Parts List - SINGULARITY COMPUTERS PHANTOM Assembly Manual

Parts List

Quantity
3
41 #
15 F
20 M
2 X
6 X
12 @
1
1
1
1
1
1
1
1
3
1
1
1
1
1
Prior to assembly, familiarise ourselves with all the pieces that we will need to build the SC
Phantom ITX/DTX Case and make sure we have all the parts needed, including computer
components. Building a Phantom system is an orderly process and missing steps or hardware
could result in having to undo multiple steps. All mounting holes are marked on the Phantom
PowerBoard pieces and there are legends on the main board that show which mark calls for
which assembly hardware. Using these markings, a Phantom can be built without an assembly
manual but prior experience is still needed.
Revision 1.0
Item
#6-32 NUT
#6-32 0.25" SCR
#6-32 10mm SO-F
#6-32 10mm SO-M
#6-32 25mm SO-M
#6-32 30mm SO-M
M3 4mm SCR
M3 / #6-32 Hex-key
Phantom PowerBoard
Universal Radiator Mount
Phantom Reinforcement "1"
Phantom Reinforcement "2"
Phantom Cover Top
Phantom Cover Mid
Phantom PCIe Bracket
Phantom PCIe Reinforcement
8pin EPS 10cm Linking Cable
24pin MB 10cm Linking Cable
"POWER SW" Wire
"RESET SW" Wire
Right-angled mains extension cable
Phantom ITX/DTX Case Assembly Manual
Note
SCR = SCRew
SO-F = StandOff Female
SO-M = StandOff Male
SO-M = StandOff Male
SO-M = StandOff Male
SCR = SCRew
Page | 4
