector
(for Radiodetection use)
Model 50AG 50A /100V peak (Continuous)
Model 100AG 100A /100V peak (Continuous)
CP supply
CP switched
External Power
On/Off Time 0-100s
0.1 sec increments up to 10 secs
Master Slave 100ms in 12 hour period
GPS (option) +/- 4ms
2 x 1.5V D cells
300 hours @ 20°C
Will run from CP supply if above 5V
IP56
14°F (-20°C) to140°F (60°C)
80% up to 31°C decreasing to 50% at 40°C
Up to 2000m
12" (300mm) x 6" (150mm) x 3" (80mm)
2.5kg (5.5lb)
2004/108/EC, 1999/5/EC (GPS Option),
2006/95/EC, FCC CFR Part 15
Battery cover
Batteries
